24.7.3 PKA clear flag register (PKA_CLRFR)
Address offset: 0x08
Reset value: 0x0000 0000
Note: Reading PKA_CLRFR returns all 0s.
24.7.4 PKA RAM
The PKA RAM is mapped at the offset address of 0x0400 compared to the PKA base
address. Only 32-bit word single accesses are supported, through PKA.AHB interface.
RAM size is 3576 bytes (max word offset: 0x11F4).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ADDR
ERRFC
RAM
ERRFC
Res.
PROC
ENDFC
Res.
ww w
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 ADDRERRFC: Clear Address error flag
0: No action
1: Clear the ADDRERRF flag in PKA_SR
Bit 19 RAMERRFC: Clear PKA RAM error flag
0: No action
1: Clear the RAMERRF flag in PKA_SR
Bit 18 Reserved, must be kept at reset value.
Bit 17 PROCENDFC: Clear PKA End of Operation flag
0: No action
1: Clear the PROCENDF flag in PKA_SR
Bits 16:0 Reserved, must be kept at reset value.
