Stober PK - Page 205

Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
P531_K102_ ∅160 128 36.0 ∅160 128 36.0 – – – – – –
P731_K102_ ∅160 128 36.0 ∅160 128 36.0 – – – – – –
P731_K202_ ∅160 147 46.0 ∅160 147 46.0 ∅200 149 46.0 – – –
P831_K202_ ∅160 147 46.0 ∅160 147 46.0 ∅200 149 46.0 – – –
P831_K302_ ∅160 167 52.5 ∅160 167 52.5 ∅200 169 52.5 – – –
P931_K402_ ∅160 187 60.0 ∅160 187 60.0 ∅200 189 60.0 ∅250 192 60.0
7 PKright-angle planetary geared motors 7.3 Dimensional drawings
205
