4-74
PDW-700/V1 (E)
S08 CCD ADJUST 2 TOP
R VSUB : 14.0V
G VSUB : 14.0V
B VSUB : 14.0V
R VSUB OFST (P) : ±0.0V
G VSUB OFST (P) : ±0.0V
B VSUB OFST (P) : ±0.0V
CCD H DRIVER : 6.0V
AD CLOCK PHASE : ±0
TEST OUT SELECT : VBS
S07 CCD ADJUST 1 TOP
R CCD GAIN : 0
G CCD GAIN : 0
B CCD GAIN : 0
R TEST SAW GAIN : 0
G TEST SAW GAIN : 0
B TEST SAW GAIN : 0
TEST SAW : OFF
TEST OUT SELECT : VBS
CCD ADJUST 1
Item Setting Function
R CCD GAIN -99 to 99 Adjusts the sensitivity of the R-channel
G CCD GAIN -99 to 99 Adjusts the sensitivity of the G-channel
B CCD GAIN -99 to 99 Adjusts the sensitivity of the B-channel
R TEST SAW GAIN -99 to 99 Adjusts the GAIN of the R-channel test saw
G TEST SAW GAIN -99 to 99 Adjusts the GAIN of the G-channel test saw
B TEST SAW GAIN -99 to 99 Adjusts the GAIN of the B-channel test saw
TEST SAW OFF/ON Turns ON/OFF the test saw function
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
CCD ADJUST 2
Item Setting Function
R VSUB 9.0 V to 18.0 V (0.1 V step)
*1
Sets the V. substrate voltage of the R-channel
G VSUB 9.0 V to 18.0 V (0.1 V step)
*1
Sets the V. substrate voltage of the G-channel
B VSUB 9.0 V to 18.0 V (0.1 V step)
*1
Sets the V. substrate voltage of the B-channel
R VSUB OFST (P) -5.0 V to +5.0 V (0.1 V step) Adjusts the offset for the V. substrate voltage of the R-channel during the
progressive reading
*2
G VSUB OFST (P) -5.0 V to +5.0 V (0.1 V step) Adjusts the offset for the V. substrate voltage of the G-channel during the
progressive reading
*2
B VSUB OFST (P) -5.0 V to +5.0 V (0.1 V step) Adjusts the offset for the V. substrate voltage of the B-channel during the
progressive reading
*2
CCD H DRIVER 5.2 V/5.4 V/5.6 V/5.8 V/6.0 V/6.2 V Sets the drive voltage of the CCD H DRIVE
AD CLOCK PHASE -2/-1/± 0/+1/+2 Sets the phase frequency of AD
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal of the TEST OUT connector
*1 : The default value varies depending on the set.
*2 : The setting that enters the Camcorder in the progressive reading
• When the SYSTEM LINE is 1080 and SYSTEM FREQUENCY is 29.9P, 25P or 23.9P at the same time, or when the slow shutter function is set to ON.
• When the SYSTEM LINE is 720 and the SYSTEM FREQUENCY is 59.9P, and at the same time SCAN MODE is 23.9P.
For example, the V. substrate voltage of the R-channel in 1080/29.9P becomes the sum of R VSUB setup value and the R VSUB OFST (P) setup value.
