n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH731K (n
1N
= 3000 rpm, M
2acc,max
= 880 Nm)
77 250 312 40 1.5 PH731_0070K102_0056 MB23 EZ404U 733 730 1545 38.98 1520/39 12 8.0 3300 2800 4000 11 111 39
77 269 290 43 1.4 PH731_0070K102_0056 MB23 EZ502U 733 730 1545 38.98 1520/39 8.0 8.0 3300 2800 4000 13 111 39
77 269 290 43 1.4 PH731_0070K102_0056 MB23 EZ502U 733 730 1545 38.98 1520/39 12 8.0 3300 2800 4000 13 111 39
90 134 146 18 3.3 PH731_0050K202_0067 MB23 EZ501U 498 500 1720 33.42 11395/341 8.0 8.0 3500 3100 4000 11 117 45
90 134 146 18 3.3 PH731_0050K202_0067 MB23 EZ501U 498 500 1720 33.42 11395/341 12 8.0 3500 3100 4000 11 117 45
90 134 146 18 3.3 PH731_0050K202_0067 MB23 EZ501U 498 500 1720 33.42 11395/341 16 8.0 3500 3100 4000 11 117 45
90 146 162 20 3.0 PH731_0050K202_0067 MB23 EZ402U 498 500 1720 33.42 11395/341 8.0 8.0 3500 3100 4000 10 117 45
90 146 162 20 3.0 PH731_0050K202_0067 MB23 EZ402U 498 500 1720 33.42 11395/341 12 8.0 3500 3100 4000 10 117 45
90 146 162 20 3.0 PH731_0050K202_0067 MB23 EZ402U 498 500 1720 33.42 11395/341 16 8.0 3500 3100 4000 10 117 45
90 215 268 29 2.0 PH731_0050K202_0067 MB23 EZ404U 882 900 1720 33.42 11395/341 8.0 8.0 3500 3100 4000 12 117 47
90 215 268 29 2.0 PH731_0050K202_0067 MB23 EZ404U 882 900 1720 33.42 11395/341 12 8.0 3500 3100 4000 12 117 47
90 215 268 29 2.0 PH731_0050K202_0067 MB23 EZ404U 882 900 1720 33.42 11395/341 16 8.0 3500 3100 4000 12 117 47
90 230 249 31 1.9 PH731_0050K202_0067 MB23 EZ502U 882 920 1720 33.42 11395/341 8.0 8.0 3500 3100 4000 14 117 46
90 230 249 31 1.9 PH731_0050K202_0067 MB23 EZ502U 882 920 1720 33.42 11395/341 12 8.0 3500 3100 4000 14 117 46
90 230 249 31 1.9 PH731_0050K202_0067 MB23 EZ502U 882 920 1720 33.42 11395/341 16 8.0 3500 3100 4000 14 117 46
90 302 345 41 1.5 PH731_0050K202_0067 MB23 EZ503U 882 920 1720 33.42 11395/341 8.0 15 3500 3100 4000 17 117 48
90 302 345 41 1.5 PH731_0050K202_0067 MB23 EZ503U 882 920 1720 33.42 11395/341 12 15 3500 3100 4000 17 117 48
90 420 498 57 1.0 PH731_0050K202_0067 MB23 EZ505U 882 920 1720 33.42 11395/341 8.0 15 3500 3100 4000 22 117 51
90 420 498 57 1.0 PH731_0050K202_0067 MB23 EZ505U 882 920 1720 33.42 11395/341 12 15 3500 3100 4000 22 117 51
100 120 131 18 3.7 PH731_0050K202_0060 MB23 EZ501U 447 450 1720 30.00 30/1 8.0 8.0 3000 2600 4000 12 117 45
100 120 131 18 3.7 PH731_0050K202_0060 MB23 EZ501U 447 450 1720 30.00 30/1 12 8.0 3000 2600 4000 12 117 45
100 120 131 18 3.7 PH731_0050K202_0060 MB23 EZ501U 447 450 1720 30.00 30/1 16 8.0 3000 2600 4000 12 117 45
100 131 145 19 3.4 PH731_0050K202_0060 MB23 EZ402U 447 450 1720 30.00 30/1 8.0 8.0 3000 2600 4000 11 117 45
100 131 145 19 3.4 PH731_0050K202_0060 MB23 EZ402U 447 450 1720 30.00 30/1 12 8.0 3000 2600 4000 11 117 45
100 131 145 19 3.4 PH731_0050K202_0060 MB23 EZ402U 447 450 1720 30.00 30/1 16 8.0 3000 2600 4000 11 117 45
100 193 240 29 2.3 PH731_0050K202_0060 MB23 EZ404U 810 810 1720 30.00 30/1 8.0 8.0 3000 2600 4000 12 117 47
100 193 240 29 2.3 PH731_0050K202_0060 MB23 EZ404U 810 810 1720 30.00 30/1 12 8.0 3000 2600 4000 12 117 47
100 193 240 29 2.3 PH731_0050K202_0060 MB23 EZ404U 810 810 1720 30.00 30/1 16 8.0 3000 2600 4000 12 117 47
100 207 223 31 2.1 PH731_0050K202_0060 MB23 EZ502U 866 870 1720 30.00 30/1 8.0 8.0 3000 2600 4000 14 117 46
100 207 223 31 2.1 PH731_0050K202_0060 MB23 EZ502U 866 870 1720 30.00 30/1 12 8.0 3000 2600 4000 14 117 46
100 207 223 31 2.1 PH731_0050K202_0060 MB23 EZ502U 866 870 1720 30.00 30/1 16 8.0 3000 2600 4000 14 117 46
100 207 232 31 2.1 PH731_0050K202_0060 MB33 EZ701U 559 560 1720 30.00 30/1 16 15 3000 2600 4000 39 117 56
100 271 310 40 1.6 PH731_0050K202_0060 MB23 EZ503U 882 920 1720 30.00 30/1 8.0 15 3000 2600 4000 18 117 48
100 271 310 40 1.6 PH731_0050K202_0060 MB23 EZ503U 882 920 1720 30.00 30/1 12 15 3000 2600 4000 18 117 48
100 335 402 50 1.3 PH731_0050K202_0060 MB33 EZ702U 882 920 1720 30.00 30/1 16 15 3000 2600 4000 45 117 58
100 377 447 56 1.2 PH731_0050K202_0060 MB23 EZ505U 882 920 1720 30.00 30/1 8.0 15 3000 2600 4000 22 117 51
100 377 447 56 1.2 PH731_0050K202_0060 MB23 EZ505U 882 920 1720 30.00 30/1 12 15 3000 2600 4000 22 117 51
107 112 123 26 3.1 PH731_0070K102_0040 MB23 EZ501U 417 420 1545 28.00 28/1 8.0 8.0 3300 2800 4000 11 111 37
107 112 123 26 3.1 PH731_0070K102_0040 MB23 EZ501U 417 420 1545 28.00 28/1 12 8.0 3300 2800 4000 11 111 37
107 112 123 26 3.1 PH731_0070K102_0040 MB23 EZ501U 417 420 1545 28.00 28/1 16 8.0 3300 2800 4000 11 111 37
107 123 136 28 2.8 PH731_0070K102_0040 MB23 EZ402U 417 420 1545 28.00 28/1 8.0 8.0 3300 2800 4000 10 111 37
107 123 136 28 2.8 PH731_0070K102_0040 MB23 EZ402U 417 420 1545 28.00 28/1 12 8.0 3300 2800 4000 10 111 37
107 123 136 28 2.8 PH731_0070K102_0040 MB23 EZ402U 417 420 1545 28.00 28/1 16 8.0 3300 2800 4000 10 111 37
107 180 224 41 1.9 PH731_0070K102_0040 MB23 EZ404U 657 660 1545 28.00 28/1 8.0 8.0 3300 2800 4000 11 111 39
107 180 224 41 1.9 PH731_0070K102_0040 MB23 EZ404U 657 660 1545 28.00 28/1 12 8.0 3300 2800 4000 11 111 39
107 180 224 41 1.9 PH731_0070K102_0040 MB23 EZ404U 657 660 1545 28.00 28/1 16 8.0 3300 2800 4000 11 111 39
107 193 209 44 1.8 PH731_0070K102_0040 MB23 EZ502U 657 660 1545 28.00 28/1 8.0 8.0 3300 2800 4000 14 111 39
107 193 209 44 1.8 PH731_0070K102_0040 MB23 EZ502U 657 660 1545 28.00 28/1 12 8.0 3300 2800 4000 14 111 39
107 193 209 44 1.8 PH731_0070K102_0040 MB23 EZ502U 657 660 1545 28.00 28/1 16 8.0 3300 2800 4000 14 111 39
107 253 289 58 1.4 PH731_0070K102_0040 MB23 EZ503U 657 660 1545 28.00 28/1 8.0 15 3300 2800 4000 17 111 41
107 253 289 58 1.4 PH731_0070K102_0040 MB23 EZ503U 657 660 1545 28.00 28/1 12 15 3300 2800 4000 17 111 41
116 104 113 17 4.2 PH731_0050K202_0052 MB23 EZ501U 386 390 1519 25.89 10535/407 8.0 8.0 3000 2600 4000 12 117 45
116 104 113 17 4.2 PH731_0050K202_0052 MB23 EZ501U 386 390 1519 25.89 10535/407 12 8.0 3000 2600 4000 12 117 45
116 104 113 17 4.2 PH731_0050K202_0052 MB23 EZ501U 386 390 1519 25.89 10535/407 16 8.0 3000 2600 4000 12 117 45
116 113 125 19 3.9 PH731_0050K202_0052 MB23 EZ402U 386 390 1519 25.89 10535/407 8.0 8.0 3000 2600 4000 11 117 45
116 113 125 19 3.9 PH731_0050K202_0052 MB23 EZ402U 386 390 1519 25.89 10535/407 12 8.0 3000 2600 4000 11 117 45
116 113 125 19 3.9 PH731_0050K202_0052 MB23 EZ402U 386 390 1519 25.89 10535/407 16 8.0 3000 2600 4000 11 117 45
116 166 207 28 2.6 PH731_0050K202_0052 MB23 EZ404U 699 700 1519 25.89 10535/407 8.0 8.0 3000 2600 4000 12 117 47
116 166 207 28 2.6 PH731_0050K202_0052 MB23 EZ404U 699 700 1519 25.89 10535/407 12 8.0 3000 2600 4000 12 117 47
116 166 207 28 2.6 PH731_0050K202_0052 MB23 EZ404U 699 700 1519 25.89 10535/407 16 8.0 3000 2600 4000 12 117 47
116 178 193 30 2.5 PH731_0050K202_0052 MB23 EZ502U 747 750 1519 25.89 10535/407 8.0 8.0 3000 2600 4000 14 117 46
116 178 193 30 2.5 PH731_0050K202_0052 MB23 EZ502U 747 750 1519 25.89 10535/407 12 8.0 3000 2600 4000 14 117 46
116 178 193 30 2.5 PH731_0050K202_0052 MB23 EZ502U 747 750 1519 25.89 10535/407 16 8.0 3000 2600 4000 14 117 46
116 178 200 30 2.5 PH731_0050K202_0052 MB33 EZ701U 482 480 1720 25.89 10535/407 16 15 3000 2600 4000 39 117 56
8.2 Selection tables 8 PHKright-angle planetary geared motors
226
