6.2 Selection tables
The technical data specified in the selection tables applies to:
• Installation altitudes up to 1000m above sea level
• Surrounding temperatures from 0°C to 40°C
• Drives with convection-cooled motors (e.g. EZ401U)
• Weight specification for mounting position EL1, housing design G
• Without consideration of the thermal limiting performance
For the technical data on drives with forced ventilated motors (e.g. EZ401B), refer to
https://configurator.stoeber.de/en-US/
.
An explanation of the formula symbols can be found in the chapter [}15.1].
n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
F1 (n
1N
= 3000 rpm, M
2acc,max
= 100 Nm)
464 27 29 3.4 2.3 F102_0065 MB23 EZ501U 100 200 6.462 84/13 8.0 8.0 3500 3000 4000 11 6.5 28
464 29 33 3.7 2.1 F102_0065 MB23 EZ402U 100 200 6.462 84/13 8.0 8.0 3500 3000 4000 9.8 6.5 27
696 18 20 3.2 3.0 F102_0043 MB23 EZ501U 67 200 4.308 56/13 8.0 8.0 3500 3000 4000 12 6.5 28
696 18 20 3.2 3.0 F102_0043 MB23 EZ501U 67 200 4.308 56/13 12 8.0 3500 3000 4000 12 6.5 28
696 18 20 3.2 3.0 F102_0043 MB23 EZ501U 67 200 4.308 56/13 16 8.0 3500 3000 4000 12 6.5 28
696 20 22 3.5 2.8 F102_0043 MB23 EZ402U 67 200 4.308 56/13 8.0 8.0 3500 3000 4000 11 6.5 27
696 20 22 3.5 2.8 F102_0043 MB23 EZ402U 67 200 4.308 56/13 12 8.0 3500 3000 4000 11 6.5 27
696 20 22 3.5 2.8 F102_0043 MB23 EZ402U 67 200 4.308 56/13 16 8.0 3500 3000 4000 11 6.5 27
696 29 36 5.1 1.9 F102_0043 MB23 EZ404U 103 200 4.308 56/13 8.0 8.0 3500 3000 4000 12 6.5 30
696 29 36 5.1 1.9 F102_0043 MB23 EZ404U 103 200 4.308 56/13 12 8.0 3500 3000 4000 12 6.5 30
696 29 36 5.1 1.9 F102_0043 MB23 EZ404U 103 200 4.308 56/13 16 8.0 3500 3000 4000 12 6.5 30
696 31 33 5.5 1.8 F102_0043 MB23 EZ502U 103 200 4.308 56/13 8.0 8.0 3500 3000 4000 14 6.5 29
696 31 33 5.5 1.8 F102_0043 MB23 EZ502U 103 200 4.308 56/13 12 8.0 3500 3000 4000 14 6.5 29
696 31 33 5.5 1.8 F102_0043 MB23 EZ502U 103 200 4.308 56/13 16 8.0 3500 3000 4000 14 6.5 29
F2 (n
1N
= 3000 rpm, M
2acc,max
= 210 Nm)
220 57 62 2.1 2.8 F202_0135 MB23 EZ501U 210 400 13.63 109/8 8.0 8.0 3800 3500 4000 11 16 36
220 62 69 2.3 2.6 F202_0135 MB23 EZ402U 210 400 13.63 109/8 8.0 8.0 3800 3500 4000 9.6 16 36
220 91 114 3.4 1.7 F202_0135 MB23 EZ404U 210 400 13.63 109/8 8.0 8.0 3800 3500 4000 11 16 38
220 98 106 3.7 1.6 F202_0135 MB23 EZ502U 210 400 13.63 109/8 8.0 8.0 3800 3500 4000 13 16 37
278 45 49 2.0 3.3 F202_0110 MB23 EZ501U 168 400 10.80 7303/676 8.0 8.0 3800 3500 4000 11 16 36
278 45 49 2.0 3.3 F202_0110 MB23 EZ501U 168 400 10.80 7303/676 12 8.0 3800 3500 4000 11 16 36
278 49 54 2.2 3.0 F202_0110 MB23 EZ402U 168 400 10.80 7303/676 8.0 8.0 3800 3500 4000 9.9 16 36
278 49 54 2.2 3.0 F202_0110 MB23 EZ402U 168 400 10.80 7303/676 12 8.0 3800 3500 4000 9.9 16 36
278 72 90 3.3 2.0 F202_0110 MB23 EZ404U 210 400 10.80 7303/676 8.0 8.0 3800 3500 4000 11 16 38
278 72 90 3.3 2.0 F202_0110 MB23 EZ404U 210 400 10.80 7303/676 12 8.0 3800 3500 4000 11 16 38
278 78 84 3.5 1.9 F202_0110 MB23 EZ502U 210 400 10.80 7303/676 8.0 8.0 3800 3500 4000 14 16 37
278 78 84 3.5 1.9 F202_0110 MB23 EZ502U 210 400 10.80 7303/676 12 8.0 3800 3500 4000 14 16 37
333 38 41 2.0 3.7 F202_0090 MB23 EZ501U 140 400 9.006 3161/351 8.0 8.0 3600 3100 4000 12 16 36
333 38 41 2.0 3.7 F202_0090 MB23 EZ501U 140 400 9.006 3161/351 12 8.0 3600 3100 4000 12 16 36
333 38 41 2.0 3.7 F202_0090 MB23 EZ501U 140 400 9.006 3161/351 16 8.0 3600 3100 4000 12 16 36
333 41 45 2.2 3.4 F202_0090 MB23 EZ402U 140 400 9.006 3161/351 8.0 8.0 3600 3100 4000 10 16 36
333 41 45 2.2 3.4 F202_0090 MB23 EZ402U 140 400 9.006 3161/351 12 8.0 3600 3100 4000 10 16 36
333 41 45 2.2 3.4 F202_0090 MB23 EZ402U 140 400 9.006 3161/351 16 8.0 3600 3100 4000 10 16 36
333 60 75 3.2 2.3 F202_0090 MB23 EZ404U 210 400 9.006 3161/351 8.0 8.0 3600 3100 4000 12 16 38
333 60 75 3.2 2.3 F202_0090 MB23 EZ404U 210 400 9.006 3161/351 12 8.0 3600 3100 4000 12 16 38
333 60 75 3.2 2.3 F202_0090 MB23 EZ404U 210 400 9.006 3161/351 16 8.0 3600 3100 4000 12 16 38
333 65 70 3.4 2.1 F202_0090 MB23 EZ502U 210 400 9.006 3161/351 8.0 8.0 3600 3100 4000 14 16 37
333 65 70 3.4 2.1 F202_0090 MB23 EZ502U 210 400 9.006 3161/351 12 8.0 3600 3100 4000 14 16 37
333 65 70 3.4 2.1 F202_0090 MB23 EZ502U 210 400 9.006 3161/351 16 8.0 3600 3100 4000 14 16 37
333 85 97 4.5 1.6 F202_0090 MB23 EZ503U 210 400 9.006 3161/351 8.0 15 3600 3100 4000 17 16 39
419 30 33 1.9 4.3 F202_0072 MB23 EZ501U 111 400 7.167 5777/806 8.0 8.0 3600 3100 4000 12 16 36
419 30 33 1.9 4.3 F202_0072 MB23 EZ501U 111 400 7.167 5777/806 12 8.0 3600 3100 4000 12 16 36
419 30 33 1.9 4.3 F202_0072 MB23 EZ501U 111 400 7.167 5777/806 16 8.0 3600 3100 4000 12 16 36
419 33 36 2.1 3.9 F202_0072 MB23 EZ402U 111 400 7.167 5777/806 8.0 8.0 3600 3100 4000 11 16 36
419 33 36 2.1 3.9 F202_0072 MB23 EZ402U 111 400 7.167 5777/806 12 8.0 3600 3100 4000 11 16 36
419 33 36 2.1 3.9 F202_0072 MB23 EZ402U 111 400 7.167 5777/806 16 8.0 3600 3100 4000 11 16 36
419 48 60 3.1 2.7 F202_0072 MB23 EZ404U 202 400 7.167 5777/806 8.0 8.0 3600 3100 4000 12 16 38
419 48 60 3.1 2.7 F202_0072 MB23 EZ404U 202 400 7.167 5777/806 12 8.0 3600 3100 4000 12 16 38
419 48 60 3.1 2.7 F202_0072 MB23 EZ404U 202 400 7.167 5777/806 16 8.0 3600 3100 4000 12 16 38
6 Foffset helical geared motors 6.2 Selection tables
