Stober PK - Selection Tables

8.2 Selection tables
The technical data specified in the selection tables applies to:
• Installation altitudes up to 1000m above sea level
• Surrounding temperatures from 0°C to 40°C
• Drives with convection-cooled motors (e.g. EZ401U)
• Without consideration of the thermal limiting performance
For the technical data on drives with forced ventilated motors (e.g. EZ401B), refer to
https://configurator.stoeber.de/en-US/
An explanation of the formula symbols can be found in the chapter [}15.1].
n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH531K (n
1N
= 3000 rpm, M
2acc,max
= 390 Nm)
150 80 88 29 2.7 PH531_0050K102_0040 MB23 EZ501U 298 300 705 20.00 20/1 8.0 8.0 3300 2800 4000 11 62 32
150 88 97 32 2.5 PH531_0050K102_0040 MB23 EZ402U 298 300 705 20.00 20/1 8.0 8.0 3300 2800 4000 9.9 62 32
150 129 160 46 1.7 PH531_0050K102_0040 MB23 EZ404U 385 400 705 20.00 20/1 8.0 8.0 3300 2800 4000 11 62 34
150 138 149 50 1.6 PH531_0050K102_0040 MB23 EZ502U 385 400 705 20.00 20/1 8.0 8.0 3300 2800 4000 14 62 33
188 64 70 26 3.1 PH531_0040K102_0040 MB23 EZ501U 238 240 696 16.00 16/1 8.0 8.0 3300 2800 4000 11 52 32
188 64 70 26 3.1 PH531_0040K102_0040 MB23 EZ501U 238 240 696 16.00 16/1 12 8.0 3300 2800 4000 11 52 32
188 64 70 26 3.1 PH531_0040K102_0040 MB23 EZ501U 238 240 696 16.00 16/1 16 8.0 3300 2800 4000 11 52 32
188 70 77 28 2.8 PH531_0040K102_0040 MB23 EZ402U 238 240 696 16.00 16/1 8.0 8.0 3300 2800 4000 10 52 32
188 70 77 28 2.8 PH531_0040K102_0040 MB23 EZ402U 238 240 696 16.00 16/1 12 8.0 3300 2800 4000 10 52 32
188 70 77 28 2.8 PH531_0040K102_0040 MB23 EZ402U 238 240 696 16.00 16/1 16 8.0 3300 2800 4000 10 52 32
188 103 128 41 1.9 PH531_0040K102_0040 MB23 EZ404U 355 380 696 16.00 16/1 8.0 8.0 3300 2800 4000 11 52 34
188 103 128 41 1.9 PH531_0040K102_0040 MB23 EZ404U 355 380 696 16.00 16/1 12 8.0 3300 2800 4000 11 52 34
188 103 128 41 1.9 PH531_0040K102_0040 MB23 EZ404U 355 380 696 16.00 16/1 16 8.0 3300 2800 4000 11 52 34
188 110 119 44 1.8 PH531_0040K102_0040 MB23 EZ502U 355 380 696 16.00 16/1 8.0 8.0 3300 2800 4000 14 52 33
188 110 119 44 1.8 PH531_0040K102_0040 MB23 EZ502U 355 380 696 16.00 16/1 12 8.0 3300 2800 4000 14 52 33
188 110 119 44 1.8 PH531_0040K102_0040 MB23 EZ502U 355 380 696 16.00 16/1 16 8.0 3300 2800 4000 14 52 33
188 145 165 58 1.4 PH531_0040K102_0040 MB23 EZ503U 355 380 696 16.00 16/1 8.0 15 3300 2800 4000 17 52 35
PH731K (n
1N
= 3000 rpm, M
2acc,max
= 880 Nm)
65 186 204 25 2.2 PH731_0070K102_0066 MB23 EZ501U 693 690 1545 46.51 2093/45 8.0 8.0 3600 3300 4000 11 111 37
65 204 225 27 2.0 PH731_0070K102_0066 MB23 EZ402U 693 690 1545 46.51 2093/45 8.0 8.0 3600 3300 4000 9.4 111 37
65 299 372 39 1.4 PH731_0070K102_0066 MB23 EZ404U 778 780 1545 46.51 2093/45 8.0 8.0 3600 3300 4000 11 111 39
65 320 346 42 1.3 PH731_0070K102_0066 MB23 EZ502U 778 780 1545 46.51 2093/45 8.0 8.0 3600 3300 4000 13 111 39
65 184 201 20 2.4 PH731_0050K202_0092 MB23 EZ501U 685 680 1720 45.95 11395/248 8.0 8.0 3500 3100 4000 11 117 45
65 184 201 20 2.4 PH731_0050K202_0092 MB23 EZ501U 685 680 1720 45.95 11395/248 12 8.0 3500 3100 4000 11 117 45
65 201 223 22 2.2 PH731_0050K202_0092 MB23 EZ402U 685 680 1720 45.95 11395/248 8.0 8.0 3500 3100 4000 10 117 45
65 201 223 22 2.2 PH731_0050K202_0092 MB23 EZ402U 685 680 1720 45.95 11395/248 12 8.0 3500 3100 4000 10 117 45
65 295 368 32 1.5 PH731_0050K202_0092 MB23 EZ404U 882 920 1720 45.95 11395/248 8.0 8.0 3500 3100 4000 11 117 47
65 295 368 32 1.5 PH731_0050K202_0092 MB23 EZ404U 882 920 1720 45.95 11395/248 12 8.0 3500 3100 4000 11 117 47
65 317 342 34 1.4 PH731_0050K202_0092 MB23 EZ502U 882 920 1720 45.95 11395/248 8.0 8.0 3500 3100 4000 14 117 46
65 317 342 34 1.4 PH731_0050K202_0092 MB23 EZ502U 882 920 1720 45.95 11395/248 12 8.0 3500 3100 4000 14 117 46
71 168 184 25 2.4 PH731_0070K102_0060 MB23 EZ501U 626 630 1545 42.00 42/1 8.0 8.0 3300 2800 4000 11 111 37
71 168 184 25 2.4 PH731_0070K102_0060 MB23 EZ501U 626 630 1545 42.00 42/1 12 8.0 3300 2800 4000 11 111 37
71 184 203 27 2.2 PH731_0070K102_0060 MB23 EZ402U 626 630 1545 42.00 42/1 8.0 8.0 3300 2800 4000 9.5 111 37
71 184 203 27 2.2 PH731_0070K102_0060 MB23 EZ402U 626 630 1545 42.00 42/1 12 8.0 3300 2800 4000 9.5 111 37
71 270 336 40 1.5 PH731_0070K102_0060 MB23 EZ404U 752 750 1545 42.00 42/1 8.0 8.0 3300 2800 4000 11 111 39
71 270 336 40 1.5 PH731_0070K102_0060 MB23 EZ404U 752 750 1545 42.00 42/1 12 8.0 3300 2800 4000 11 111 39
71 289 313 43 1.4 PH731_0070K102_0060 MB23 EZ502U 752 750 1545 42.00 42/1 8.0 8.0 3300 2800 4000 13 111 39
71 289 313 43 1.4 PH731_0070K102_0060 MB23 EZ502U 752 750 1545 42.00 42/1 12 8.0 3300 2800 4000 13 111 39
71 168 184 19 2.6 PH731_0050K202_0084 MB23 EZ501U 626 630 1720 41.99 12470/297 8.0 8.0 3500 3100 4000 11 117 45
71 168 184 19 2.6 PH731_0050K202_0084 MB23 EZ501U 626 630 1720 41.99 12470/297 12 8.0 3500 3100 4000 11 117 45
71 184 203 21 2.4 PH731_0050K202_0084 MB23 EZ402U 626 630 1720 41.99 12470/297 8.0 8.0 3500 3100 4000 9.8 117 45
71 184 203 21 2.4 PH731_0050K202_0084 MB23 EZ402U 626 630 1720 41.99 12470/297 12 8.0 3500 3100 4000 9.8 117 45
71 270 336 31 1.6 PH731_0050K202_0084 MB23 EZ404U 882 920 1720 41.99 12470/297 8.0 8.0 3500 3100 4000 11 117 47
71 270 336 31 1.6 PH731_0050K202_0084 MB23 EZ404U 882 920 1720 41.99 12470/297 12 8.0 3500 3100 4000 11 117 47
71 289 313 33 1.5 PH731_0050K202_0084 MB23 EZ502U 882 920 1720 41.99 12470/297 8.0 8.0 3500 3100 4000 13 117 46
71 289 313 33 1.5 PH731_0050K202_0084 MB23 EZ502U 882 920 1720 41.99 12470/297 12 8.0 3500 3100 4000 13 117 46
77 156 171 25 2.5 PH731_0070K102_0056 MB23 EZ501U 581 580 1545 38.98 1520/39 8.0 8.0 3300 2800 4000 11 111 37
77 156 171 25 2.5 PH731_0070K102_0056 MB23 EZ501U 581 580 1545 38.98 1520/39 12 8.0 3300 2800 4000 11 111 37
77 171 189 27 2.3 PH731_0070K102_0056 MB23 EZ402U 581 580 1545 38.98 1520/39 8.0 8.0 3300 2800 4000 9.7 111 37
77 171 189 27 2.3 PH731_0070K102_0056 MB23 EZ402U 581 580 1545 38.98 1520/39 12 8.0 3300 2800 4000 9.7 111 37
77 250 312 40 1.5 PH731_0070K102_0056 MB23 EZ404U 733 730 1545 38.98 1520/39 8.0 8.0 3300 2800 4000 11 111 39
