4-79
PDW-700/V1 (E)
DRIVE MAINTE Screen
Menu Item Sub item Description
CHECK DEVICE TEMPERATURE Checks the temperature sensor on the drive block
SENSOR
DEW SENSOR Checks the dew sensor on the optical block assembly
FAN MOTOR Checks the fan motor connected to the drive block
ACCELERATION Checks the acceleration sensor
SENSOR
LOADER Checks the loader performance
AUTO TEST Checks the slider performance and the limit sensor
SLIDER IN-LIM TEST Moves the slider to the IN LIMIT position
OUT-LIM TEST Move the slider to the OUT LIMIT position
SPINDLE AUTO TEST Checks the spindle motor performance
MOTOR
OPTICAL FOCUS ACTUATOR Checks the focus directions of the two shafts
BLOCK
TRACKING Checks the tracking directions of the two shafts
ACTUATOR
SA ACTUATOR Checks the SA actuator
LASER Checks the laser
ND FILTER Checks the ND filter
LENS CLEANING Performs Pick-up lens cleaning
ADJUST SERVO_1 Servo 1 system (MTX BLOCK, PI/FE BLOCK, FE AGC) auto
adjustment
SKEW TAN ADJUST Adjust the skew
RAD ADJUST
SERVO_2 Servo 2 system (SKEW OFFSET, TE/CE BLOCK, SV LOOP GAIN)
auto adjustment
OTHER ADJUST ACCELERATION Adjusts the offset of the acceleration sensor
OFFSET
ERROR LOGGER Records the error occurred in the drive
OTHERS VERSION Displays the version of the drive block
SERIAL NO Displays the serial number of the drive block
CLEAR MEDIA LOG Clears the acquired media information
MEMORY UPLOAD TO Uploads the data backed up in the DR-606 board back to the
SUPPORT EEPROM EEPROM (IC4) on the SE-857 board
