4-78
PDW-700/V1 (E)
S16 VDR MAINTENANCE TOP
AUDIO A/D ADJUST: EXEC
AUDIO D/A ADJUST: EXEC
AU SIDE VOL ADJ : EXEC
POWER A/D ADJUST: EXEC
DRIVE MAINTE : EXEC
SERVICE SUPPORT : EXEC
PRN MANAGE
Item Setting Function
CONC (APR) RESET Press the MENU knob Deletes the RPN data registered at ABB, APR, or AUTO CONCEAL
to execute this menu item
CONC2 (APR) RESET Press the MENU knob Deletes the RPN data registered at ABB, APR (SLS), or AUTO CONCEAL2
to execute this menu item
RPN ALL PRESET Press the MENU knob Returns all RPN data to the state of factory shipment
to execute this menu item (Data registered manually are also deleted)
AUTO CONCEAL Press the MENU knob Executes the AUTO RPN correction
to execute this menu item (The Black Level adjustment is not executed)
AUTO CONCEAL2 Press the MENU knob Executes the AUTO RPN correction (For SLS ON)
to execute this menu item (The Black Level adjustment is not executed)
n
The execution time for this function is about 30 minutes.
More time may be required when temperatures inside the unit are low.
VDR MAINTENANCE
Item Setting Function
AUDIO A/D ADJUST Press the MENU knob Adjustment of the AUDIO A/D Error Correction value
to execute this menu item (Refer to “4-11. AUDIO A/D Error Correction” for details)
AUDIO D/A ADJUST Press the MENU knob Adjustment of the AUDIO D/A Error Correction value
to execute this menu item (Refer to “4-12. AUDIO D/A Error Correction” for details)
AU SIDE VOL ADJ Press the MENU knob Adjustment of the AUDIO LEVEL Volume (inside panel)
to execute this menu item Error Correction value
(Refer to “4-13. AUDIO LEVEL Volume Compensation” for details)
POWER A/D ADJUST Press the MENU knob Adjustment of the Battery END Detecting Voltage
to execute this menu item (Refer to “4-14. Adjusting Battery End Detection Voltage” for details)
DRIVE MAINTE Press the MENU knob For the description of DRIVE MAINTE screen, see below
to move to the DRIVE
MAINTE screen
SERVICE SUPPORT Press the MENU knob Displaying the VDR system error log and setting clear
to move to the SERVICE (Refer to “4-15. SERVICE SUPPORT Menu” for details)
SUPPORT screen
S15 RPN MANAGE TOP
CONC (APR)RESET : EXEC
CONC2(APR)RESET : EXEC
RPN ALL PRESET : EXEC
AUTO CONCEAL : EXEC
AUTO CONCEAL2 : EXEC
