4-75
PDW-700/V1 (E)
REGI ADJUST
Item Setting Function
R CCD REGI -0.100 to 0.1 % (0.002 % step) Adjusts the registry (H direction) of CCD
B CCD REGI -0.100 to 0.1 % (0.002 % step) Adjusts the registry (H direction) of CCD
R DCP REGI -0.100 to 0.1 % (0.002 % step) Adjusts the registry (H direction) of the DCP circuit
B DCP REGI -0.100 to 0.1 % (0.002 % step) Adjusts the registry (H direction) of the DCP circuit
DCP REGI PULSE OFF/ON Turns ON/OFF the pulse for the adjustment of the registry
(H direction) of the DCP circuit
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
FBC ADJUST
Item Setting Function
FBC ADJUST MODE OFF/ON Periodically switches the high-speed feedback clamp and the normal
feedback clamp (For adjusting R/G/B FBC OFFSET)
R FBC OFFSET (_99 to 99) Adjusts the DC offset for the high-speed feedback clamp
G FBC OFFSET (_99 to 99) Adjusts the DC offset for the high-speed feedback clamp
B FBC OFFSET (_99 to 99) Adjusts the DC offset for the high-speed feedback clamp
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
S09 REGI ADJUST TOP
R CCD REGI : 0.000%
B CCD REGI : 0.000%
R DCP REGI : 0.000%
B DCP REGI : 0.000%
DCP REGI PULSE : OFF
TEST OUT SELECT : VBS
S10 FBC ADJUST TOP
FBC ADJUST MODE : OFF
R FBC OFFSET : 0
G FBC OFFSET : 0
B FBC OFFSET : 0
TEST OUT SELECT : VBS
