Stober PK - Page 230

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
60 320 399 24 2.3 PH831_0070K202_0071 MB23 EZ404U 1346 1350 2917 49.83 14749/296 8.0 8.0 3000 2600 4000 12 245 65
60 320 399 24 2.3 PH831_0070K202_0071 MB23 EZ404U 1346 1350 2917 49.83 14749/296 12 8.0 3000 2600 4000 12 245 65
60 320 399 24 2.3 PH831_0070K202_0071 MB23 EZ404U 1346 1350 2917 49.83 14749/296 16 8.0 3000 2600 4000 12 245 65
60 343 371 26 2.2 PH831_0070K202_0071 MB23 EZ502U 1421 1420 2917 49.83 14749/296 8.0 8.0 3000 2600 4000 14 245 65
60 343 371 26 2.2 PH831_0070K202_0071 MB23 EZ502U 1421 1420 2917 49.83 14749/296 12 8.0 3000 2600 4000 14 245 65
60 343 371 26 2.2 PH831_0070K202_0071 MB23 EZ502U 1421 1420 2917 49.83 14749/296 16 8.0 3000 2600 4000 14 245 65
60 343 385 26 2.2 PH831_0070K202_0071 MB33 EZ701U 928 930 2917 49.83 14749/296 16 15 3000 2600 4000 39 245 74
60 450 515 34 1.7 PH831_0070K202_0071 MB23 EZ503U 1421 1420 2917 49.83 14749/296 8.0 15 3000 2600 4000 18 245 66
60 450 515 34 1.7 PH831_0070K202_0071 MB23 EZ503U 1421 1420 2917 49.83 14749/296 12 15 3000 2600 4000 18 245 66
60 557 668 42 1.4 PH831_0070K202_0071 MB33 EZ702U 1421 1420 2917 49.83 14749/296 16 15 3000 2600 4000 44 245 76
60 626 742 48 1.2 PH831_0070K202_0071 MB23 EZ505U 1421 1420 2917 49.83 14749/296 8.0 15 3000 2600 4000 22 245 69
60 626 742 48 1.2 PH831_0070K202_0071 MB23 EZ505U 1421 1420 2917 49.83 14749/296 12 15 3000 2600 4000 22 245 69
64 187 205 15 3.9 PH831_0070K202_0067 MB23 EZ501U 697 700 2744 46.78 15953/341 8.0 8.0 3500 3100 4000 12 245 63
64 187 205 15 3.9 PH831_0070K202_0067 MB23 EZ501U 697 700 2744 46.78 15953/341 12 8.0 3500 3100 4000 12 245 63
64 187 205 15 3.9 PH831_0070K202_0067 MB23 EZ501U 697 700 2744 46.78 15953/341 16 8.0 3500 3100 4000 12 245 63
64 205 227 17 3.6 PH831_0070K202_0067 MB23 EZ402U 697 700 2744 46.78 15953/341 8.0 8.0 3500 3100 4000 10 245 63
64 205 227 17 3.6 PH831_0070K202_0067 MB23 EZ402U 697 700 2744 46.78 15953/341 12 8.0 3500 3100 4000 10 245 63
64 205 227 17 3.6 PH831_0070K202_0067 MB23 EZ402U 697 700 2744 46.78 15953/341 16 8.0 3500 3100 4000 10 245 63
64 301 375 25 2.4 PH831_0070K202_0067 MB23 EZ404U 1263 1260 2744 46.78 15953/341 8.0 8.0 3500 3100 4000 12 245 65
64 301 375 25 2.4 PH831_0070K202_0067 MB23 EZ404U 1263 1260 2744 46.78 15953/341 12 8.0 3500 3100 4000 12 245 65
64 301 375 25 2.4 PH831_0070K202_0067 MB23 EZ404U 1263 1260 2744 46.78 15953/341 16 8.0 3500 3100 4000 12 245 65
64 322 349 26 2.3 PH831_0070K202_0067 MB23 EZ502U 1350 1350 2744 46.78 15953/341 8.0 8.0 3500 3100 4000 14 245 65
64 322 349 26 2.3 PH831_0070K202_0067 MB23 EZ502U 1350 1350 2744 46.78 15953/341 12 8.0 3500 3100 4000 14 245 65
64 322 349 26 2.3 PH831_0070K202_0067 MB23 EZ502U 1350 1350 2744 46.78 15953/341 16 8.0 3500 3100 4000 14 245 65
64 322 362 26 2.3 PH831_0070K202_0067 MB33 EZ701U 871 870 2917 46.78 15953/341 16 15 3500 3100 4000 39 245 74
64 423 484 35 1.7 PH831_0070K202_0067 MB23 EZ503U 1391 1390 2744 46.78 15953/341 8.0 15 3500 3100 4000 17 245 66
64 423 484 35 1.7 PH831_0070K202_0067 MB23 EZ503U 1391 1390 2744 46.78 15953/341 12 15 3500 3100 4000 17 245 66
64 523 627 43 1.4 PH831_0070K202_0067 MB33 EZ702U 1391 1390 2917 46.78 15953/341 16 15 3500 3100 4000 44 245 76
64 588 697 48 1.3 PH831_0070K202_0067 MB23 EZ505U 1391 1390 2744 46.78 15953/341 8.0 15 3500 3100 4000 22 245 69
64 588 697 48 1.3 PH831_0070K202_0067 MB23 EZ505U 1391 1390 2744 46.78 15953/341 12 15 3500 3100 4000 22 245 69
65 298 371 15 3.5 PH831_0050K302_0093 MB23 EZ404U 1251 1250 2718 46.34 5375/116 8.0 8.0 3200 2800 4000 12 245 70
65 298 371 15 3.5 PH831_0050K302_0093 MB23 EZ404U 1251 1250 2718 46.34 5375/116 12 8.0 3200 2800 4000 12 245 70
65 298 371 15 3.5 PH831_0050K302_0093 MB23 EZ404U 1251 1250 2718 46.34 5375/116 16 8.0 3200 2800 4000 12 245 70
65 319 345 16 3.2 PH831_0050K302_0093 MB23 EZ502U 1338 1340 2718 46.34 5375/116 8.0 8.0 3200 2800 4000 15 245 70
65 319 345 16 3.2 PH831_0050K302_0093 MB23 EZ502U 1338 1340 2718 46.34 5375/116 12 8.0 3200 2800 4000 15 245 70
65 319 345 16 3.2 PH831_0050K302_0093 MB23 EZ502U 1338 1340 2718 46.34 5375/116 16 8.0 3200 2800 4000 15 245 70
65 319 358 16 3.2 PH831_0050K302_0093 MB33 EZ701U 863 860 3646 46.34 5375/116 16 15 3200 2800 4000 40 245 79
65 319 358 16 3.2 PH831_0050K302_0093 MB33 EZ701U 863 860 3646 46.34 5375/116 24 15 3200 2800 4000 40 245 79
65 419 479 21 2.5 PH831_0050K302_0093 MB23 EZ503U 1618 1620 2718 46.34 5375/116 8.0 15 3200 2800 4000 18 245 71
65 419 479 21 2.5 PH831_0050K302_0093 MB23 EZ503U 1618 1620 2718 46.34 5375/116 12 15 3200 2800 4000 18 245 71
65 518 621 26 2.0 PH831_0050K302_0093 MB33 EZ702U 1769 1770 3646 46.34 5375/116 16 15 3200 2800 4000 45 245 81
65 518 621 26 2.0 PH831_0050K302_0093 MB33 EZ702U 1769 1770 3646 46.34 5375/116 24 15 3200 2800 4000 45 245 81
65 582 690 29 1.8 PH831_0050K302_0093 MB23 EZ505U 1618 1620 2718 46.34 5375/116 8.0 15 3200 2800 4000 23 245 74
65 582 690 29 1.8 PH831_0050K302_0093 MB23 EZ505U 1618 1620 2718 46.34 5375/116 12 15 3200 2800 4000 23 245 74
71 168 184 15 4.2 PH831_0070K202_0060 MB23 EZ501U 626 630 2464 42.00 42/1 8.0 8.0 3000 2600 4000 12 245 63
71 168 184 15 4.2 PH831_0070K202_0060 MB23 EZ501U 626 630 2464 42.00 42/1 12 8.0 3000 2600 4000 12 245 63
71 168 184 15 4.2 PH831_0070K202_0060 MB23 EZ501U 626 630 2464 42.00 42/1 16 8.0 3000 2600 4000 12 245 63
71 184 203 17 3.9 PH831_0070K202_0060 MB23 EZ402U 626 630 2464 42.00 42/1 8.0 8.0 3000 2600 4000 11 245 63
71 184 203 17 3.9 PH831_0070K202_0060 MB23 EZ402U 626 630 2464 42.00 42/1 12 8.0 3000 2600 4000 11 245 63
71 184 203 17 3.9 PH831_0070K202_0060 MB23 EZ402U 626 630 2464 42.00 42/1 16 8.0 3000 2600 4000 11 245 63
71 270 336 25 2.6 PH831_0070K202_0060 MB23 EZ404U 1134 1130 2464 42.00 42/1 8.0 8.0 3000 2600 4000 12 245 65
71 270 336 25 2.6 PH831_0070K202_0060 MB23 EZ404U 1134 1130 2464 42.00 42/1 12 8.0 3000 2600 4000 12 245 65
71 270 336 25 2.6 PH831_0070K202_0060 MB23 EZ404U 1134 1130 2464 42.00 42/1 16 8.0 3000 2600 4000 12 245 65
71 289 313 27 2.5 PH831_0070K202_0060 MB23 EZ502U 1212 1210 2464 42.00 42/1 8.0 8.0 3000 2600 4000 15 245 65
71 289 313 27 2.5 PH831_0070K202_0060 MB23 EZ502U 1212 1210 2464 42.00 42/1 12 8.0 3000 2600 4000 15 245 65
71 289 313 27 2.5 PH831_0070K202_0060 MB23 EZ502U 1212 1210 2464 42.00 42/1 16 8.0 3000 2600 4000 15 245 65
71 289 325 27 2.5 PH831_0070K202_0060 MB33 EZ701U 782 780 2917 42.00 42/1 16 15 3000 2600 4000 39 245 74
71 289 325 27 2.5 PH831_0070K202_0060 MB33 EZ701U 782 780 2917 42.00 42/1 24 15 3000 2600 4000 39 245 74
71 379 434 35 1.9 PH831_0070K202_0060 MB23 EZ503U 1342 1340 2464 42.00 42/1 8.0 15 3000 2600 4000 18 245 66
71 379 434 35 1.9 PH831_0070K202_0060 MB23 EZ503U 1342 1340 2464 42.00 42/1 12 15 3000 2600 4000 18 245 66
71 469 563 43 1.5 PH831_0070K202_0060 MB33 EZ702U 1342 1340 2917 42.00 42/1 16 15 3000 2600 4000 45 245 76
71 469 563 43 1.5 PH831_0070K202_0060 MB33 EZ702U 1342 1340 2917 42.00 42/1 24 15 3000 2600 4000 45 245 76
71 528 626 48 1.3 PH831_0070K202_0060 MB23 EZ505U 1342 1340 2464 42.00 42/1 8.0 15 3000 2600 4000 23 245 69
71 528 626 48 1.3 PH831_0070K202_0060 MB23 EZ505U 1342 1340 2464 42.00 42/1 12 15 3000 2600 4000 23 245 69
8.2 Selection tables 8 PHKright-angle planetary geared motors
