Stober PK - Page 115

Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
C_MB23 140 59 102.9 58 64 57.5
C_MB33 161 59 115.4 58 64 71.0
C_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m a m a m a m
C002 ∅160 100 ∅160 100 – – – –
C102 ∅160 120 ∅160 120 ∅200 122 – –
C202 ∅160 132 ∅160 132 ∅200 134 – –
C302 ∅160 151 ∅160 151 ∅200 153 ∅250 156
C402 ∅160 178 ∅160 178 ∅200 180 ∅250 183
C502 ∅160 198 ∅160 198 ∅200 200 ∅250 203
C612 – – – – ∅200 197 ∅250 200
C712 – – – – ∅200 222 ∅250 224
C812 – – – – – – ∅250 270
5 Chelical geared motors 5.3 Dimensional drawings
115
