11.4.3 EZ4 – EZ7 motors with convection cooling (One Cable Solution)
q0 Applies to motors without holding brake q1 Applies to motors with holding brake
Type
☐
a
∅
b1
c1 c3
∅
d
∅
e1
f1
☐
g
l p1 q0 q1
∅
s1
s2 w1 z0
EZ401U 98 95
j6
9.5 20.5 14
k6
115 3.5 98 30 40 118.5 167.0 9 M5 99 76.5
EZ402U 98 95
j6
9.5 20.5 19
k6
115 3.5 98 40 40 143.5 192.0 9 M6 99 101.5
EZ404U 98 95
j6
9.5 20.5 19
k6
115 3.5 98 40 40 193.5 242.0 9 M6 99 151.5
EZ501U 115 110
j6
10.0 16.0 19
k6
130 3.5 115 40 40 109.0 163.5 9 M6 110 74.5
EZ502U 115 110
j6
10.0 16.0 19
k6
130 3.5 115 40 40 134.0 188.5 9 M6 110 99.5
EZ503U 115 110
j6
10.0 16.0 24
k6
130 3.5 115 50 40 159.0 213.5 9 M8 110 124.5
EZ505U 115 110
j6
10.0 16.0 24
k6
130 3.5 115 50 40 209.0 263.5 9 M8 110 174.5
EZ701U 145 130
j6
10.0 19.0 24
k6
165 3.5 145 50 40 121.0 180.0 11 M8 125 83.0
EZ702U 145 130
j6
10.0 19.0 24
k6
165 3.5 145 50 40 146.0 205.0 11 M8 125 108.0
EZ703U 145 130
j6
10.0 19.0 24
k6
165 3.5 145 50 40 171.0 230.0 11 M8 125 133.0
EZ705U 145 130
j6
10.0 19.0 32
k6
165 3.5 145 58 40 226.0 285.0 11 M12 125 184.0
11.4 Dimensional drawings 11 EZsynchronous servo motors
