LENS FILE 2 Display (Setting-2 the LENS file)
Item Setting Function
LENS M VMOD (_99 to 99) Adjusts the lens file V SAW shading compensation
LENS CENTER H _480 to 479 Sets the center marker position (Horizontal direction)
LENS CENTER V _270 to 269 Sets the center marker position (Vertical direction)
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST OUT
connector
LENS R FLARE (_99 to 99) Adjusts the R flare compensation level
LENS G FLARE (_99 to 99) Adjusts the G flare compensation level
LENS B FLARE (_99 to 99) Adjusts the B flare compensation level
LENS W-R OFST (_99 to 99) Adjusts the R white gain offset value
LENS W-B OFST (_99 to 99) Adjusts the B white gain offset value
n
In the LENS M VMOD, LENS CENTER H, LENS CENTER V, LENS R/G/B FLARE and LENS W-R/
W-B OFST, the lens extender position is displayed in the rightmost-end of the menu items.
Blank : Extender OFF
EX : Extender ON
0.8 : Shrinker ON
F07 LENS FILE 2 TOP
LENS M VMOD : 0
LENS CENTER H : 0
LENS CENTER V : 0
TEST OUT SELECT : VBS
LENS R FLARE : 0
LENS G FLARE : 0
LENS B FLARE : 0
LENS W-R OFST : 0
LENS W-B OFST : 0
