CAM CONFIG 2 Display (Setting-2 on camcorder)
Item Setting Function
TEST SAW SELECT REC/SAW Selects the test signal
COLOR BAR SELECT ARIB/100%/75%/SMPTE Selects the color bar type
Reference : The R GAIN and B GAIN value also change accordingly at the
same time.
USER & ALL ONLY OFF/ON Show only USER menu in the top menu
RM COMMON MEMORY OFF/ON Selects whether or not to share settings for when a remote control unit is
connected and when the unit is used alone
RM REC START RM/CAM/PARA When an remote control unit is connected, selects which recording start/stop
buttons are enabled
RM : Remote control unit
CAM : Camcorder
PARA : Both
SHT DISP MODE SEC/DEG Selects shutter speed display (second or degree)
AF MARKER SOURCE
*1
SAFE/ASPEC/USER When the FUJINON PF lens (HA22x7.4BRD, HA13x4.5BRD) is connected,
selects which existing marker is enabled to display the AF detection window
ASPEC : Use ASPECT MARKER as the substitute
SAFE : Use SAFETY ZONE as the substitute
USER : Use USER BOX as the substitute (It is not displayed in the LCD/
VBS output)
RM F NO DISPLAY CTRL/RET Selects the method used to display IRIS F values on the MSU-900 or another
remote control unit
CTRL : Display on the basis of control value from the camera
(normal display method)
RET: Display on the basis of position information from the lens
(same method as when AUTO IRIS is enabled)
FAN CONTROL
*2
AUTO/R.MIN/MIN Selects the control method of the cooling fan
AUTO : The cooling fan rotation is automatically controlled
R.MIN : The cooling fan runs at a low speed only during recording
(The fan stops rotating if the temperature inside the unit does not rise
due to the low temperature environment)
MIN : The cooling fan runs at a low speed (The fan stops rotating if the
temperature inside the unit does not rise due to the low temperature
environment)
n
Regardless of the setting of this item, the cooling fan starts running at a high
speed if the internal temperature of the unit rises close to the point where an
alarm is issued.
FOCUS MAG SW MTRY/ALT Selects the operation when the FOCUS MAG function is assigned to the
ASSIGN switch
MTRY : Turns ON only as long as it is pressed
ALT : Toggles between ON and OFF each time it is pressed
(Turns OFF automatically after 5 seconds have passed since ON)
*1 : Displayed only when AF DISPLAY is set to ON on SERVICE MENU.
*2 : The setting of this item is retained even after the power is turned off.
M13 CAM CONFIG 2 TOP
TEST SAW SELECT : SAW
COLOR BAR SELECT: ARIB
USER & ALL ONLY : OFF
RM COMMON MEMORY: OFF
RM REC START : RM
SHT DISP MODE : SEC
AF MARKER SOURCE: ASPEC
RM F NO DISPLAY : CTRL
FAN CONTROL : AUTO
FOCUS MAG SW : MTRY
