4-71
PDW-700/V1 (E)
S03 WHITE SHADING TOP
WHT SHAD CH SEL : R
TEST OUT SELECT : VBS
R WHT H SAW : 0
R WHT H PARA : 0
R WHT V SAW : 0
R WHT V PARA : 0
WHITE SAW/PARA : ON
WHITE SHADING
Item Setting Function
WHT SHAD CH SEL R/G/B/TEST Selects the channel of shading correction
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
R WHT H SAW (-99 to 99) Adjusts the H SAW correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above WHT SHAD CH SEL
R WHT H PARA (-99 to 99) Adjusts the H PARA correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above WHT SHAD CH SEL
R WHT V SAW (-99 to 99) Adjusts the V SAW correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above WHT SHAD CH SEL
R WHT V PARA (-99 to 99) Adjusts the V PARA correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above WHT SHAD CH SEL
WHITE SAW/PARA OFF/ON Turns ON/OFF all of the white shading menu items of R/G/B, H/V and
SAW/PARA corrections
