Stober PK - Page 109

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C7 (n
1N
= 3000 rpm, M
2acc,max
= 2760 Nm)
228 272 386 1.9 4.7 C712_0130 MB33 EZ705U 1279 2417 13.18 4851/368 16 32 2900 2600 4000 89 122 131
228 272 386 1.9 4.7 C712_0130 MB33 EZ705U 1279 2417 13.18 4851/368 24 32 2900 2600 4000 89 122 131
228 272 386 1.9 4.7 C712_0130 MB33 EZ705U 1279 2417 13.18 4851/368 32 32 2900 2600 4000 89 122 131
228 272 386 1.9 4.7 C712_0130 MB33 EZ705U 1279 2417 13.18 4851/368 45 32 2900 2600 4000 89 122 131
303 205 290 2.2 4.7 C712_0099 MB33 EZ705U 961 1817 9.912 4599/464 16 32 2900 2600 4000 98 122 131
303 205 290 2.2 4.7 C712_0099 MB33 EZ705U 961 1817 9.912 4599/464 24 32 2900 2600 4000 98 122 131
303 205 290 2.2 4.7 C712_0099 MB33 EZ705U 961 1817 9.912 4599/464 32 32 2900 2600 4000 98 122 131
303 205 290 2.2 4.7 C712_0099 MB33 EZ705U 961 1817 9.912 4599/464 45 32 2900 2600 4000 98 122 131
C8 (n
1N
= 2000 rpm, M
2acc,max
= 4800 Nm)
60 1424 2153 2.3 2.5 C812_0340 MB43 EZ805U 4800 8400 33.59 2183/65 50 115 2900 2700 3000 275 145 237
73 1164 1761 2.1 3.1 C812_0270 MB43 EZ805U 4140 7200 27.47 412/15 50 115 2900 2700 3000 289 204 237
77 1105 1671 2.1 3.1 C812_0260 MB43 EZ805U 4800 8400 26.06 3127/120 50 115 2900 2700 3000 281 145 237
86 983 1487 1.9 3.7 C812_0230 MB43 EZ805U 4140 7200 23.19 1600/69 50 115 2900 2700 3000 297 204 237
99 859 1299 2.0 3.9 C812_0200 MB43 EZ805U 4028 6602 20.26 6077/300 50 115 2900 2700 3000 290 145 237
116 733 1108 1.8 4.6 C812_0175 MB43 EZ805U 3438 5634 17.29 1504/87 50 115 2700 2400 3000 314 204 237
117 725 1096 1.9 4.4 C812_0170 MB43 EZ805U 3401 5574 17.10 1180/69 50 115 2900 2700 3000 298 145 237
145 583 882 2.0 4.6 C812_0140 MB43 EZ805U 2737 4486 13.76 1280/93 50 115 2700 2400 3000 332 204 237
157 540 817 2.1 4.6 C812_0125 MB43 EZ805U 2535 4155 12.75 5546/435 50 115 2700 2400 3000 317 145 237
197 430 651 2.3 4.6 C812_0100 MB43 EZ805U 2019 3308 10.15 944/93 50 115 2700 2400 3000 337 145 237
221 383 580 2.4 4.6 C812_0090 MB43 EZ805U 1798 2947 9.043 208/23 50 115 2500 2200 3000 384 204 237
300 283 428 2.8 4.6 C812_0067 MB43 EZ805U 1326 2174 6.670 767/115 50 115 2500 2200 3000 395 145 237
C8 (n
1N
= 3000 rpm, M
2acc,max
= 4720 Nm)
75 1030 1867 1.7 3.2 C812_0400 MB43 EZ803U 4542 7570 39.94 2596/65 50 65 2900 2700 3000 184 145 221
85 912 1652 1.4 3.9 C812_0350 MB43 EZ803U 4140 7200 35.33 106/3 50 65 2900 2700 3000 192 204 221
85 912 1652 1.4 3.9 C812_0350 MB43 EZ803U 4140 7200 35.33 106/3 72 65 2900 2700 3000 192 204 221
89 867 1570 1.6 3.6 C812_0340 MB43 EZ803U 4724 8400 33.59 2183/65 50 65 2900 2700 3000 187 145 221
89 867 1570 1.6 3.6 C812_0340 MB43 EZ803U 4724 8400 33.59 2183/65 72 65 2900 2700 3000 187 145 221
89 867 1570 1.6 3.6 C812_0340 MB43 EZ803U 4724 8400 33.59 2183/65 100 65 2900 2700 3000 187 145 221
115 672 1218 1.5 4.5 C812_0260 MB43 EZ803U 3665 8400 26.06 3127/120 50 65 2900 2700 3000 193 145 221
115 672 1218 1.5 4.5 C812_0260 MB43 EZ803U 3665 8400 26.06 3127/120 72 65 2900 2700 3000 193 145 221
115 672 1218 1.5 4.5 C812_0260 MB43 EZ803U 3665 8400 26.06 3127/120 100 65 2900 2700 3000 193 145 221
5 Chelical geared motors 5.2 Selection tables
109
