S12 FLARE TOP
R FLARE : 0
G FLARE : 0
B FLARE : 0
FLARE : ON
TEST OUT SELECT : VBS
S11 LCD ADJUST TOP
LCD VCO ADJUST : EXEC
LCD COM DC : 0
LCD BLACK LIMIT : 0
LCD PS BRIGHT : 0
LCD BRIGHT : 0
LCD BRIGHT R : 0
LCD BRIGHT B : 0
LCD CONTRAST : 0
LCD ADJUST
Item Setting Function
LCD VCO ADJUST Press the MENU knob Adjusts the free run frequency of the color LCD VCO
to execute this menu item
LCD COM DC (_99 to 99) Adjusts the DC bias of the common electrode drive signal of the color LCD
LCD BLACK LIMIT (_99 to 99) Adjusts the limiter level on the black side of the color LCD
LCD PS BRIGHT (_99 to 99) Adjusts the amplitude of the output signal of the color LCD PSIG
LCD BRIGHT (_99 to 99) Adjusts the color LCD brightness displayed in normal position
LCD BRIGHT R (_99 to 99) Adjusts the black balance of the picture displayed in normal position
Adjusts the R output signal BRIGHT with reference to the G output signal
LCD BRIGHT B (_99 to 99) Adjusts the black balance of the picture displayed in reverse position
Adjusts the B output signal BRIGHT with reference to the G output signal
LCD CONTRAST (_99 to 99) Adjusts the color LCD contrast displayed in normal position
FLARE
Item Setting Function
R FLARE (_99 to 99) Adjusts the R flare compensation level
G FLARE (_99 to 99) Adjusts the G flare compensation level
B FLARE (_99 to 99) Adjusts the B flare compensation level
FLARE OFF/ON Turns ON/OFF the flare compensation circuit
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
