4-77
PDW-700/V1 (E)
S13 GAMMA/DETAIL TOP
R GAMMA : 0
G GAMMA : 0
B GAMMA : 0
DETAIL LEVEL : 0
GAMMA / DETAIL
Item Setting Function
R GAMMA (_99 to 99) Offsets PAINT/GAMMA/R
G GAMMA (_99 to 99) Offsets PAINT/GAMMA/G
B GAMMA (_99 to 99) Offsets PAINT/GAMMA/B
DETAIL LEVEL (_99 to 99) Offsets PAINT/DETAIL1/DETAIL LEVEL
MANUAL RPN
Item Setting Function
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
RPN CURSOR OFF/ON Controls ON/OFF of the RPN cursor
SUPER (MENU) OFF/ON Turns ON/OFF the character information output (superimpose) of the
TEST OUT connector
RPN WIDTH 0/1/2/3/4 Sets the RPN correction width
CURSOR H POS 37 to 1966 Sets position of the RPN cursor (horizontal)
CURSOR V POS 34 to 1118 Sets position of the RPN cursor (vertical)
CURSOR JUMP PREV/CURR/NEXT Jumps the cursor to the position in which the RPN data is registered
PREV : Jumps to the RPN data preceding the current position
CURR : Current display
NEXT : Jumps to the RPN data after the current position
RECORD RPN Press the MENU knob Registers the RPN data of the present cursor position
to execute this menu item
DELETE RPN Press the MENU knob Deletes the RPN data of the present cursor position
to execute this menu item
S14 MANUAL RPN TOP
TEST OUT SELECT : VBS
RPN CURSOR : OFF
SUPER(MENU) : OFF
RPN WIDTH : 1
CURSOR H POS : 960
CURSOR V POS : 540
CURSOR JUMP : CURR
RECORD RPN : EXEC
DELETE RPN : EXEC
