Also note the calculation for equivalent values:
× × + + × ×
=
× + + ×
3 3
2m,1* 1* 2k,acc,1* 2m,n* n* 2k,acc,n*
3
2k,eq*
2m,1* 1* 2m,n* n*
n t M ... n t M
M
n t ... n t
× × + + × ×
=
× + + ×
3 3
2m,1* 1* 2rad,acc,1* 2m,n* n* 2rad,acc,n*
3
2rad,eq*
2m,1* 1* 2m,n* n*
n t F ... n t F
F
n t ... n t
5.6.3 Radial shaft seal rings
Leak-proofness
Our gear units are equipped with high-quality radial shaft seal rings and checked for leaks. However, a leak
cannot be fully ruled out over the length of use of a gear unit. If you use a gear unit with goods incompatible
with the lubricant, you must take measures to prevent direct contact with the gear unit lubricant in case of a
leak.
5.6.4 Oil expansion tank
The gear units have a higher fill level in mounting position EL5. The oil expansion tank prevents oil from es-
caping out of the gear unit.
Notes
• We recommend using an oil expansion tank in mounting position EL5 (additional cost) for fast running
gear units with an input speed n
1
> 1750 rpm and gear ratios i < 20.
• It is not possible to use an oil expansion tank if the plug connector is at 90°!
5.7 Additional documentation
Additional documentation related to the product can be found at
http://www.stoeber.de/en/downloads/
Enter the ID of the documentation in the Search field.
Documentation ID
Operating manual for C/F/K/S gear units and gear motors 443027_en
Operating manual for MB23/MB33/MB43/MB53 ServoStop motor
adapters with brake
443287_en
