13.6 Connection to Beckhoff drive controllers
This chapter contains the information for connecting STOBER synchronous servo motors to drive controllers
of the above-named manufacturer which differs from connecting to STOBER drive controllers. You can find
all other information about STOBER synchronous servo motors in the respective chapter of this catalog.
STOBER has taken the following measures to minimize the effort of commissioning STOBER motors con-
nected to AX5000 drive controllers and avoiding errors during parameterization:
• The commutation offset of the motor was set so that calibration by the customer is not necessary.
• The electronic nameplate of the motor was designed to be compatible with the AX5000.
• Parameter files for all supported motor versions are available for download.
More information on commissioning EZ motors connected to Beckhoff AX5000 drive controllers can be
found in the 443185_en document in the download area on the STOBER website.
13.6.1 Encoders
Encoders with EnDat 2.1 interface
Encoder model Code Mea-
suring
metho
d
Recordable
revolutions
Resolu-
tion
Position val-
ues per revo-
lution
Periods per
revolution
MTTF
[years]
PHF [h]
EnDat 2.1 ECI 119 C4 Induc-
tive
– 19 bit 524288 Sin/cos 32 > 57 ≤2×10
-6
EnDat 2.1 EQN
1125 FMA
M2 Optical 4096 13 bit 8192 Sin/cos 512 > 57 ≤2×10
-6
EnDat 2.1 EQN
1125
Q4 Optical 4096 13 bit 8192 Sin/cos 512 > 57 ≤2×10
-6
EnDat 2.1 ECN
1113 FMA
M0 Optical – 13 bit 8192 Sin/cos 512 > 57 ≤2×10
-6
EnDat 2.1 ECN
1113
C6 Optical – 13 bit 8192 Sin/cos 512 > 57 ≤2×10
-6
Notes
• The encoder code is a part of the type designation of the motor.
• FMA = Version with fault exclusion for mechanical coupling.
• Multiple revolutions of the motor shaft can be recorded only using multi-turn encoders.
13.6.2 Possible combinations with drive controllers
The following table shows the possible combinations of STOBER synchronous servo motors with drive con-
trollers from Beckhoff depending on the encoder model.
Drive controller AX5000
Drive controller code FM
Connection plan ID 442318
Encoder Encoder code
EnDat 2.1 ECI 119 C4 EZHD, EZM
EnDat 2.1 EQN 1125 FMA M2 EZ, EZS
EnDat 2.1 EQN 1125 Q4 EZ, EZS
EnDat 2.1 ECN 1113 FMA M0 EZ, EZS
EnDat 2.1 ECN 1113 C6 EZ, EZS
The encoder and drive controller codes are a part of the type designation of the motor.
