11.6.4.5 Resolver
In this chapter, you can find detailed technical data for the resolver that can be installed as an encoder in a
STOBER synchronous servo motor.
Feature Description
Number of poles 2
Input voltage U
1eff
7 V ± 5%
Input frequency f
1
10 kHz
Output voltage U
2,S1–S3
K
tr
⋅ U
R1–R2
⋅ cos θ
Output voltage U
2,S2–S4
K
tr
⋅ U
R1–R2
⋅ sin θ
Transformation ratio K
tr
0.5 ± 5%
Electrical fault ±10arcmin
MTTF > 100 years
PHF ≤ 10
-9
11.6.4.6 Possible combinations with drive controllers
The following table shows the options for combining STOBER drive controllers with selectable encoder mod-
els.
Drive controller SDS 5000 SD6 SI6 SC6
Drive controller code AA AC AD AE AP AQ BB AU AV BA
Connection plan ID 442305 442307 442450 442451 442771 442772 443175 443052 443053 443174
Encoder Encoder
code
EnDat 3 EQI 1131 Q7 – – – – – – ✓ – – ✓
EnDat 2.2 EQI 1131 Q6 ✓ – ✓ – ✓ – – ✓ – –
EnDat 2.2 EQN 1135 FMA M3 ✓ – ✓ – – – – – – –
EnDat 2.2 EQN 1135 Q5 ✓ – ✓ – ✓ – – ✓ – –
EnDat 2.2 ECN 1123 FMA M1 ✓ – ✓ – – – – – – –
EnDat 2.2 ECN 1123 C7 ✓ – ✓ – ✓ – – ✓ – –
EnDat 2.2 ECI 1118-G2 C5 ✓ – ✓ – ✓ – – ✓ – –
EnDat 2.1 EQN 1125 FMA M2 ✓ ✓ ✓ ✓ – – – – – –
EnDat 2.1 EQN 1125 Q4 ✓ ✓ ✓ ✓ – – – – – –
EnDat 2.1 ECN 1113 FMA M0 ✓ ✓ ✓ ✓ – – – – – –
EnDat 2.1 ECN 1113 C6 ✓ ✓ ✓ ✓ – – – – – –
Resolver R0 ✓ – – ✓ – ✓ – – ✓ –
Notes
• The drive controller and encoder codes are a part of the type designation of the motor (see the "Type
designation" chapter).
11.6.5 Temperature sensor
In this chapter, you can find technical data for the temperature sensors that are installed in STOBER syn-
chronous servo motors for implementing thermal winding protection. To prevent damage to the motor, al-
ways monitor the temperature sensor with appropriate devices that will turn off the motor if the maximum
permitted winding temperature is exceeded.
Some encoders feature integrated temperature monitoring, the warning and switch-off thresholds of which
may overlap with the corresponding values set for the temperature sensor in the drive controller. In some
cases, this may result in an instance where an encoder with internal temperature monitoring forces the mo-
tor to shut down, even before the motor has reached its nominal data.
You can find information about the electrical connection of the temperature sensor in the "Connection
method" chapter.
