7.2 Selection tables
The technical data specified in the selection tables applies to:
• Installation altitudes up to 1000m above sea level
• Surrounding temperatures from 0°C to 40°C
• Drives with convection-cooled motors (e.g. EZ401U)
• Without consideration of the thermal limiting performance
For the technical data on drives with forced ventilated motors (e.g. EZ401B), refer to
https://configurator.stoeber.de/en-US/
.
An explanation of the formula symbols can be found in the chapter [}15.1].
n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P531K (n
1N
= 3000 rpm, M
2acc,max
= 350 Nm)
150 81 88 29 2.7 P531_0050K102_0040 MB23 EZ501U 301 300 700 20.00 20/1 8.0 8.0 3300 2800 4000 11 29 32
150 88 98 32 2.5 P531_0050K102_0040 MB23 EZ402U 301 300 700 20.00 20/1 8.0 8.0 3300 2800 4000 9.9 29 31
150 130 162 47 1.7 P531_0050K102_0040 MB23 EZ404U 350 390 700 20.00 20/1 8.0 8.0 3300 2800 4000 11 29 33
150 139 151 50 1.6 P531_0050K102_0040 MB23 EZ502U 350 390 700 20.00 20/1 8.0 8.0 3300 2800 4000 13 29 33
188 65 71 26 3.1 P531_0040K102_0040 MB23 EZ501U 241 240 600 16.00 16/1 8.0 8.0 3300 2800 4000 11 27 32
188 65 71 26 3.1 P531_0040K102_0040 MB23 EZ501U 241 240 600 16.00 16/1 12 8.0 3300 2800 4000 11 27 32
188 71 78 28 2.8 P531_0040K102_0040 MB23 EZ402U 241 240 600 16.00 16/1 8.0 8.0 3300 2800 4000 9.9 27 31
188 71 78 28 2.8 P531_0040K102_0040 MB23 EZ402U 241 240 600 16.00 16/1 12 8.0 3300 2800 4000 9.9 27 31
188 104 129 41 1.9 P531_0040K102_0040 MB23 EZ404U 300 320 600 16.00 16/1 8.0 8.0 3300 2800 4000 11 27 33
188 104 129 41 1.9 P531_0040K102_0040 MB23 EZ404U 300 320 600 16.00 16/1 12 8.0 3300 2800 4000 11 27 33
188 111 120 44 1.8 P531_0040K102_0040 MB23 EZ502U 300 320 600 16.00 16/1 8.0 8.0 3300 2800 4000 14 27 33
188 111 120 44 1.8 P531_0040K102_0040 MB23 EZ502U 300 320 600 16.00 16/1 12 8.0 3300 2800 4000 14 27 33
250 49 53 32 2.5 P531_0030K102_0040 MB23 EZ501U 181 180 400 12.00 12/1 8.0 8.0 3300 2800 4000 11 22 32
250 53 59 35 2.3 P531_0030K102_0040 MB23 EZ402U 181 180 400 12.00 12/1 8.0 8.0 3300 2800 4000 10 22 31
250 78 97 52 1.5 P531_0030K102_0040 MB23 EZ404U 200 200 400 12.00 12/1 8.0 8.0 3300 2800 4000 11 22 33
250 84 90 55 1.4 P531_0030K102_0040 MB23 EZ502U 200 200 400 12.00 12/1 8.0 8.0 3300 2800 4000 14 22 33
P731K (n
1N
= 3000 rpm, M
2acc,max
= 810 Nm)
65 188 206 25 2.2 P731_0070K102_0066 MB23 EZ501U 700 700 1561 46.51 2093/45 8.0 8.0 3600 3300 4000 11 52 38
65 206 228 27 2.0 P731_0070K102_0066 MB23 EZ402U 700 700 1561 46.51 2093/45 8.0 8.0 3600 3300 4000 9.4 52 38
65 302 376 39 1.4 P731_0070K102_0066 MB23 EZ404U 786 790 1561 46.51 2093/45 8.0 8.0 3600 3300 4000 11 52 40
65 324 350 42 1.3 P731_0070K102_0066 MB23 EZ502U 786 790 1561 46.51 2093/45 8.0 8.0 3600 3300 4000 13 52 40
65 186 203 20 2.4 P731_0050K202_0092 MB23 EZ501U 692 690 1610 45.95 11395/248 8.0 8.0 3500 3100 4000 11 53 46
65 203 225 22 2.2 P731_0050K202_0092 MB23 EZ402U 692 690 1610 45.95 11395/248 8.0 8.0 3500 3100 4000 9.9 53 46
65 298 372 32 1.5 P731_0050K202_0092 MB23 EZ404U 805 840 1610 45.95 11395/248 8.0 8.0 3500 3100 4000 11 53 48
65 320 346 34 1.4 P731_0050K202_0092 MB23 EZ502U 805 840 1610 45.95 11395/248 8.0 8.0 3500 3100 4000 14 53 47
71 170 186 25 2.4 P731_0070K102_0060 MB23 EZ501U 632 630 1561 42.00 42/1 8.0 8.0 3300 2800 4000 11 52 38
71 170 186 25 2.4 P731_0070K102_0060 MB23 EZ501U 632 630 1561 42.00 42/1 12 8.0 3300 2800 4000 11 52 38
71 186 205 27 2.2 P731_0070K102_0060 MB23 EZ402U 632 630 1561 42.00 42/1 8.0 8.0 3300 2800 4000 9.5 52 38
71 186 205 27 2.2 P731_0070K102_0060 MB23 EZ402U 632 630 1561 42.00 42/1 12 8.0 3300 2800 4000 9.5 52 38
71 273 340 40 1.5 P731_0070K102_0060 MB23 EZ404U 760 760 1561 42.00 42/1 8.0 8.0 3300 2800 4000 11 52 40
71 273 340 40 1.5 P731_0070K102_0060 MB23 EZ404U 760 760 1561 42.00 42/1 12 8.0 3300 2800 4000 11 52 40
71 292 316 43 1.4 P731_0070K102_0060 MB23 EZ502U 760 760 1561 42.00 42/1 8.0 8.0 3300 2800 4000 13 52 40
71 292 316 43 1.4 P731_0070K102_0060 MB23 EZ502U 760 760 1561 42.00 42/1 12 8.0 3300 2800 4000 13 52 40
71 170 186 20 2.6 P731_0050K202_0084 MB23 EZ501U 632 630 1610 41.99 12470/297 8.0 8.0 3500 3100 4000 11 53 46
71 170 186 20 2.6 P731_0050K202_0084 MB23 EZ501U 632 630 1610 41.99 12470/297 12 8.0 3500 3100 4000 11 53 46
71 186 205 21 2.4 P731_0050K202_0084 MB23 EZ402U 632 630 1610 41.99 12470/297 8.0 8.0 3500 3100 4000 9.8 53 46
71 186 205 21 2.4 P731_0050K202_0084 MB23 EZ402U 632 630 1610 41.99 12470/297 12 8.0 3500 3100 4000 9.8 53 46
71 273 340 31 1.6 P731_0050K202_0084 MB23 EZ404U 805 840 1610 41.99 12470/297 8.0 8.0 3500 3100 4000 11 53 48
71 273 340 31 1.6 P731_0050K202_0084 MB23 EZ404U 805 840 1610 41.99 12470/297 12 8.0 3500 3100 4000 11 53 48
71 292 316 34 1.5 P731_0050K202_0084 MB23 EZ502U 805 840 1610 41.99 12470/297 8.0 8.0 3500 3100 4000 13 53 47
71 292 316 34 1.5 P731_0050K202_0084 MB23 EZ502U 805 840 1610 41.99 12470/297 12 8.0 3500 3100 4000 13 53 47
77 158 172 25 2.5 P731_0070K102_0056 MB23 EZ501U 587 590 1561 38.98 1520/39 8.0 8.0 3300 2800 4000 11 52 38
77 158 172 25 2.5 P731_0070K102_0056 MB23 EZ501U 587 590 1561 38.98 1520/39 12 8.0 3300 2800 4000 11 52 38
77 172 191 27 2.3 P731_0070K102_0056 MB23 EZ402U 587 590 1561 38.98 1520/39 8.0 8.0 3300 2800 4000 9.7 52 38
77 172 191 27 2.3 P731_0070K102_0056 MB23 EZ402U 587 590 1561 38.98 1520/39 12 8.0 3300 2800 4000 9.7 52 38
77 253 315 40 1.5 P731_0070K102_0056 MB23 EZ404U 741 740 1561 38.98 1520/39 8.0 8.0 3300 2800 4000 11 52 40
77 253 315 40 1.5 P731_0070K102_0056 MB23 EZ404U 741 740 1561 38.98 1520/39 12 8.0 3300 2800 4000 11 52 40
77 271 293 43 1.4 P731_0070K102_0056 MB23 EZ502U 741 740 1561 38.98 1520/39 8.0 8.0 3300 2800 4000 13 52 40
77 271 293 43 1.4 P731_0070K102_0056 MB23 EZ502U 741 740 1561 38.98 1520/39 12 8.0 3300 2800 4000 13 52 40
90 135 148 18 3.3 P731_0050K202_0067 MB23 EZ501U 503 500 1610 33.42 11395/341 8.0 8.0 3500 3100 4000 11 53 46
90 135 148 18 3.3 P731_0050K202_0067 MB23 EZ501U 503 500 1610 33.42 11395/341 12 8.0 3500 3100 4000 11 53 46
