Stober PK - EZ Motors with Forced Ventilation

11.2.2 EZ motors with forced ventilation
Type K
EM
n
N
M
N
I
N
K
M,N
P
N
M
0
I
0
K
M0
M
R
M
max
I
max
R
U-V
L
U-V
T
el
J
dyn
m
dyn
[V/1000 [rpm] [Nm] [A] [Nm/A] [kW] [Nm] [A] [Nm/A] [Nm] [Nm] [A] [Ω] [mH] [ms] [kgcm²] [kg]
rpm]
EZ401B 47 6000 2.90 5.62 0.52 1.8 3.50 6.83 0.52 0.04 8.50 33.0 1.94 11.52 5.94 0.93 5.40
EZ401B 96 3000 3.40 3.40 1.00 1.1 3.70 3.60 1.04 0.04 8.50 16.5 6.70 37.70 5.63 0.93 5.40
EZ402B 60 6000 5.10 7.88 0.65 3.2 6.40 9.34 0.69 0.04 16.0 43.5 1.20 8.88 7.40 1.63 6.50
EZ402B 94 3000 5.90 5.50 1.07 1.9 6.30 5.80 1.09 0.04 16.0 26.5 3.00 21.80 7.26 1.63 6.50
EZ404B 78 6000 8.00 9.98 0.80 5.0 10.5 12.0 0.88 0.04 29.0 51.0 0.89 7.07 7.94 2.98 8.60
EZ404B 116 3000 10.2 8.20 1.24 3.2 11.2 8.70 1.29 0.04 29.0 35.0 1.85 15.00 8.11 2.98 8.60
EZ501B 68 6000 4.50 6.70 0.67 2.8 5.70 7.50 0.77 0.06 16.0 31.0 2.10 12.10 5.76 2.90 7.00
EZ501B 97 3000 5.40 4.70 1.15 1.7 5.80 5.00 1.17 0.06 16.0 22.0 3.80 23.50 6.18 2.90 7.00
EZ502B 72 6000 8.20 11.4 0.72 5.2 10.5 13.4 0.79 0.06 31.0 59.0 0.76 5.60 7.37 5.20 8.50
EZ502B 121 3000 10.3 7.80 1.32 3.2 11.2 8.16 1.38 0.06 31.0 33.0 2.32 16.80 7.24 5.20 8.50
EZ503B 84 6000 10.4 13.5 0.77 6.5 14.8 15.9 1.07 0.06 43.0 63.5 0.62 5.00 8.06 7.58 10.0
EZ503B 119 3000 14.4 10.9 1.32 4.5 15.9 11.8 1.35 0.06 43.0 41.0 1.25 10.00 8.00 7.58 10.0
EZ505B 103 4500 16.4 16.4 1.00 7.7 22.0 19.4 1.14 0.06 67.0 73.0 0.50 4.47 8.94 12.2 12.9
EZ505B 141 3000 20.2 13.7 1.47 6.4 23.4 14.7 1.60 0.06 67.0 52.0 0.93 8.33 8.96 12.2 12.9
EZ701B 76 6000 7.50 10.6 0.71 4.7 10.2 12.4 0.84 0.24 20.0 31.0 0.87 8.13 9.34 8.50 11.2
EZ701B 95 3000 9.70 9.50 1.02 3.1 10.5 10.0 1.07 0.24 20.0 25.0 1.30 12.83 9.87 8.50 11.2
EZ702B 82 6000 12.5 16.7 0.75 7.9 19.3 22.1 0.89 0.24 41.0 60.5 0.34 3.90 11.47 13.7 13.7
EZ702B 133 3000 16.6 11.8 1.41 5.2 19.3 12.9 1.51 0.24 41.0 36.0 1.00 11.73 11.73 13.7 13.7
EZ703B 99 4500 19.8 20.3 0.98 9.3 27.2 24.2 1.13 0.24 65.0 78.0 0.36 4.42 12.28 21.6 15.7
EZ703B 122 3000 24.0 18.2 1.32 7.5 28.0 20.0 1.41 0.24 65.0 62.0 0.52 6.80 13.08 21.6 15.7
EZ705B 106 4500 27.7 25.4 1.09 13 39.4 32.8 1.21 0.24 104 114 0.22 2.76 12.55 34.0 21.2
EZ705B 140 3000 33.8 22.9 1.48 11 41.8 26.5 1.59 0.24 104 87.0 0.33 4.80 14.55 34.0 21.2
EZ802B 90 4500 30.6 30.5 1.00 14 47.4 45.1 1.06 0.30 100 135 0.13 1.90 14.60 58.0 31.6
EZ802B 136 3000 34.3 26.5 1.29 11 47.9 28.9 1.67 0.30 100 84.0 0.30 5.00 16.66 58.0 31.6
EZ803B 131 3000 49.0 35.9 1.37 15 66.7 42.3 1.58 0.30 145 124 0.18 2.79 15.50 83.5 37.7
EZ805B 142 2000 77.2 45.2 1.71 16 94.0 53.9 1.75 0.30 205 155 0.13 2.22 17.08 133 51.8
11 EZsynchronous servo motors 11.2 Selection tables
379
