7.5.4 Mounting positions
The following table shows the standard mounting positions.
The numbers identify the gear unit sides. The mounting position is defined by the gear side facing down-
wards.
EL1 EL2 EL3
EL4 EL5 EL6
Since the lubricant filling volume of the gear unit depends on the mounting position, the mounting position
must be specified when ordering.
7.5.5 Lubricants
STOBER fills the gear units with the amount and type of lubricant specified on the nameplate. The filling vol-
ume and the structure of the gear units depend on the mounting position.
Only install the gear units in the intended mounting position! Reposition the gear units only after consulting
STOBER. Otherwise, STOBER assumes no liability for the gear units.
You will receive lubricants for use in the food industry upon request.
