11 Synchronous servo motors
EZ
11.1 Overview
Synchronous servo motors with single tooth winding
Features
High dynamics
✓
Short length
✓
Super compact due to tooth-coil winding
method with the highest possible copper fill fac-
tor
✓
Backlash-free holding brake (optional)
✓
Electronic nameplate for fast and reliable com-
missioning
✓
Convection cooling or forced ventilation (op-
tional)
✓
Optical, inductive EnDat absolute encoders or
resolvers
✓
Elimination of referencing with multi-turn abso-
lute encoders (optional)
✓
One Cable Solution (OCS) with EnDat 3 encoder
(optional)
✓
Rotatable plug connectors with quick lock
✓
Torques
M
N
0.4 – 77.2 Nm
M
0
0.44 – 94 Nm
376
