PDW-700/V1 (E)
S04 BLACK SHADING TOP
BLK SHAD CH SEL : R
TEST OUT SELECT : VBS
R BLK H SAW : 0
R BLK H PARA : 0
R BLK V SAW : 0
R BLK V PARA : 0
BLACK SAW/PARA : ON
MASTER BLACK : 0
MASTER GAIN(TMP): 0dB
BLACK SHADING
Item Setting Function
BLK SHAD CH SEL R/G/B/TEST Selects the channel of shading correction
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
R BLK H SAW (-99 to 99) Adjusts the H SAW correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above BLK SHAD CH SEL
R BLK H PARA (-99 to 99) Adjusts the H PARA correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above BLK SHAD CH SEL
R BLK V SAW (-99 to 99) Adjusts the V SAW correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above BLK SHAD CH SEL
R BLK V PARA (-99 to 99) Adjusts the V PARA correction
(R/G/B) The R, G and B displays are switched in accordance with the channel
selection implemented by the above BLK SHAD CH SEL
BLACK SAW/PARA OFF/ON Turns ON/OFF all of the black shading menu items of R/G/B, H/V and
SAW/PARA corrections
MASTER BLACK (-99 to 99) Adjusts the master black level
(All of the R, G and B master black levels are adjusted)
MASTER GAIN (TMP) -6/-3/0/3/6/9/12/ Temporarily adjusts the master gain value
18/24/30/36/42 dB
To Next Page
