Stober PK - Page 227

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH731K (n
1N
= 3000 rpm, M
2acc,max
= 880 Nm)
116 234 268 39 1.9 PH731_0050K202_0052 MB23 EZ503U 882 900 1519 25.89 10535/407 8.0 15 3000 2600 4000 18 117 48
116 234 268 39 1.9 PH731_0050K202_0052 MB23 EZ503U 882 900 1519 25.89 10535/407 12 15 3000 2600 4000 18 117 48
116 289 347 48 1.5 PH731_0050K202_0052 MB33 EZ702U 882 910 1720 25.89 10535/407 16 15 3000 2600 4000 45 117 58
116 325 386 54 1.4 PH731_0050K202_0052 MB23 EZ505U 882 900 1519 25.89 10535/407 8.0 15 3000 2600 4000 22 117 51
116 325 386 54 1.4 PH731_0050K202_0052 MB23 EZ505U 882 900 1519 25.89 10535/407 12 15 3000 2600 4000 22 117 51
150 129 160 26 3.4 PH731_0050K202_0040 MB23 EZ404U 540 540 1173 20.00 20/1 8.0 8.0 3000 2600 4000 13 117 47
150 129 160 26 3.4 PH731_0050K202_0040 MB23 EZ404U 540 540 1173 20.00 20/1 12 8.0 3000 2600 4000 13 117 47
150 129 160 26 3.4 PH731_0050K202_0040 MB23 EZ404U 540 540 1173 20.00 20/1 16 8.0 3000 2600 4000 13 117 47
150 138 149 28 3.2 PH731_0050K202_0040 MB23 EZ502U 577 580 1173 20.00 20/1 8.0 8.0 3000 2600 4000 15 117 46
150 138 149 28 3.2 PH731_0050K202_0040 MB23 EZ502U 577 580 1173 20.00 20/1 12 8.0 3000 2600 4000 15 117 46
150 138 149 28 3.2 PH731_0050K202_0040 MB23 EZ502U 577 580 1173 20.00 20/1 16 8.0 3000 2600 4000 15 117 46
150 138 155 28 3.2 PH731_0050K202_0040 MB33 EZ701U 372 370 1720 20.00 20/1 16 15 3000 2600 4000 40 117 56
150 138 155 28 3.2 PH731_0050K202_0040 MB33 EZ701U 372 370 1720 20.00 20/1 24 15 3000 2600 4000 40 117 56
150 138 155 28 3.2 PH731_0050K202_0040 MB33 EZ701U 372 370 1720 20.00 20/1 32 15 3000 2600 4000 40 117 56
150 181 207 36 2.4 PH731_0050K202_0040 MB23 EZ503U 698 700 1173 20.00 20/1 8.0 15 3000 2600 4000 19 117 48
150 181 207 36 2.4 PH731_0050K202_0040 MB23 EZ503U 698 700 1173 20.00 20/1 12 15 3000 2600 4000 19 117 48
150 223 268 45 2.0 PH731_0050K202_0040 MB33 EZ702U 764 760 1720 20.00 20/1 16 15 3000 2600 4000 45 117 58
150 223 268 45 2.0 PH731_0050K202_0040 MB33 EZ702U 764 760 1720 20.00 20/1 24 15 3000 2600 4000 45 117 58
150 223 268 45 2.0 PH731_0050K202_0040 MB33 EZ702U 764 760 1720 20.00 20/1 32 15 3000 2600 4000 45 117 58
150 251 298 51 1.8 PH731_0050K202_0040 MB23 EZ505U 698 700 1173 20.00 20/1 8.0 15 3000 2600 4000 23 117 51
150 251 298 51 1.8 PH731_0050K202_0040 MB23 EZ505U 698 700 1173 20.00 20/1 12 15 3000 2600 4000 23 117 51
188 103 128 26 3.4 PH731_0040K202_0040 MB23 EZ404U 432 430 939 16.00 16/1 8.0 8.0 3000 2600 4000 13 100 47
188 103 128 26 3.4 PH731_0040K202_0040 MB23 EZ404U 432 430 939 16.00 16/1 12 8.0 3000 2600 4000 13 100 47
188 103 128 26 3.4 PH731_0040K202_0040 MB23 EZ404U 432 430 939 16.00 16/1 16 8.0 3000 2600 4000 13 100 47
188 110 119 27 3.2 PH731_0040K202_0040 MB23 EZ502U 462 460 939 16.00 16/1 8.0 8.0 3000 2600 4000 15 100 46
188 110 119 27 3.2 PH731_0040K202_0040 MB23 EZ502U 462 460 939 16.00 16/1 12 8.0 3000 2600 4000 15 100 46
188 110 119 27 3.2 PH731_0040K202_0040 MB23 EZ502U 462 460 939 16.00 16/1 16 8.0 3000 2600 4000 15 100 46
188 110 124 27 3.2 PH731_0040K202_0040 MB33 EZ701U 298 300 1667 16.00 16/1 16 15 3000 2600 4000 40 100 56
188 110 124 27 3.2 PH731_0040K202_0040 MB33 EZ701U 298 300 1667 16.00 16/1 24 15 3000 2600 4000 40 100 56
188 110 124 27 3.2 PH731_0040K202_0040 MB33 EZ701U 298 300 1667 16.00 16/1 32 15 3000 2600 4000 40 100 56
188 110 124 27 3.2 PH731_0040K202_0040 MB33 EZ701U 298 300 1667 16.00 16/1 45 15 3000 2600 4000 40 100 56
188 145 165 36 2.5 PH731_0040K202_0040 MB23 EZ503U 559 560 939 16.00 16/1 8.0 15 3000 2600 4000 19 100 48
188 145 165 36 2.5 PH731_0040K202_0040 MB23 EZ503U 559 560 939 16.00 16/1 12 15 3000 2600 4000 19 100 48
188 179 215 45 2.0 PH731_0040K202_0040 MB33 EZ702U 611 610 1667 16.00 16/1 16 15 3000 2600 4000 46 100 58
188 179 215 45 2.0 PH731_0040K202_0040 MB33 EZ702U 611 610 1667 16.00 16/1 24 15 3000 2600 4000 46 100 58
188 179 215 45 2.0 PH731_0040K202_0040 MB33 EZ702U 611 610 1667 16.00 16/1 32 15 3000 2600 4000 46 100 58
188 179 215 45 2.0 PH731_0040K202_0040 MB33 EZ702U 611 610 1667 16.00 16/1 45 15 3000 2600 4000 46 100 58
188 201 238 50 1.8 PH731_0040K202_0040 MB23 EZ505U 559 560 939 16.00 16/1 8.0 15 3000 2600 4000 23 100 51
188 201 238 50 1.8 PH731_0040K202_0040 MB23 EZ505U 559 560 939 16.00 16/1 12 15 3000 2600 4000 23 100 51
188 246 310 61 1.4 PH731_0040K202_0040 MB33 EZ703U 670 670 1667 16.00 16/1 16 32 3000 2600 4000 57 100 61
188 317 450 79 1.1 PH731_0040K202_0040 MB33 EZ705U 670 670 1667 16.00 16/1 16 32 3000 2600 4000 70 100 66
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
26 466 510 11 2.4 PH831_0050K302_0230 MB23 EZ501U 1735 1740 3646 116.5 2795/24 8.0 8.0 3800 3500 4000 11 245 68
26 510 564 12 2.2 PH831_0050K302_0230 MB23 EZ402U 1735 1740 3646 116.5 2795/24 8.0 8.0 3800 3500 4000 9.5 245 68
26 748 933 18 1.5 PH831_0050K302_0230 MB23 EZ404U 1848 1850 3646 116.5 2795/24 8.0 8.0 3800 3500 4000 11 245 70
26 803 868 19 1.4 PH831_0050K302_0230 MB23 EZ502U 1848 1850 3646 116.5 2795/24 8.0 8.0 3800 3500 4000 13 245 70
31 388 424 14 2.4 PH831_0070K202_0140 MB23 EZ501U 1445 1440 2917 96.96 20167/208 8.0 8.0 3900 3500 4000 11 245 63
31 424 469 16 2.2 PH831_0070K202_0140 MB23 EZ402U 1445 1440 2917 96.96 20167/208 8.0 8.0 3900 3500 4000 9.5 245 63
31 623 776 23 1.5 PH831_0070K202_0140 MB23 EZ404U 1478 1480 2917 96.96 20167/208 8.0 8.0 3900 3500 4000 11 245 65
31 668 722 25 1.4 PH831_0070K202_0140 MB23 EZ502U 1478 1480 2917 96.96 20167/208 8.0 8.0 3900 3500 4000 13 245 65
33 368 402 21 2.3 PH831_0100K202_0092 MB23 EZ501U 1369 1370 2784 91.90 11395/124 8.0 8.0 3500 3100 4000 11 260 63
33 402 445 22 2.1 PH831_0100K202_0092 MB23 EZ402U 1369 1370 2784 91.90 11395/124 8.0 8.0 3500 3100 4000 10 260 63
33 590 736 33 1.4 PH831_0100K202_0092 MB23 EZ404U 1392 1390 2784 91.90 11395/124 8.0 8.0 3500 3100 4000 11 260 65
33 633 685 35 1.3 PH831_0100K202_0092 MB23 EZ502U 1392 1390 2784 91.90 11395/124 8.0 8.0 3500 3100 4000 14 260 65
34 356 389 15 2.6 PH831_0070K202_0125 MB23 EZ501U 1325 1330 2917 88.94 3913/44 8.0 8.0 3900 3500 4000 11 245 63
34 389 431 16 2.3 PH831_0070K202_0125 MB23 EZ402U 1325 1330 2917 88.94 3913/44 8.0 8.0 3900 3500 4000 9.5 245 63
34 571 712 23 1.6 PH831_0070K202_0125 MB23 EZ404U 1478 1480 2917 88.94 3913/44 8.0 8.0 3900 3500 4000 11 245 65
34 613 663 25 1.5 PH831_0070K202_0125 MB23 EZ502U 1478 1480 2917 88.94 3913/44 8.0 8.0 3900 3500 4000 13 245 65
35 346 378 10 3.2 PH831_0050K302_0175 MB23 EZ501U 1288 1290 3646 86.47 7955/92 8.0 8.0 3500 3100 4000 11 245 68
35 346 378 10 3.2 PH831_0050K302_0175 MB23 EZ501U 1288 1290 3646 86.47 7955/92 12 8.0 3500 3100 4000 11 245 68
35 378 419 11 2.9 PH831_0050K302_0175 MB23 EZ402U 1288 1290 3646 86.47 7955/92 8.0 8.0 3500 3100 4000 9.8 245 68
35 378 419 11 2.9 PH831_0050K302_0175 MB23 EZ402U 1288 1290 3646 86.47 7955/92 12 8.0 3500 3100 4000 9.8 245 68
35 556 692 16 2.0 PH831_0050K302_0175 MB23 EZ404U 1848 1850 3646 86.47 7955/92 8.0 8.0 3500 3100 4000 11 245 70
35 556 692 16 2.0 PH831_0050K302_0175 MB23 EZ404U 1848 1850 3646 86.47 7955/92 12 8.0 3500 3100 4000 11 245 70
8 PHKright-angle planetary geared motors 8.2 Selection tables
227
