Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m a m a m a m
C002 ∅160 118 ∅160 118 – – – –
C102 ∅160 141 ∅160 141 ∅200 143 – –
C202 ∅160 159 ∅160 159 ∅200 161 – –
C302 ∅160 178 ∅160 178 ∅200 180 ∅250 183
C402 ∅160 206 ∅160 206 ∅200 208 ∅250 211
5 Chelical geared motors 5.3 Dimensional drawings
