Stober PK - EZ4 - EZ8 Motors with Forced Ventilation

11.4.6 EZ4 – EZ8 motors with forced ventilation
q3 Applies to motors without holding brake q4 Applies to motors with holding brake
1) Machine wall
Type
☐
a
∅
b1
c1 c3
∅
d
∅
e1
f1
☐
g1
l lfl
min
p1 p2 p4 p5 q3 q4
∅
s1
s2 w1 w2 z0 z5
EZ401B 98 95
j6
9.5 20.5 14
k6
115 3.5 118 30 20 40 32 37.5 0 175 224 9.0 M5 91.0 111 76.5 25
EZ402B 98 95
j6
9.5 20.5 19
k6
115 3.5 118 40 20 40 32 37.5 0 200 249 9.0 M6 91.0 111 101.5 25
EZ404B 98 95
j6
9.5 20.5 19
k6
115 3.5 118 40 20 40 32 37.5 0 250 299 9.0 M6 91.0 111 151.5 25
EZ501B 115 110
j6
10.0 16.0 19
k6
130 3.5 135 40 20 40 36 37.5 0 179 234 9.0 M6 100.0 120 74.5 25
EZ502B 115 110
j6
10.0 16.0 19
k6
130 3.5 135 40 20 40 36 37.5 0 204 259 9.0 M6 100.0 120 99.5 25
EZ503B 115 110
j6
10.0 16.0 24
k6
130 3.5 135 50 20 40 36 37.5 0 229 284 9.0 M8 100.0 120 124.5 25
EZ505B 115 110
j6
10.0 16.0 24
k6
130 3.5 135 50 20 40 36 37.5 0 279 334 9.0 M8 100.0 120 174.5 25
EZ701B 145 130
j6
10.0 19.0 24
k6
165 3.5 165 50 30 40 42 37.5 0 213 272 11.0 M8 115.0 134 83.0 40
EZ702B 145 130
j6
10.0 19.0 24
k6
165 3.5 165 50 30 40 42 37.5 0 238 297 11.0 M8 115.0 134 108.0 40
EZ703B 145 130
j6
10.0 19.0 24
k6
165 3.5 165 50 30 40 42 37.5 0 263 322 11.0 M8 115.0 134 133.0 40
EZ705B 145 130
j6
10.0 19.0 32
k6
165 3.5 165 58 30 71 42 37.5 0 318 377 11.0 M12 134.0 134 184.0 40
EZ802B 190 180
j6
15.0 25.0 32
k6
215 3.5 215 58 30 71 60 37.5 62 322 399 13.5 M12 156.5 160 168.0 40
EZ803B 190 180
j6
15.0 25.0 38
k6
215 3.5 215 80 30 71 60 37.5 62 363 440 13.5 M12 156.5 160 209.0 40
EZ805B 190 180
j6
15.0 25.0 38
k6
215 3.5 215 80 30 71 60 37.5 62 445 522 13.5 M12 156.5 160 277.0 40
11 EZsynchronous servo motors 11.4 Dimensional drawings
