11.4.2 EZ2 – EZ3 motors
q0 Applies to motors without holding brake q1 Applies to motors with holding brake
x0 EZ2: Applies only to motors with holding brake and en-
coders using an optical or inductive measuring method
EZ3 − EZ8: Applies to encoders using an optical measuring
method
Type
☐
a
∅
b1
c1 c3
∅
d
∅
e1
f1
☐
g
l p1 p2 q0 q1
∅
s1
s2 w1 x0 z0
EZ202U 55 40
j6
7 7 9
k6
63 3.5 55 20 45 19 148 157 5.8 M4 47.0 25 93.0
EZ203U 55 40
j6
7 7 9
k6
63 3.5 55 20 45 19 166 175 5.8 M4 47.0 25 111.0
EZ301U 72 60
j6
7 26 14
k6
75 3.0 72 30 45 19 116 156 6.0 M5 55.5 21 80.5
EZ302U 72 60
j6
7 26 14
k6
75 3.0 72 30 45 19 138 178 6.0 M5 55.5 21 102.5
EZ303U 72 60
j6
7 26 14
k6
75 3.0 72 30 45 19 160 200 6.0 M5 55.5 21 124.5
11 EZsynchronous servo motors 11.4 Dimensional drawings
