11.2.1 EZ motors with convection cooling
Type K
EM
n
N
M
N
I
N
K
M,N
P
N
M
0
I
0
K
M0
M
R
M
max
I
max
R
U-V
L
U-V
T
el
J
dyn
m
dyn
[V/1000 [rpm] [Nm] [A] [Nm/A] [kW] [Nm] [A] [Nm/A] [Nm] [Nm] [A] [Ω] [mH] [ms] [kgcm²] [kg]
rpm]
EZ202U 40 6000 0.40 0.99 0.41 0.25 0.44 1.03 0.45 0.03 1.48 3.48 26.00 15.80 0.61 0.13 1.43
EZ203U 40 6000 0.61 1.54 0.40 0.38 0.69 1.64 0.44 0.03 2.70 5.80 13.20 10.30 0.76 0.17 1.67
EZ301U 40 6000 0.89 1.93 0.46 0.56 0.95 2.02 0.49 0.04 2.80 12.7 11.70 39.80 3.40 0.19 1.50
EZ301U 40 3000 0.93 1.99 0.47 0.29 0.95 2.02 0.49 0.04 2.80 12.7 11.70 39.80 3.40 0.19 1.50
EZ302U 42 6000 1.50 3.18 0.47 0.94 1.68 3.48 0.49 0.04 5.00 17.8 4.50 18.70 4.16 0.29 2.10
EZ302U 86 3000 1.59 1.60 0.99 0.50 1.68 1.67 1.03 0.04 5.00 8.55 17.80 75.00 4.21 0.29 2.10
EZ303U 55 6000 1.96 3.17 0.62 1.2 2.25 3.55 0.65 0.04 7.00 16.9 4.90 21.10 4.31 0.40 2.60
EZ303U 109 3000 2.07 1.63 1.27 0.65 2.19 1.71 1.30 0.04 7.00 8.25 20.30 68.70 5.24 0.40 2.60
EZ401U 47 6000 2.30 4.56 0.50 1.4 2.80 5.36 0.53 0.04 8.50 33.0 1.94 11.52 5.94 0.93 4.00
EZ401U 96 3000 2.80 2.74 1.02 0.88 3.00 2.88 1.06 0.04 8.50 16.5 6.70 37.70 5.63 0.93 4.00
EZ402U 60 6000 3.50 5.65 0.62 2.2 4.90 7.43 0.66 0.04 16.0 43.5 1.20 8.88 7.40 1.63 5.10
EZ402U 94 3000 4.70 4.40 1.07 1.5 5.20 4.80 1.09 0.04 16.0 26.5 3.00 21.80 7.26 1.63 5.10
EZ404U 78 6000 5.80 7.18 0.81 3.6 8.40 9.78 0.86 0.04 29.0 51.0 0.89 7.07 7.94 2.98 7.20
EZ404U 116 3000 6.90 5.80 1.19 2.2 8.60 6.60 1.31 0.04 29.0 35.0 1.85 15.00 8.11 2.98 7.20
EZ501U 68 6000 3.40 4.77 0.71 2.1 4.40 5.80 0.77 0.06 16.0 31.0 2.10 12.10 5.76 2.90 5.00
EZ501U 97 3000 4.30 3.74 1.15 1.4 4.70 4.00 1.19 0.06 16.0 22.0 3.80 23.50 6.18 2.90 5.00
EZ502U 72 6000 5.20 7.35 0.71 3.3 7.80 9.80 0.80 0.06 31.0 59.0 0.76 5.60 7.37 5.20 6.50
EZ502U 121 3000 7.40 5.46 1.36 2.3 8.00 5.76 1.40 0.06 31.0 33.0 2.32 16.80 7.24 5.20 6.50
EZ503U 84 6000 6.20 7.64 0.81 3.9 10.6 11.6 0.92 0.06 43.0 63.5 0.62 5.00 8.06 7.58 8.00
EZ503U 119 3000 9.70 6.90 1.41 3.1 11.1 7.67 1.46 0.06 43.0 41.0 1.25 10.00 8.00 7.58 8.00
EZ505U 103 4500 9.50 8.94 1.06 4.5 15.3 13.4 1.15 0.06 67.0 73.0 0.50 4.47 8.94 12.2 10.9
EZ505U 141 3000 13.5 8.80 1.53 4.2 16.0 10.0 1.61 0.06 67.0 52.0 0.93 8.33 8.96 12.2 10.9
EZ701U 76 6000 5.20 6.68 0.78 3.3 7.90 9.38 0.87 0.24 20.0 31.0 0.87 8.13 9.34 8.50 8.30
EZ701U 95 3000 7.40 7.20 1.03 2.3 8.30 8.00 1.07 0.24 20.0 25.0 1.30 12.83 9.87 8.50 8.30
EZ702U 82 6000 7.20 8.96 0.80 4.5 14.3 16.5 0.88 0.24 41.0 60.5 0.34 3.90 11.47 13.7 10.8
EZ702U 133 3000 12.0 8.20 1.46 3.8 14.4 9.60 1.53 0.24 41.0 36.0 1.00 11.73 11.73 13.7 10.8
EZ703U 99 4500 12.1 11.5 1.05 5.7 20.0 17.8 1.14 0.24 65.0 78.0 0.36 4.42 12.28 21.6 12.8
EZ703U 122 3000 16.5 11.4 1.45 5.2 20.8 14.0 1.50 0.24 65.0 62.0 0.52 6.80 13.08 21.6 12.8
EZ705U 106 4500 16.4 14.8 1.11 7.7 30.0 25.2 1.20 0.24 104 114 0.22 2.76 12.55 34.0 18.3
EZ705U 140 3000 21.3 14.2 1.50 6.7 30.2 19.5 1.56 0.24 104 87.0 0.33 4.80 14.55 34.0 18.3
EZ802U 90 4500 10.5 11.2 0.94 5.0 34.5 33.3 1.05 0.30 100 135 0.13 1.90 14.60 58.0 26.6
EZ802U 136 3000 22.3 13.9 1.60 7.0 37.1 22.3 1.68 0.30 100 84.0 0.30 5.00 16.66 58.0 26.6
EZ803U 131 3000 26.6 17.7 1.50 8.4 48.2 31.1 1.56 0.30 145 124 0.18 2.79 15.50 83.5 32.7
EZ805U 142 2000 43.7 25.9 1.69 9.2 66.1 37.9 1.75 0.30 205 155 0.13 2.22 17.08 133 45.8
11.2 Selection tables 11 EZsynchronous servo motors
