n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
50 386 480 30 2.2 PH831_0100K202_0060 MB23 EZ404U 1392 1390 2784 60.00 60/1 8.0 8.0 3000 2600 4000 12 260 65
50 386 480 30 2.2 PH831_0100K202_0060 MB23 EZ404U 1392 1390 2784 60.00 60/1 12 8.0 3000 2600 4000 12 260 65
50 386 480 30 2.2 PH831_0100K202_0060 MB23 EZ404U 1392 1390 2784 60.00 60/1 16 8.0 3000 2600 4000 12 260 65
50 413 447 32 2.1 PH831_0100K202_0060 MB23 EZ502U 1392 1390 2784 60.00 60/1 8.0 8.0 3000 2600 4000 14 260 65
50 413 447 32 2.1 PH831_0100K202_0060 MB23 EZ502U 1392 1390 2784 60.00 60/1 12 8.0 3000 2600 4000 14 260 65
50 413 447 32 2.1 PH831_0100K202_0060 MB23 EZ502U 1392 1390 2784 60.00 60/1 16 8.0 3000 2600 4000 14 260 65
50 542 620 42 1.6 PH831_0100K202_0060 MB23 EZ503U 1392 1390 2784 60.00 60/1 8.0 15 3000 2600 4000 18 260 66
50 754 894 58 1.1 PH831_0100K202_0060 MB23 EZ505U 1392 1390 2784 60.00 60/1 8.0 15 3000 2600 4000 22 260 69
51 235 257 15 3.4 PH831_0070K202_0084 MB23 EZ501U 876 880 2917 58.78 17458/297 8.0 8.0 3500 3100 4000 11 245 63
51 235 257 15 3.4 PH831_0070K202_0084 MB23 EZ501U 876 880 2917 58.78 17458/297 12 8.0 3500 3100 4000 11 245 63
51 235 257 15 3.4 PH831_0070K202_0084 MB23 EZ501U 876 880 2917 58.78 17458/297 16 8.0 3500 3100 4000 11 245 63
51 257 285 16 3.1 PH831_0070K202_0084 MB23 EZ402U 876 880 2917 58.78 17458/297 8.0 8.0 3500 3100 4000 9.9 245 63
51 257 285 16 3.1 PH831_0070K202_0084 MB23 EZ402U 876 880 2917 58.78 17458/297 12 8.0 3500 3100 4000 9.9 245 63
51 257 285 16 3.1 PH831_0070K202_0084 MB23 EZ402U 876 880 2917 58.78 17458/297 16 8.0 3500 3100 4000 9.9 245 63
51 378 471 24 2.1 PH831_0070K202_0084 MB23 EZ404U 1478 1480 2917 58.78 17458/297 8.0 8.0 3500 3100 4000 11 245 65
51 378 471 24 2.1 PH831_0070K202_0084 MB23 EZ404U 1478 1480 2917 58.78 17458/297 12 8.0 3500 3100 4000 11 245 65
51 378 471 24 2.1 PH831_0070K202_0084 MB23 EZ404U 1478 1480 2917 58.78 17458/297 16 8.0 3500 3100 4000 11 245 65
51 405 438 26 2.0 PH831_0070K202_0084 MB23 EZ502U 1478 1480 2917 58.78 17458/297 8.0 8.0 3500 3100 4000 13 245 65
51 405 438 26 2.0 PH831_0070K202_0084 MB23 EZ502U 1478 1480 2917 58.78 17458/297 12 8.0 3500 3100 4000 13 245 65
51 405 438 26 2.0 PH831_0070K202_0084 MB23 EZ502U 1478 1480 2917 58.78 17458/297 16 8.0 3500 3100 4000 13 245 65
51 531 608 34 1.5 PH831_0070K202_0084 MB23 EZ503U 1478 1480 2917 58.78 17458/297 8.0 15 3500 3100 4000 17 245 66
51 531 608 34 1.5 PH831_0070K202_0084 MB23 EZ503U 1478 1480 2917 58.78 17458/297 12 15 3500 3100 4000 17 245 66
51 739 876 47 1.1 PH831_0070K202_0084 MB23 EZ505U 1478 1480 2917 58.78 17458/297 8.0 15 3500 3100 4000 22 245 69
51 739 876 47 1.1 PH831_0070K202_0084 MB23 EZ505U 1478 1480 2917 58.78 17458/297 12 15 3500 3100 4000 22 245 69
52 232 254 9.2 4.7 PH831_0050K302_0115 MB23 EZ501U 865 860 3406 58.05 1161/20 8.0 8.0 3200 2800 4000 12 245 68
52 232 254 9.2 4.7 PH831_0050K302_0115 MB23 EZ501U 865 860 3406 58.05 1161/20 12 8.0 3200 2800 4000 12 245 68
52 232 254 9.2 4.7 PH831_0050K302_0115 MB23 EZ501U 865 860 3406 58.05 1161/20 16 8.0 3200 2800 4000 12 245 68
52 254 281 10 4.3 PH831_0050K302_0115 MB23 EZ402U 865 860 3406 58.05 1161/20 8.0 8.0 3200 2800 4000 10 245 68
52 254 281 10 4.3 PH831_0050K302_0115 MB23 EZ402U 865 860 3406 58.05 1161/20 12 8.0 3200 2800 4000 10 245 68
52 254 281 10 4.3 PH831_0050K302_0115 MB23 EZ402U 865 860 3406 58.05 1161/20 16 8.0 3200 2800 4000 10 245 68
52 373 465 15 2.9 PH831_0050K302_0115 MB23 EZ404U 1568 1570 3406 58.05 1161/20 8.0 8.0 3200 2800 4000 12 245 70
52 373 465 15 2.9 PH831_0050K302_0115 MB23 EZ404U 1568 1570 3406 58.05 1161/20 12 8.0 3200 2800 4000 12 245 70
52 373 465 15 2.9 PH831_0050K302_0115 MB23 EZ404U 1568 1570 3406 58.05 1161/20 16 8.0 3200 2800 4000 12 245 70
52 400 432 16 2.8 PH831_0050K302_0115 MB23 EZ502U 1676 1680 3406 58.05 1161/20 8.0 8.0 3200 2800 4000 14 245 70
52 400 432 16 2.8 PH831_0050K302_0115 MB23 EZ502U 1676 1680 3406 58.05 1161/20 12 8.0 3200 2800 4000 14 245 70
52 400 432 16 2.8 PH831_0050K302_0115 MB23 EZ502U 1676 1680 3406 58.05 1161/20 16 8.0 3200 2800 4000 14 245 70
52 400 449 16 2.8 PH831_0050K302_0115 MB33 EZ701U 1081 1080 3646 58.05 1161/20 16 15 3200 2800 4000 39 245 79
52 524 600 21 2.1 PH831_0050K302_0115 MB23 EZ503U 1848 1850 3406 58.05 1161/20 8.0 15 3200 2800 4000 18 245 71
52 524 600 21 2.1 PH831_0050K302_0115 MB23 EZ503U 1848 1850 3406 58.05 1161/20 12 15 3200 2800 4000 18 245 71
52 649 778 26 1.7 PH831_0050K302_0115 MB33 EZ702U 1848 1850 3646 58.05 1161/20 16 15 3200 2800 4000 44 245 81
52 730 865 29 1.5 PH831_0050K302_0115 MB23 EZ505U 1848 1850 3406 58.05 1161/20 8.0 15 3200 2800 4000 22 245 74
52 730 865 29 1.5 PH831_0050K302_0115 MB23 EZ505U 1848 1850 3406 58.05 1161/20 12 15 3200 2800 4000 22 245 74
58 207 227 18 4.1 PH831_0100K202_0052 MB23 EZ501U 771 770 2784 51.77 21070/407 8.0 8.0 3000 2600 4000 12 260 63
58 207 227 18 4.1 PH831_0100K202_0052 MB23 EZ501U 771 770 2784 51.77 21070/407 12 8.0 3000 2600 4000 12 260 63
58 207 227 18 4.1 PH831_0100K202_0052 MB23 EZ501U 771 770 2784 51.77 21070/407 16 8.0 3000 2600 4000 12 260 63
58 227 251 19 3.8 PH831_0100K202_0052 MB23 EZ402U 771 770 2784 51.77 21070/407 8.0 8.0 3000 2600 4000 11 260 63
58 227 251 19 3.8 PH831_0100K202_0052 MB23 EZ402U 771 770 2784 51.77 21070/407 12 8.0 3000 2600 4000 11 260 63
58 227 251 19 3.8 PH831_0100K202_0052 MB23 EZ402U 771 770 2784 51.77 21070/407 16 8.0 3000 2600 4000 11 260 63
58 333 415 29 2.6 PH831_0100K202_0052 MB23 EZ404U 1392 1390 2784 51.77 21070/407 8.0 8.0 3000 2600 4000 12 260 65
58 333 415 29 2.6 PH831_0100K202_0052 MB23 EZ404U 1392 1390 2784 51.77 21070/407 12 8.0 3000 2600 4000 12 260 65
58 333 415 29 2.6 PH831_0100K202_0052 MB23 EZ404U 1392 1390 2784 51.77 21070/407 16 8.0 3000 2600 4000 12 260 65
58 357 386 31 2.4 PH831_0100K202_0052 MB23 EZ502U 1392 1390 2784 51.77 21070/407 8.0 8.0 3000 2600 4000 14 260 65
58 357 386 31 2.4 PH831_0100K202_0052 MB23 EZ502U 1392 1390 2784 51.77 21070/407 12 8.0 3000 2600 4000 14 260 65
58 357 386 31 2.4 PH831_0100K202_0052 MB23 EZ502U 1392 1390 2784 51.77 21070/407 16 8.0 3000 2600 4000 14 260 65
58 468 535 40 1.8 PH831_0100K202_0052 MB23 EZ503U 1392 1390 2784 51.77 21070/407 8.0 15 3000 2600 4000 18 260 66
58 468 535 40 1.8 PH831_0100K202_0052 MB23 EZ503U 1392 1390 2784 51.77 21070/407 12 15 3000 2600 4000 18 260 66
58 651 771 56 1.3 PH831_0100K202_0052 MB23 EZ505U 1392 1390 2784 51.77 21070/407 8.0 15 3000 2600 4000 22 260 69
58 651 771 56 1.3 PH831_0100K202_0052 MB23 EZ505U 1392 1390 2784 51.77 21070/407 12 15 3000 2600 4000 22 260 69
60 200 218 15 3.8 PH831_0070K202_0071 MB23 EZ501U 742 740 2917 49.83 14749/296 8.0 8.0 3000 2600 4000 12 245 63
60 200 218 15 3.8 PH831_0070K202_0071 MB23 EZ501U 742 740 2917 49.83 14749/296 12 8.0 3000 2600 4000 12 245 63
60 200 218 15 3.8 PH831_0070K202_0071 MB23 EZ501U 742 740 2917 49.83 14749/296 16 8.0 3000 2600 4000 12 245 63
60 218 241 17 3.4 PH831_0070K202_0071 MB23 EZ402U 742 740 2917 49.83 14749/296 8.0 8.0 3000 2600 4000 11 245 63
60 218 241 17 3.4 PH831_0070K202_0071 MB23 EZ402U 742 740 2917 49.83 14749/296 12 8.0 3000 2600 4000 11 245 63
60 218 241 17 3.4 PH831_0070K202_0071 MB23 EZ402U 742 740 2917 49.83 14749/296 16 8.0 3000 2600 4000 11 245 63
8 PHKright-angle planetary geared motors 8.2 Selection tables
