10.2 Selection tables
The technical data specified in the selection tables applies to:
• Installation altitudes up to 1000m above sea level
• Surrounding temperatures from 0°C to 40°C
• Drives with convection-cooled motors (e.g. EZ401U)
• Weight specification for mounting position EL1, housing design G
• Without consideration of the thermal limiting performance
For the technical data on drives with forced ventilated motors (e.g. EZ401B), refer to
https://configurator.stoeber.de/en-US/
.
An explanation of the formula symbols can be found in the chapter [}15.1].
n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K1 (n
1N
= 3000 rpm, M
2acc,max
= 110 Nm)
452 28 30 25 2.2 K102_0066 MB23 EZ501U 103 220 6.644 299/45 8.0 8.0 3600 3300 4000 11 6.8 26
452 30 34 27 2.0 K102_0066 MB23 EZ402U 103 220 6.644 299/45 8.0 8.0 3600 3300 4000 9.4 6.8 26
500 25 27 25 2.4 K102_0060 MB23 EZ501U 93 220 6.000 6/1 8.0 8.0 3300 2800 4000 11 6.8 26
500 25 27 25 2.4 K102_0060 MB23 EZ501U 93 220 6.000 6/1 12 8.0 3300 2800 4000 11 6.8 26
500 27 30 27 2.2 K102_0060 MB23 EZ402U 93 220 6.000 6/1 8.0 8.0 3300 2800 4000 9.5 6.8 26
500 27 30 27 2.2 K102_0060 MB23 EZ402U 93 220 6.000 6/1 12 8.0 3300 2800 4000 9.5 6.8 26
539 23 25 25 2.5 K102_0056 MB23 EZ501U 86 240 5.568 1520/273 8.0 8.0 3300 2800 4000 11 6.8 26
539 23 25 25 2.5 K102_0056 MB23 EZ501U 86 240 5.568 1520/273 12 8.0 3300 2800 4000 11 6.8 26
539 23 25 25 2.5 K102_0056 MB23 EZ501U 86 240 5.568 1520/273 16 8.0 3300 2800 4000 11 6.8 26
539 25 28 27 2.3 K102_0056 MB23 EZ402U 86 240 5.568 1520/273 8.0 8.0 3300 2800 4000 9.7 6.8 26
539 25 28 27 2.3 K102_0056 MB23 EZ402U 86 240 5.568 1520/273 12 8.0 3300 2800 4000 9.7 6.8 26
539 25 28 27 2.3 K102_0056 MB23 EZ402U 86 240 5.568 1520/273 16 8.0 3300 2800 4000 9.7 6.8 26
539 37 46 40 1.5 K102_0056 MB23 EZ404U 109 240 5.568 1520/273 8.0 8.0 3300 2800 4000 11 6.8 28
539 37 46 40 1.5 K102_0056 MB23 EZ404U 109 240 5.568 1520/273 12 8.0 3300 2800 4000 11 6.8 28
539 37 46 40 1.5 K102_0056 MB23 EZ404U 109 240 5.568 1520/273 16 8.0 3300 2800 4000 11 6.8 28
750 17 18 26 3.1 K102_0040 MB23 EZ501U 62 220 4.000 4/1 8.0 8.0 3300 2800 4000 11 6.8 26
750 17 18 26 3.1 K102_0040 MB23 EZ501U 62 220 4.000 4/1 12 8.0 3300 2800 4000 11 6.8 26
750 17 18 26 3.1 K102_0040 MB23 EZ501U 62 220 4.000 4/1 16 8.0 3300 2800 4000 11 6.8 26
750 18 20 28 2.8 K102_0040 MB23 EZ402U 62 220 4.000 4/1 8.0 8.0 3300 2800 4000 9.9 6.8 26
750 18 20 28 2.8 K102_0040 MB23 EZ402U 62 220 4.000 4/1 12 8.0 3300 2800 4000 9.9 6.8 26
750 18 20 28 2.8 K102_0040 MB23 EZ402U 62 220 4.000 4/1 16 8.0 3300 2800 4000 9.9 6.8 26
750 27 33 41 1.9 K102_0040 MB23 EZ404U 98 220 4.000 4/1 8.0 8.0 3300 2800 4000 11 6.8 28
750 27 33 41 1.9 K102_0040 MB23 EZ404U 98 220 4.000 4/1 12 8.0 3300 2800 4000 11 6.8 28
750 27 33 41 1.9 K102_0040 MB23 EZ404U 98 220 4.000 4/1 16 8.0 3300 2800 4000 11 6.8 28
750 29 31 44 1.8 K102_0040 MB23 EZ502U 98 220 4.000 4/1 8.0 8.0 3300 2800 4000 13 6.8 28
750 29 31 44 1.8 K102_0040 MB23 EZ502U 98 220 4.000 4/1 12 8.0 3300 2800 4000 13 6.8 28
750 29 31 44 1.8 K102_0040 MB23 EZ502U 98 220 4.000 4/1 16 8.0 3300 2800 4000 13 6.8 28
K2 (n
1N
= 3000 rpm, M
2acc,max
= 220 Nm)
217 58 63 14 2.4 K202_0140 MB23 EZ501U 215 400 13.85 2881/208 8.0 8.0 3900 3500 4000 11 11 34
217 63 70 16 2.2 K202_0140 MB23 EZ402U 215 400 13.85 2881/208 8.0 8.0 3900 3500 4000 9.5 11 33
217 93 116 23 1.5 K202_0140 MB23 EZ404U 220 400 13.85 2881/208 8.0 8.0 3900 3500 4000 11 11 36
236 53 58 15 2.6 K202_0125 MB23 EZ501U 197 400 12.71 559/44 8.0 8.0 3900 3500 4000 11 11 34
236 58 64 16 2.3 K202_0125 MB23 EZ402U 197 400 12.71 559/44 8.0 8.0 3900 3500 4000 9.4 11 33
236 85 106 23 1.6 K202_0125 MB23 EZ404U 220 400 12.71 559/44 8.0 8.0 3900 3500 4000 11 11 36
260 48 53 15 2.7 K202_0115 MB23 EZ501U 179 400 11.55 1247/108 8.0 8.0 3500 3100 4000 11 11 34
260 53 58 16 2.5 K202_0115 MB23 EZ402U 179 400 11.55 1247/108 8.0 8.0 3500 3100 4000 9.7 11 33
260 77 96 23 1.7 K202_0115 MB23 EZ404U 220 400 11.55 1247/108 8.0 8.0 3500 3100 4000 11 11 36
260 83 90 25 1.6 K202_0115 MB23 EZ502U 220 400 11.55 1247/108 8.0 8.0 3500 3100 4000 13 11 35
298 42 46 15 3.0 K202_0100 MB23 EZ501U 156 400 10.07 2881/286 8.0 8.0 3900 3500 4000 11 11 34
298 42 46 15 3.0 K202_0100 MB23 EZ501U 156 400 10.07 2881/286 12 8.0 3900 3500 4000 11 11 34
298 46 51 16 2.7 K202_0100 MB23 EZ402U 156 400 10.07 2881/286 8.0 8.0 3900 3500 4000 9.6 11 33
298 46 51 16 2.7 K202_0100 MB23 EZ402U 156 400 10.07 2881/286 12 8.0 3900 3500 4000 9.6 11 33
298 67 84 24 1.9 K202_0100 MB23 EZ404U 220 400 10.07 2881/286 8.0 8.0 3900 3500 4000 11 11 36
298 67 84 24 1.9 K202_0100 MB23 EZ404U 220 400 10.07 2881/286 12 8.0 3900 3500 4000 11 11 36
298 72 78 25 1.7 K202_0100 MB23 EZ502U 220 400 10.07 2881/286 8.0 8.0 3900 3500 4000 13 11 35
298 72 78 25 1.7 K202_0100 MB23 EZ502U 220 400 10.07 2881/286 12 8.0 3900 3500 4000 13 11 35
326 38 42 15 3.2 K202_0092 MB23 EZ501U 143 400 9.190 2279/248 8.0 8.0 3500 3100 4000 11 11 34
326 38 42 15 3.2 K202_0092 MB23 EZ501U 143 400 9.190 2279/248 12 8.0 3500 3100 4000 11 11 34
326 38 42 15 3.2 K202_0092 MB23 EZ501U 143 400 9.190 2279/248 16 8.0 3500 3100 4000 11 11 34
