PDW-700/V1 (E)
CAM CONFIG 1 Display (Setting-1 on camcorder)
Item Setting Function
REC TALLY BLINK OFF/ON Turns ON/OFF the tally blinking at the event of BATTERY BEFORE END/DISC
BEFORE END
REC START BEEP OFF/ON Turns ON/OFF the beep sound at REC START/STOP
SUB LCD MODEL SEL TIMER/OFF/CONT Sets the time counter display on the LCD after the power supply is turned off
TIMER : Display is terminated after the elapse of time which is specified in the
item SUB LCD TIMER below
OFF : No displayed
CONT : Displayed
SUB LCD TIMER 1H/3H/8H Specifies the time to terminate the display of time counter after the power-off,
when TIMER was set in the above SUB LCD MODEL SEL (H : hour)
HDSDI REMOTE I/F OFF/CHARA/G-TLY/ Selects whether to use the function that enables recording control from this unit
R-TLY of an external device connected to the SDI OUT 1/2 connectors (HDSDI output)
of this unit.
*1
Also selects the indication that shows whether the external device
is recording
OFF : Do not use the remote recording control function
CHARA : Use the function, and indicate by the controlling external device
indicator in the viewfinder
G-TLY : Use the function, and indicate by the TALLY indicator in the viewfinder
R-TLY : Use the function, and indicate by the REC (recording, red tally) indicator
in the viewfinder
PROAV DISPLAY DSABL/ENABL Specifies whether to display the PROAV folder when this unit is accessed by a
FAM/FTP connection
DSABL : Do not display
ENABL : Display
MIXED RECORDING DSABL/ENABL Turns ON/OFF the function that enables recording and saving of the clips having
the different recording formats to the same disc only when they belong to the
same frame frequency group
*2
SINGLE CLIP MODE OFF/ON Selects the clip for the playback operation
ON : Selects only the currently selected clip for the playback operation
OFF : Selects all clips stored on the disc for the playback operation
PB POSITION KEEP/TOP Specifies the playback start position of the clip or sub clip when switching
between the clip playback screen and the clip list playback screen
KEEP : Resumes playback at the previous stop position
TOP : Starts playback from the top clip or from the top frame of the top sub clip
*1 : SDI OUT 1 SELECT or SDI OUT 2 SELECT in the OUTPUT 1 page of the OPERATION menu must be set to HDSDI.
*2 : The details of the frame frequency groups are shown below.
M12 CAM CONFIG 1 TOP
REC TALLY BLINK : ON
REC START BEEP : OFF
SUB LCD MODE SEL: TIMER
SUB LCD TIMER : 1H
HDSDI REMOTE I/F: OFF
PROAV DISPLAY : DSABL
MIXED RECORDING : DSABL
SINGLE CLIP MODE: OFF
PB POSITION : KEEP
59.94 Hz
50 Hz
23.98 Hz
59.94P, 59.94i, 29.97P
50P, 50i, 25P
23.98P
Frame frequency System frequency
