4-83
PDW-700/V1 (E)
FUNCTION LIMIT
Item Setting Function
AF DISPLAY OFF/ON When the FUJINON PF lens (HA22x7.4BRD, HA13x4.5BRD) is used,
turns ON/OFF the function that displays the AF detection window and the
in-focus indicator on the viewfinder screen
*
* : Turning ON/OFF the AF detection window, changing the area and turning ON/OFF the in-focus display are activated by the switch of the lens side.
(For details, refer to the lens specifications.)
In-focus indicator display (displayed above F value display of lens on VF DISP) : Out of former focus
Just focus
Out of post-focus
S/H DC
Item Setting Function
S/H DC ADJ MODE OFF/ON Turns ON/OFF the function that displays the dummy white spots (vertical
bars) for adjustment on the screen (The dummy white spots are displayed
in the order of R/G/B starting from the center of screen to the right)
Adjusts the S/H DC B R-channel/G-channel/B-channel to the point where
the dummy white spots are least visible on the screen (Adjusts them with
the GAIN set in 12 dB)
TEST OUT SELECT VBS/Y/R/G/B/LCD Select the video signal to be output from the TEST OUT connector
S/H DC B R ch (1) (_99 to 99) Adjusts the sample-and-hold DC level of the R-channel
*
S/H DC B G ch (1) (_99 to 99) Adjusts the sample-and-hold DC level of the G-channel
*
S/H DC B B ch (1) (_99 to 99) Adjusts the sample-and-hold DC level of the B-channel
*
* : If this adjustment is not made for optimum result, the troubles may occur such as thin vertical bars during the high gain mode or poor accuracy of white spot
compensation.
S22 FUNCTION LIMIT TOP
AF DISPLAY : OFF
S23 S/H DC TOP
S/H DC ADJ MODE : OFF
TEST OUT SELECT : VBS
S/H DC B Rch (1): 0
S/H DC B Gch (1): 0
S/H DC B Bch (1): 0
