4-80
PDW-700/V1 (E)
FAN
Item Setting Function
FAN VOLT FIX OFF/ON Sets the fan mode
(Normally, set this to OFF and use the automatic control)
OFF: Temperature increase inside the unit is detected and the fan is
automatically controlled
ON: The fan is controlled by the fixed voltage (8 V)
(For the operation check of the fan)
FAN ROTATION DET —/OK/NG Display only
MEASURE
Item Setting Function
MEASUREMENT OFF/S/N/MODU/RESO/ Selects the measurement mode
MODE SENSE/REGI/DRANG OFF : It returns to OFF when the main power is turned on
S/N : S/N ratio measurement mode
MODU : Modulation degree measurement mode
RESO : Resolution power measurement mode
SENSE : Sensitivity measurement mode
REGI : Registration measurement mode
DRANG : Dynamic range measurement mode
MASTER BLACK (_99 to 99) Adjusts the master black level
(All of the R, G and B signal black levels are adjusted)
MASTER GAIN(TMP) _6/_3/0/3/6/9/12/18/24/ Sets the tentative gain value
30/36/42
S17 FAN TOP
FAN VOLT FIX : OFF
FAN ROTATION DET: OK
S18 MEASURE TOP
MEASUREMENT MODE: OFF
MASTER BLACK : 0
MASTER GAIN(TMP): 0dB
