RM0453 Rev 2 435/1454

RM0453 System configuration controller (SYSCFG)

444

11.2.8 SYSCFG configuration register 2 (SYSCFG_CFGR2)

Address offset: 0x01C

Reset value: 0x0000 0000

Bits 7:2 Reserved, must be kept at reset value.

Bit 1 SRAMBSY: SRAM1 or SRAM2 busy by erase operation

0: No SRAM1 or SRAM2 erase operation is ongoing.

1: SRAM1 or SRAM2 erase operation is ongoing.

See Section 2.4: SRAM erase for more information on SRAM erase conditions

Bit 0 SRAM2ER: SRAM2 erase

Setting this bit starts a hardware SRAM2 erase operation. This bit is automatically cleared at

the end of the SRAM2 erase operation.

Note: This bit is write-protected: setting this bit is possible only after the correct key sequence

is written in the SYSCFG_SKR register.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. Res. Res. Res. Res. Res. SPF Res. Res. Res. Res. ECCL PVDL SPL CLL

rc_w1 rsrsrsrs

Bits 31:9 Reserved, must be kept at reset value.

Bit 8 SPF: SRAM2 parity error flag

This bit is set by hardware when an SRAM2 parity error is detected. It is cleared by software

by writing ‘1’.

0: No SRAM2 parity error detected

1: SRAM2 parity error detected

Bits 7:4 Reserved, must be kept at reset value.

Bit 3 ECCL: ECC lock

This bit is set by software and cleared only by a system reset. It can be used to enable and

lock the Flash ECC error connection to TIM1/16/17 break input.

0: ECC error disconnected from TIM1/16/17 break input.

1: ECC error connected to TIM1/16/17 break input.
