4-64
PDW-700/V1 (E)
F09 MEMORY STICK TOP
M.S.FORMAT : EXEC
M.S.IN > JUMP TO: OFF
LENS FILE 3 Display (Setting-3 the LENS file)
Item Setting Function
SHADING CH SEL Y/R/G/B/TEST Selects the channel of shading adjustment
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST OUT
connector
LENS R H SAW (_99 to 99) Adjusts the H SAW correction value
LENS R H PARA (_99 to 99) Adjusts the H PARA correction value
LENS R V SAW (_99 to 99) Adjusts the V SAW correction value
LENS R V PARA (_99 to 99) Adjusts the V PARA correction value
n
In the LENS R/G/B V/H SAW and LENS R/G/B V/H PARA, the lens extender position is displayed in
the rightmost-end of the menu items.
Blank : Extender OFF
EX : Extender ON
0.8 : Shrinker ON
MEMORY STICK Display (Function on Memory Stick)
Item Setting Function
M. S. FORMAT Press the MENU knob Implements formatting of a Memory Stick
to execute this menu item (All of the data is erased)
M. S. IN > JUMP TO OFF/USER/ALL/SCENE/ Sets the function that opens the file setup page
LENS/REFER/USER1 automatically as a Memory Stick is inserted when this
menu is set to ON
(This function is disabled when the file-related page is
opened already)
F08 LENS FILE 3 TOP
SHADING CH SEL : R
TEST OUT SELECT : VBS
LENS R H SAW : 0
LENS R H PARA : 0
LENS R V SAW : 0
LENS R V PARA : 0
To Next Page
