When at least one PES bit is set, the following occurs:
• Any ongoing program or erase operation is completed.
The maximum latency for a Flash program erase suspension is the maximum time for
one program or erase operation to complete (see product datasheets for more
information on the Flash program and erase timing).
• All new requested program and erase operations is not started but suspended.
PESD bits in FLASH_SR and FLASH_C2SR are set as soon as any PES is set, no
matter if a program/erase is currently suspended. This allows a CPU to test PESD prior
to requesting a program or an erase operation.
When all PES bits are reset to 0, a suspended program or erase operation is started: the
PESD bits are cleared.
4.8 FLASH interrupts
4.8.1 Illegal access interrupts
Unprivileged access to privileged registers generates an illegal access event. This event is
connected to the GTZC_TZIC.
Non-secure access to secure registers generates an illegal access event. This event is
connected to the GTZC_TZIC.
For more information on illegal access events see: Section 3: Global security controller
(GTZC).
Table 23. Flash interrupt requests
Interrupt event Event flag
Event flag/interrupt
clearing method
Interrupt enable
control bit
End of operation EOP
(1)
Write EOP=1 EOPIE
Operation error OPERR
(2)
Write OPERR=1 ERRIE
Readout protection error RDERR Write RDERR=1 RDERRIE
Write protection error WRPERR Write WRPERR=1 N/A
Size error SIZERR Write SIZERR=1 N/A
Programming sequential error PROGERR Write PROGERR=1 N/A
Programming alignment error PGAERR Write PGAERR=1 N/A
Programming sequence error PGSERR Write PGSERR=1 N/A
Data miss during fast programming error MISSERR Write MISSERR=1 N/A
Fast programming error FASTERR Write FASTERR=1 N/A
ECC error correction ECCC Write ECCC=1 ECCCIE
ECC double-error (NMI) ECCD Write ECCD=1 N/A
1. EOP is set only if EOPIE is set.
2. OPERR is set only if ERRIE is set.
