5.2 Selection tables
The technical data specified in the selection tables applies to:
• Installation altitudes up to 1000m above sea level
• Surrounding temperatures from 0°C to 40°C
• Drives with convection-cooled motors (e.g. EZ401U)
• Weight specification for mounting position EL1, housing design N
• Without consideration of the thermal limiting performance
For the technical data on drives with forced ventilated motors (e.g. EZ401B), refer to
https://configurator.stoeber.de/en-US/
.
An explanation of the formula symbols can be found in the chapter [}15.1].
n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2,3,4 EL5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
C0 (n
1N
= 3000 rpm, M
2acc,max
= 60 Nm)
904 14 15 4.2 2.4 C002_0033 MB23 EZ501U 51 110 3.318 1702/513 8.0 8.0 3700 3600 4000 11 1.3 22
904 15 17 4.6 2.2 C002_0033 MB23 EZ402U 51 110 3.318 1702/513 8.0 8.0 3700 3600 4000 9.4 1.3 22
978 13 14 4.1 2.5 C002_0031 MB23 EZ501U 48 110 3.067 46/15 8.0 8.0 3700 3600 4000 11 1.3 22
978 13 14 4.1 2.5 C002_0031 MB23 EZ501U 48 110 3.067 46/15 12 8.0 3700 3600 4000 11 1.3 22
978 14 15 4.5 2.3 C002_0031 MB23 EZ402U 48 110 3.067 46/15 8.0 8.0 3700 3600 4000 9.4 1.3 22
978 14 15 4.5 2.3 C002_0031 MB23 EZ402U 48 110 3.067 46/15 12 8.0 3700 3600 4000 9.4 1.3 22
978 21 26 6.7 1.5 C002_0031 MB23 EZ404U 60 110 3.067 46/15 8.0 8.0 3700 3600 4000 11 1.3 24
978 21 26 6.7 1.5 C002_0031 MB23 EZ404U 60 110 3.067 46/15 12 8.0 3700 3600 4000 11 1.3 24
1083 12 13 4.1 2.7 C002_0028 MB23 EZ501U 43 110 2.769 36/13 8.0 8.0 3500 3000 4000 11 1.3 22
1083 12 13 4.1 2.7 C002_0028 MB23 EZ501U 43 110 2.769 36/13 12 8.0 3500 3000 4000 11 1.3 22
1083 13 14 4.5 2.4 C002_0028 MB23 EZ402U 43 110 2.769 36/13 8.0 8.0 3500 3000 4000 9.4 1.3 22
1083 13 14 4.5 2.4 C002_0028 MB23 EZ402U 43 110 2.769 36/13 12 8.0 3500 3000 4000 9.4 1.3 22
1083 19 23 6.5 1.7 C002_0028 MB23 EZ404U 58 110 2.769 36/13 8.0 8.0 3500 3000 4000 11 1.3 24
1083 19 23 6.5 1.7 C002_0028 MB23 EZ404U 58 110 2.769 36/13 12 8.0 3500 3000 4000 11 1.3 24
1083 20 21 7.0 1.5 C002_0028 MB23 EZ502U 58 110 2.769 36/13 8.0 8.0 3500 3000 4000 13 1.3 24
1083 20 21 7.0 1.5 C002_0028 MB23 EZ502U 58 110 2.769 36/13 12 8.0 3500 3000 4000 13 1.3 24
1502 8.3 9.1 3.9 3.3 C002_0020 MB23 EZ501U 31 110 1.997 1480/741 8.0 8.0 3500 3000 4000 11 1.3 22
1502 8.3 9.1 3.9 3.3 C002_0020 MB23 EZ501U 31 110 1.997 1480/741 12 8.0 3500 3000 4000 11 1.3 22
1502 8.3 9.1 3.9 3.3 C002_0020 MB23 EZ501U 31 110 1.997 1480/741 16 8.0 3500 3000 4000 11 1.3 22
1502 9.1 10 4.2 3.0 C002_0020 MB23 EZ402U 31 110 1.997 1480/741 8.0 8.0 3500 3000 4000 9.7 1.3 22
1502 9.1 10 4.2 3.0 C002_0020 MB23 EZ402U 31 110 1.997 1480/741 12 8.0 3500 3000 4000 9.7 1.3 22
1502 9.1 10 4.2 3.0 C002_0020 MB23 EZ402U 31 110 1.997 1480/741 16 8.0 3500 3000 4000 9.7 1.3 22
1502 13 17 6.2 2.1 C002_0020 MB23 EZ404U 52 110 1.997 1480/741 8.0 8.0 3500 3000 4000 11 1.3 24
1502 13 17 6.2 2.1 C002_0020 MB23 EZ404U 52 110 1.997 1480/741 12 8.0 3500 3000 4000 11 1.3 24
1502 13 17 6.2 2.1 C002_0020 MB23 EZ404U 52 110 1.997 1480/741 16 8.0 3500 3000 4000 11 1.3 24
1502 14 15 6.6 1.9 C002_0020 MB23 EZ502U 52 110 1.997 1480/741 8.0 8.0 3500 3000 4000 13 1.3 24
1502 14 15 6.6 1.9 C002_0020 MB23 EZ502U 52 110 1.997 1480/741 12 8.0 3500 3000 4000 13 1.3 24
1502 14 15 6.6 1.9 C002_0020 MB23 EZ502U 52 110 1.997 1480/741 16 8.0 3500 3000 4000 13 1.3 24
C1 (n
1N
= 3000 rpm, M
2acc,max
= 140 Nm)
363 34 38 2.3 3.0 C102_0083 MB23 EZ501U 128 240 8.263 1537/186 8.0 8.0 3600 3100 4000 11 3.9 27
363 38 42 2.5 2.8 C102_0083 MB23 EZ402U 128 240 8.263 1537/186 8.0 8.0 3600 3100 4000 9.7 3.9 27
363 55 69 3.7 1.9 C102_0083 MB23 EZ404U 138 240 8.263 1537/186 8.0 8.0 3600 3100 4000 11 3.9 29
363 59 64 4.0 1.8 C102_0083 MB23 EZ502U 138 240 8.263 1537/186 8.0 8.0 3600 3100 4000 13 3.9 29
473 26 29 2.6 3.1 C102_0063 MB23 EZ501U 98 220 6.338 507/80 8.0 8.0 3800 3500 4000 11 3.1 27
473 29 32 2.8 2.8 C102_0063 MB23 EZ402U 98 220 6.338 507/80 8.0 8.0 3800 3500 4000 9.4 3.1 27
473 42 53 4.2 1.9 C102_0063 MB23 EZ404U 130 220 6.338 507/80 8.0 8.0 3800 3500 4000 11 3.1 29
473 45 49 4.5 1.8 C102_0063 MB23 EZ502U 130 220 6.338 507/80 8.0 8.0 3800 3500 4000 13 3.1 29
511 25 27 2.6 3.2 C102_0059 MB23 EZ501U 91 220 5.875 47/8 8.0 8.0 3800 3500 4000 11 3.1 27
511 25 27 2.6 3.2 C102_0059 MB23 EZ501U 91 220 5.875 47/8 12 8.0 3800 3500 4000 11 3.1 27
511 27 30 2.8 2.9 C102_0059 MB23 EZ402U 91 220 5.875 47/8 8.0 8.0 3800 3500 4000 9.4 3.1 27
511 27 30 2.8 2.9 C102_0059 MB23 EZ402U 91 220 5.875 47/8 12 8.0 3800 3500 4000 9.4 3.1 27
511 39 49 4.1 2.0 C102_0059 MB23 EZ404U 130 220 5.875 47/8 8.0 8.0 3800 3500 4000 11 3.1 29
511 39 49 4.1 2.0 C102_0059 MB23 EZ404U 130 220 5.875 47/8 12 8.0 3800 3500 4000 11 3.1 29
511 42 46 4.4 1.9 C102_0059 MB23 EZ502U 130 220 5.875 47/8 8.0 8.0 3800 3500 4000 13 3.1 29
511 42 46 4.4 1.9 C102_0059 MB23 EZ502U 130 220 5.875 47/8 12 8.0 3800 3500 4000 13 3.1 29
597 21 23 2.5 3.6 C102_0050 MB23 EZ501U 78 220 5.025 201/40 8.0 8.0 3800 3500 4000 11 3.1 27
597 21 23 2.5 3.6 C102_0050 MB23 EZ501U 78 220 5.025 201/40 12 8.0 3800 3500 4000 11 3.1 27
597 21 23 2.5 3.6 C102_0050 MB23 EZ501U 78 220 5.025 201/40 16 8.0 3800 3500 4000 11 3.1 27
597 23 25 2.7 3.3 C102_0050 MB23 EZ402U 78 220 5.025 201/40 8.0 8.0 3800 3500 4000 9.5 3.1 27
