7.4 Type designation
This chapter shows you an explanation of the type designation with the associated options.
Additional ordering information not included in the type designation can be found at the end of the chapter.
Example code
P 5 3 1 S G S S 0050 K102VF 0040 MB23 EZ501U
Explanation
Code Designation Design
P Type Planetary gear unit
5 Size 5 (example)
3 Generation Generation 3
1 Stages Single-stage
S Housing Standard
G
P
Shaft Solid shaft without feather key
Solid shaft with feather key
S
D
Z
Bearing Standard bearing
Axially reinforced bearing (P3 – P9)
Radially reinforced bearing (P3 – P9)
1
S
R
Backlash Standard
Reduced
0050 Transmission ratio of output
(i x 10)
i = 5 (example)
K102VF Input K1 right-angle geared motor (example)
0040 Transmission ratio of input
(i x 10)
i = 4 (example)
MB Motor adapter ServoStop motor adapter with brake
2 Size 2 (example)
3 Generation Generation 3
EZ501U Motor EZ synchronous servo motor
To complete the type designation, also specify the following in your order:
• A detailed type designation of the motor, see the chapter [}11]
• Mounting position, see the chapter [}4.5.4]
• Output gear unit side3 or 4, see the chapter [}4.5.4]
• Radial shaft seal rings at the output made of NBR or FKM (option), see the chapter [}7.6.3]
• Position of the plug connectors, see the chapter [}7.5.6]
• For reverse operation of the output shaft from ±20° to ±90° and horizontal installation, note the chap-
ter [}7.6.4]
7.4.1 Nameplate
An example gear unit nameplate is explained in the figure below.
1
2
5 76
8 9
3
4
K913AF0320MB43EZ805U
i=32,12 21/34
Oil: CLP 220 Volume=21,0 l
SN: 10080005 CD: 48283012345
STÖBER Antriebstechnik GmbH + Co. KG
Kieselbronner Str. 12, 75177 Pforzheim, DE
Made in Germany
1
Not for reduced-backlash option.
