Stober PK - Page 228

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
35 596 644 18 1.8 PH831_0050K302_0175 MB23 EZ502U 1848 1850 3646 86.47 7955/92 8.0 8.0 3500 3100 4000 13 245 70
35 596 644 18 1.8 PH831_0050K302_0175 MB23 EZ502U 1848 1850 3646 86.47 7955/92 12 8.0 3500 3100 4000 13 245 70
35 781 894 23 1.4 PH831_0050K302_0175 MB23 EZ503U 1848 1850 3646 86.47 7955/92 8.0 15 3500 3100 4000 17 245 71
35 1087 1288 32 1.0 PH831_0050K302_0175 MB23 EZ505U 1848 1850 3646 86.47 7955/92 8.0 15 3500 3100 4000 21 245 74
36 336 368 20 2.5 PH831_0100K202_0084 MB23 EZ501U 1251 1250 2784 83.97 24940/297 8.0 8.0 3500 3100 4000 11 260 63
36 368 407 22 2.3 PH831_0100K202_0084 MB23 EZ402U 1251 1250 2784 83.97 24940/297 8.0 8.0 3500 3100 4000 9.8 260 63
36 540 672 32 1.6 PH831_0100K202_0084 MB23 EZ404U 1392 1390 2784 83.97 24940/297 8.0 8.0 3500 3100 4000 11 260 65
36 579 626 35 1.5 PH831_0100K202_0084 MB23 EZ502U 1392 1390 2784 83.97 24940/297 8.0 8.0 3500 3100 4000 13 260 65
37 324 354 15 2.7 PH831_0070K202_0115 MB23 EZ501U 1204 1200 2917 80.82 8729/108 8.0 8.0 3500 3100 4000 11 245 63
37 354 391 16 2.5 PH831_0070K202_0115 MB23 EZ402U 1204 1200 2917 80.82 8729/108 8.0 8.0 3500 3100 4000 9.7 245 63
37 519 647 23 1.7 PH831_0070K202_0115 MB23 EZ404U 1478 1480 2917 80.82 8729/108 8.0 8.0 3500 3100 4000 11 245 65
37 557 602 25 1.6 PH831_0070K202_0115 MB23 EZ502U 1478 1480 2917 80.82 8729/108 8.0 8.0 3500 3100 4000 13 245 65
43 282 309 15 3.0 PH831_0070K202_0100 MB23 EZ501U 1051 1050 2917 70.51 20167/286 8.0 8.0 3900 3500 4000 11 245 63
43 282 309 15 3.0 PH831_0070K202_0100 MB23 EZ501U 1051 1050 2917 70.51 20167/286 12 8.0 3900 3500 4000 11 245 63
43 309 341 16 2.7 PH831_0070K202_0100 MB23 EZ402U 1051 1050 2917 70.51 20167/286 8.0 8.0 3900 3500 4000 9.7 245 63
43 309 341 16 2.7 PH831_0070K202_0100 MB23 EZ402U 1051 1050 2917 70.51 20167/286 12 8.0 3900 3500 4000 9.7 245 63
43 453 565 24 1.9 PH831_0070K202_0100 MB23 EZ404U 1478 1480 2917 70.51 20167/286 8.0 8.0 3900 3500 4000 11 245 65
43 453 565 24 1.9 PH831_0070K202_0100 MB23 EZ404U 1478 1480 2917 70.51 20167/286 12 8.0 3900 3500 4000 11 245 65
43 486 525 25 1.7 PH831_0070K202_0100 MB23 EZ502U 1478 1480 2917 70.51 20167/286 8.0 8.0 3900 3500 4000 13 245 65
43 486 525 25 1.7 PH831_0070K202_0100 MB23 EZ502U 1478 1480 2917 70.51 20167/286 12 8.0 3900 3500 4000 13 245 65
43 279 305 9.7 3.9 PH831_0050K302_0140 MB23 EZ501U 1038 1040 3646 69.68 7525/108 8.0 8.0 3500 3100 4000 11 245 68
43 279 305 9.7 3.9 PH831_0050K302_0140 MB23 EZ501U 1038 1040 3646 69.68 7525/108 12 8.0 3500 3100 4000 11 245 68
43 279 305 9.7 3.9 PH831_0050K302_0140 MB23 EZ501U 1038 1040 3646 69.68 7525/108 16 8.0 3500 3100 4000 11 245 68
43 305 337 11 3.6 PH831_0050K302_0140 MB23 EZ402U 1038 1040 3646 69.68 7525/108 8.0 8.0 3500 3100 4000 10 245 68
43 305 337 11 3.6 PH831_0050K302_0140 MB23 EZ402U 1038 1040 3646 69.68 7525/108 12 8.0 3500 3100 4000 10 245 68
43 305 337 11 3.6 PH831_0050K302_0140 MB23 EZ402U 1038 1040 3646 69.68 7525/108 16 8.0 3500 3100 4000 10 245 68
43 448 558 16 2.5 PH831_0050K302_0140 MB23 EZ404U 1848 1850 3646 69.68 7525/108 8.0 8.0 3500 3100 4000 11 245 70
43 448 558 16 2.5 PH831_0050K302_0140 MB23 EZ404U 1848 1850 3646 69.68 7525/108 12 8.0 3500 3100 4000 11 245 70
43 448 558 16 2.5 PH831_0050K302_0140 MB23 EZ404U 1848 1850 3646 69.68 7525/108 16 8.0 3500 3100 4000 11 245 70
43 480 519 17 2.3 PH831_0050K302_0140 MB23 EZ502U 1848 1850 3646 69.68 7525/108 8.0 8.0 3500 3100 4000 14 245 70
43 480 519 17 2.3 PH831_0050K302_0140 MB23 EZ502U 1848 1850 3646 69.68 7525/108 12 8.0 3500 3100 4000 14 245 70
43 480 519 17 2.3 PH831_0050K302_0140 MB23 EZ502U 1848 1850 3646 69.68 7525/108 16 8.0 3500 3100 4000 14 245 70
43 629 720 22 1.7 PH831_0050K302_0140 MB23 EZ503U 1848 1850 3646 69.68 7525/108 8.0 15 3500 3100 4000 17 245 71
43 629 720 22 1.7 PH831_0050K302_0140 MB23 EZ503U 1848 1850 3646 69.68 7525/108 12 15 3500 3100 4000 17 245 71
43 876 1038 30 1.3 PH831_0050K302_0140 MB23 EZ505U 1848 1850 3646 69.68 7525/108 8.0 15 3500 3100 4000 22 245 74
43 876 1038 30 1.3 PH831_0050K302_0140 MB23 EZ505U 1848 1850 3646 69.68 7525/108 12 15 3500 3100 4000 22 245 74
45 268 292 19 3.2 PH831_0100K202_0067 MB23 EZ501U 996 1000 2784 66.83 22790/341 8.0 8.0 3500 3100 4000 11 260 63
45 268 292 19 3.2 PH831_0100K202_0067 MB23 EZ501U 996 1000 2784 66.83 22790/341 12 8.0 3500 3100 4000 11 260 63
45 292 324 21 2.9 PH831_0100K202_0067 MB23 EZ402U 996 1000 2784 66.83 22790/341 8.0 8.0 3500 3100 4000 10 260 63
45 292 324 21 2.9 PH831_0100K202_0067 MB23 EZ402U 996 1000 2784 66.83 22790/341 12 8.0 3500 3100 4000 10 260 63
45 429 535 30 2.0 PH831_0100K202_0067 MB23 EZ404U 1392 1390 2784 66.83 22790/341 8.0 8.0 3500 3100 4000 12 260 65
45 429 535 30 2.0 PH831_0100K202_0067 MB23 EZ404U 1392 1390 2784 66.83 22790/341 12 8.0 3500 3100 4000 12 260 65
45 461 498 33 1.8 PH831_0100K202_0067 MB23 EZ502U 1392 1390 2784 66.83 22790/341 8.0 8.0 3500 3100 4000 14 260 65
45 461 498 33 1.8 PH831_0100K202_0067 MB23 EZ502U 1392 1390 2784 66.83 22790/341 12 8.0 3500 3100 4000 14 260 65
47 258 282 15 3.2 PH831_0070K202_0092 MB23 EZ501U 958 960 2917 64.33 15953/248 8.0 8.0 3500 3100 4000 11 245 63
47 258 282 15 3.2 PH831_0070K202_0092 MB23 EZ501U 958 960 2917 64.33 15953/248 12 8.0 3500 3100 4000 11 245 63
47 258 282 15 3.2 PH831_0070K202_0092 MB23 EZ501U 958 960 2917 64.33 15953/248 16 8.0 3500 3100 4000 11 245 63
47 282 312 16 2.9 PH831_0070K202_0092 MB23 EZ402U 958 960 2917 64.33 15953/248 8.0 8.0 3500 3100 4000 10 245 63
47 282 312 16 2.9 PH831_0070K202_0092 MB23 EZ402U 958 960 2917 64.33 15953/248 12 8.0 3500 3100 4000 10 245 63
47 282 312 16 2.9 PH831_0070K202_0092 MB23 EZ402U 958 960 2917 64.33 15953/248 16 8.0 3500 3100 4000 10 245 63
47 413 515 24 2.0 PH831_0070K202_0092 MB23 EZ404U 1478 1480 2917 64.33 15953/248 8.0 8.0 3500 3100 4000 11 245 65
47 413 515 24 2.0 PH831_0070K202_0092 MB23 EZ404U 1478 1480 2917 64.33 15953/248 12 8.0 3500 3100 4000 11 245 65
47 413 515 24 2.0 PH831_0070K202_0092 MB23 EZ404U 1478 1480 2917 64.33 15953/248 16 8.0 3500 3100 4000 11 245 65
47 443 479 26 1.8 PH831_0070K202_0092 MB23 EZ502U 1478 1480 2917 64.33 15953/248 8.0 8.0 3500 3100 4000 14 245 65
47 443 479 26 1.8 PH831_0070K202_0092 MB23 EZ502U 1478 1480 2917 64.33 15953/248 12 8.0 3500 3100 4000 14 245 65
47 443 479 26 1.8 PH831_0070K202_0092 MB23 EZ502U 1478 1480 2917 64.33 15953/248 16 8.0 3500 3100 4000 14 245 65
47 581 665 34 1.4 PH831_0070K202_0092 MB23 EZ503U 1478 1480 2917 64.33 15953/248 8.0 15 3500 3100 4000 17 245 66
47 809 958 47 1.0 PH831_0070K202_0092 MB23 EZ505U 1478 1480 2917 64.33 15953/248 8.0 15 3500 3100 4000 22 245 69
50 240 263 18 3.5 PH831_0100K202_0060 MB23 EZ501U 894 890 2784 60.00 60/1 8.0 8.0 3000 2600 4000 12 260 63
50 240 263 18 3.5 PH831_0100K202_0060 MB23 EZ501U 894 890 2784 60.00 60/1 12 8.0 3000 2600 4000 12 260 63
50 240 263 18 3.5 PH831_0100K202_0060 MB23 EZ501U 894 890 2784 60.00 60/1 16 8.0 3000 2600 4000 12 260 63
50 263 291 20 3.2 PH831_0100K202_0060 MB23 EZ402U 894 890 2784 60.00 60/1 8.0 8.0 3000 2600 4000 11 260 63
50 263 291 20 3.2 PH831_0100K202_0060 MB23 EZ402U 894 890 2784 60.00 60/1 12 8.0 3000 2600 4000 11 260 63
50 263 291 20 3.2 PH831_0100K202_0060 MB23 EZ402U 894 890 2784 60.00 60/1 16 8.0 3000 2600 4000 11 260 63
8.2 Selection tables 8 PHKright-angle planetary geared motors
