Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
C002 ∅160 101.5 – ∅160 101.5 – – – – – – –
C102 ∅160 122.0 – ∅160 122.0 – ∅200 124.0 – – – –
C202 ∅160 133.0 – ∅160 133.0 – ∅200 135.0 – – – –
C302 ∅160 152.5 – ∅160 152.5 – ∅200 154.5 – ∅250 157.5 –
C402 ∅160 180.0 – ∅160 180.0 – ∅200 182.0 – ∅250 185.0 –
C502 ∅160 200.0 – ∅160 200.0 – ∅200 202.0 – ∅250 205.0 –
C612 – – – – – – ∅200 180.0 6 ∅250 183.0 6
C712 – – – – – – ∅200 201.0 – ∅250 203.0 –
C812 – – – – – – – – – ∅250 237.0 –
5 Chelical geared motors 5.3 Dimensional drawings
