4-70
PDW-700/V1 (E)
S01 MENU SET TOP
RE ROTATION REV : OFF
RE SPEED : 2
DIRECT VALUE : OFF
SERVICE RESET : EXEC
FACTORY PRESET : EXEC
MENU SET
Item Setting Function
RE ROTATION REV OFF/ON Turns ON/OFF the function to invert the rotating direction of the
MENU knob
RE SPEED 1/2/3 Sets the response speed of the MENU knob 1 (slow)
→
3 (fast)
DIRECT VALUE OFF/DEC/HEX OFF: The set value is displayed after conversion (in the range of
-99 to 99) (It returns to OFF when the main power is turned on)
DEC : The set value is displayed after being converted into a decimal
number (The variable range differs depending on the item)
HEX : The set value is displayed after being converted into a hexadecimal
number (The variable range differs depending on the item)
SERVICE RESET Press the MENU knob Resets the data in the SERVICE hierarchy
to execute this menu item Refer to “5-2 Data Structure” for details of the hierarchical structure
FACTORY PRESET Press the MENU knob Returns all of the settings to the default setting when shipped from the
to execute this menu item factory (Excluding the black balance automatic adjustment value)
SP FUNC
Item Setting Function
GAIN DISP MODE dB/ISO Turns ON/OFF the function that sets the GAIN value in the ISO indication
ON: ISO indication
OFF: Decibel (dB) indication
n
Correspondence between the ISO and decibel (dB) indications is shown
below. Values in parenthesis indicate the decibel (dB) indication
400(-6)/570(-3)/800(0)/1100(3)/1600(6)/2300(9)/3200(12)/6400(18)
13000(24)/26000(50)/51000(36)/100000(42)
KNEE 2ND POINT OFF/ON The setting whether or not to enable the knee 2nd point when
compressing a high luminance signal
ON : The knee 2nd point is enabled to allow operator to compress the
high luminance part in wide range
OFF : The knee 2nd point is disabled and only the knee 1st point is
enabled
S02 SP FUNC TOP
GAIN DISP MODE : dB
KNEE 2ND POINT : ON
