n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH831K (n
1N
= 3000 rpm, M
2acc,max
= 1850 Nm)
75 175 194 18 4.9 PH831_0100K202_0040 MB23 EZ402U 596 600 2347 40.00 40/1 8.0 8.0 3000 2600 4000 12 260 63
75 175 194 18 4.9 PH831_0100K202_0040 MB23 EZ402U 596 600 2347 40.00 40/1 12 8.0 3000 2600 4000 12 260 63
75 175 194 18 4.9 PH831_0100K202_0040 MB23 EZ402U 596 600 2347 40.00 40/1 16 8.0 3000 2600 4000 12 260 63
75 257 320 27 3.3 PH831_0100K202_0040 MB23 EZ404U 1080 1080 2347 40.00 40/1 8.0 8.0 3000 2600 4000 13 260 65
75 257 320 27 3.3 PH831_0100K202_0040 MB23 EZ404U 1080 1080 2347 40.00 40/1 12 8.0 3000 2600 4000 13 260 65
75 257 320 27 3.3 PH831_0100K202_0040 MB23 EZ404U 1080 1080 2347 40.00 40/1 16 8.0 3000 2600 4000 13 260 65
75 276 298 29 3.1 PH831_0100K202_0040 MB23 EZ502U 1155 1150 2347 40.00 40/1 8.0 8.0 3000 2600 4000 15 260 65
75 276 298 29 3.1 PH831_0100K202_0040 MB23 EZ502U 1155 1150 2347 40.00 40/1 12 8.0 3000 2600 4000 15 260 65
75 276 298 29 3.1 PH831_0100K202_0040 MB23 EZ502U 1155 1150 2347 40.00 40/1 16 8.0 3000 2600 4000 15 260 65
75 276 309 29 3.1 PH831_0100K202_0040 MB33 EZ701U 745 740 2784 40.00 40/1 16 15 3000 2600 4000 40 260 74
75 276 309 29 3.1 PH831_0100K202_0040 MB33 EZ701U 745 740 2784 40.00 40/1 24 15 3000 2600 4000 40 260 74
75 361 413 38 2.4 PH831_0100K202_0040 MB23 EZ503U 1392 1390 2347 40.00 40/1 8.0 15 3000 2600 4000 19 260 66
75 361 413 38 2.4 PH831_0100K202_0040 MB23 EZ503U 1392 1390 2347 40.00 40/1 12 15 3000 2600 4000 19 260 66
75 447 536 46 1.9 PH831_0100K202_0040 MB33 EZ702U 1392 1390 2784 40.00 40/1 16 15 3000 2600 4000 45 260 76
75 447 536 46 1.9 PH831_0100K202_0040 MB33 EZ702U 1392 1390 2784 40.00 40/1 24 15 3000 2600 4000 45 260 76
75 503 596 52 1.7 PH831_0100K202_0040 MB23 EZ505U 1392 1390 2347 40.00 40/1 8.0 15 3000 2600 4000 23 260 69
75 503 596 52 1.7 PH831_0100K202_0040 MB23 EZ505U 1392 1390 2347 40.00 40/1 12 15 3000 2600 4000 23 260 69
81 237 296 15 4.0 PH831_0050K302_0074 MB23 EZ404U 998 1000 2168 36.96 2365/64 8.0 8.0 2700 2300 4000 13 245 70
81 237 296 15 4.0 PH831_0050K302_0074 MB23 EZ404U 998 1000 2168 36.96 2365/64 12 8.0 2700 2300 4000 13 245 70
81 237 296 15 4.0 PH831_0050K302_0074 MB23 EZ404U 998 1000 2168 36.96 2365/64 16 8.0 2700 2300 4000 13 245 70
81 255 275 16 3.7 PH831_0050K302_0074 MB23 EZ502U 1067 1070 2168 36.96 2365/64 8.0 8.0 2700 2300 4000 16 245 70
81 255 275 16 3.7 PH831_0050K302_0074 MB23 EZ502U 1067 1070 2168 36.96 2365/64 12 8.0 2700 2300 4000 16 245 70
81 255 275 16 3.7 PH831_0050K302_0074 MB23 EZ502U 1067 1070 2168 36.96 2365/64 16 8.0 2700 2300 4000 16 245 70
81 255 286 16 3.7 PH831_0050K302_0074 MB33 EZ701U 688 690 3646 36.96 2365/64 16 15 2700 2300 4000 40 245 79
81 255 286 16 3.7 PH831_0050K302_0074 MB33 EZ701U 688 690 3646 36.96 2365/64 24 15 2700 2300 4000 40 245 79
81 255 286 16 3.7 PH831_0050K302_0074 MB33 EZ701U 688 690 3646 36.96 2365/64 32 15 2700 2300 4000 40 245 79
81 334 382 22 2.9 PH831_0050K302_0074 MB23 EZ503U 1290 1290 2168 36.96 2365/64 8.0 15 2700 2300 4000 19 245 71
81 334 382 22 2.9 PH831_0050K302_0074 MB23 EZ503U 1290 1290 2168 36.96 2365/64 12 15 2700 2300 4000 19 245 71
81 413 496 27 2.3 PH831_0050K302_0074 MB33 EZ702U 1411 1410 3646 36.96 2365/64 16 15 2700 2300 4000 46 245 81
81 413 496 27 2.3 PH831_0050K302_0074 MB33 EZ702U 1411 1410 3646 36.96 2365/64 24 15 2700 2300 4000 46 245 81
81 413 496 27 2.3 PH831_0050K302_0074 MB33 EZ702U 1411 1410 3646 36.96 2365/64 32 15 2700 2300 4000 46 245 81
81 465 551 30 2.1 PH831_0050K302_0074 MB23 EZ505U 1290 1290 2168 36.96 2365/64 8.0 15 2700 2300 4000 24 245 74
81 465 551 30 2.1 PH831_0050K302_0074 MB23 EZ505U 1290 1290 2168 36.96 2365/64 12 15 2700 2300 4000 24 245 74
81 568 716 37 1.7 PH831_0050K302_0074 MB33 EZ703U 1800 1800 3646 36.96 2365/64 16 32 2700 2300 4000 58 245 84
81 733 1039 47 1.3 PH831_0050K302_0074 MB33 EZ705U 1800 1800 3646 36.96 2365/64 16 32 2700 2300 4000 70 245 90
83 145 159 16 4.7 PH831_0070K202_0052 MB23 EZ501U 540 540 2126 36.24 14749/407 8.0 8.0 3000 2600 4000 12 245 63
83 145 159 16 4.7 PH831_0070K202_0052 MB23 EZ501U 540 540 2126 36.24 14749/407 12 8.0 3000 2600 4000 12 245 63
83 145 159 16 4.7 PH831_0070K202_0052 MB23 EZ501U 540 540 2126 36.24 14749/407 16 8.0 3000 2600 4000 12 245 63
83 159 175 17 4.3 PH831_0070K202_0052 MB23 EZ402U 540 540 2126 36.24 14749/407 8.0 8.0 3000 2600 4000 11 245 63
83 159 175 17 4.3 PH831_0070K202_0052 MB23 EZ402U 540 540 2126 36.24 14749/407 12 8.0 3000 2600 4000 11 245 63
83 159 175 17 4.3 PH831_0070K202_0052 MB23 EZ402U 540 540 2126 36.24 14749/407 16 8.0 3000 2600 4000 11 245 63
83 233 290 25 2.9 PH831_0070K202_0052 MB23 EZ404U 979 980 2126 36.24 14749/407 8.0 8.0 3000 2600 4000 12 245 65
83 233 290 25 2.9 PH831_0070K202_0052 MB23 EZ404U 979 980 2126 36.24 14749/407 12 8.0 3000 2600 4000 12 245 65
83 233 290 25 2.9 PH831_0070K202_0052 MB23 EZ404U 979 980 2126 36.24 14749/407 16 8.0 3000 2600 4000 12 245 65
83 250 270 27 2.7 PH831_0070K202_0052 MB23 EZ502U 1046 1050 2126 36.24 14749/407 8.0 8.0 3000 2600 4000 15 245 65
83 250 270 27 2.7 PH831_0070K202_0052 MB23 EZ502U 1046 1050 2126 36.24 14749/407 12 8.0 3000 2600 4000 15 245 65
83 250 270 27 2.7 PH831_0070K202_0052 MB23 EZ502U 1046 1050 2126 36.24 14749/407 16 8.0 3000 2600 4000 15 245 65
83 250 280 27 2.7 PH831_0070K202_0052 MB33 EZ701U 675 670 2917 36.24 14749/407 16 15 3000 2600 4000 40 245 74
83 250 280 27 2.7 PH831_0070K202_0052 MB33 EZ701U 675 670 2917 36.24 14749/407 24 15 3000 2600 4000 40 245 74
83 327 375 35 2.1 PH831_0070K202_0052 MB23 EZ503U 1265 1270 2126 36.24 14749/407 8.0 15 3000 2600 4000 18 245 66
83 327 375 35 2.1 PH831_0070K202_0052 MB23 EZ503U 1265 1270 2126 36.24 14749/407 12 15 3000 2600 4000 18 245 66
83 405 486 44 1.7 PH831_0070K202_0052 MB33 EZ702U 1278 1280 2917 36.24 14749/407 16 15 3000 2600 4000 45 245 76
83 405 486 44 1.7 PH831_0070K202_0052 MB33 EZ702U 1278 1280 2917 36.24 14749/407 24 15 3000 2600 4000 45 245 76
83 456 540 49 1.5 PH831_0070K202_0052 MB23 EZ505U 1265 1270 2126 36.24 14749/407 8.0 15 3000 2600 4000 23 245 69
83 456 540 49 1.5 PH831_0070K202_0052 MB23 EZ505U 1265 1270 2126 36.24 14749/407 12 15 3000 2600 4000 23 245 69
98 134 148 17 4.8 PH831_0070K202_0044 MB23 EZ402U 455 460 1792 30.55 336/11 8.0 8.0 3000 2600 4000 12 245 63
98 134 148 17 4.8 PH831_0070K202_0044 MB23 EZ402U 455 460 1792 30.55 336/11 12 8.0 3000 2600 4000 12 245 63
98 134 148 17 4.8 PH831_0070K202_0044 MB23 EZ402U 455 460 1792 30.55 336/11 16 8.0 3000 2600 4000 12 245 63
98 196 245 25 3.3 PH831_0070K202_0044 MB23 EZ404U 825 820 1792 30.55 336/11 8.0 8.0 3000 2600 4000 13 245 65
98 196 245 25 3.3 PH831_0070K202_0044 MB23 EZ404U 825 820 1792 30.55 336/11 12 8.0 3000 2600 4000 13 245 65
98 196 245 25 3.3 PH831_0070K202_0044 MB23 EZ404U 825 820 1792 30.55 336/11 16 8.0 3000 2600 4000 13 245 65
98 211 228 27 3.0 PH831_0070K202_0044 MB23 EZ502U 882 880 1792 30.55 336/11 8.0 8.0 3000 2600 4000 15 245 65
98 211 228 27 3.0 PH831_0070K202_0044 MB23 EZ502U 882 880 1792 30.55 336/11 12 8.0 3000 2600 4000 15 245 65
98 211 228 27 3.0 PH831_0070K202_0044 MB23 EZ502U 882 880 1792 30.55 336/11 16 8.0 3000 2600 4000 15 245 65
8 PHKright-angle planetary geared motors 8.2 Selection tables
