Dimensions of gear units
Type
☐
a4
ad ad1
∅
b
B cd
∅
dd
∅
dh
∅
Dd
∅
Dh
∅
Dha
∅
e
f h H i2 i3 ld le lh las lha s4 sd sm sas t4 th uh
F1 100 29.5 150 70
j6
145 20 11.0
+0,5
20
H7
30 35 70 85 2.5 74 238.0 6.5 12.5 15 73 95 12 112 M8 M10 M6 M8 13 22.8 6
JS9
F2 130 33.0 181 95
j6
180 22 11.0
+0,5
25
H7
30 45 82 115 3.0 93 299.0 8.0 15.0 15 92 115 12 132 M8 M10 M10 M12 13 28.3 8
JS9
F3 150 36.5 205 110
j6
206 30 14.0
+0,5
30
H7
37 50 88 130 3.5 106 335.5 8.5 16.5 20 103 130 12 157 M10 M12 M10 M12 16 33.3 8
JS9
F4 150 38.5 228 110
j6
230 30 14.0
+0,5
40
H7
37 55 100 130 3.5 116 370.0 8.5 16.5 20 114 145 12 175 M10 M12 M16 M20 16 43.3 12
JS9
F6 180 44.5 270 130
j6
265 35 22.0
+0,5
50
H7
60 70 115 165 3.5 137 433.0 10.5 20.5 30 143 180 12 194 M10 M20 M16 M20 16 53.8 14
JS9
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
F_MB23 140 59 102.9 58 64 57.5
F_MB33 161 59 115.4 58 64 71.0
F_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
F102 ∅160 101.5 102.0 ∅160 101.5 102.0 – – – – – –
F202 ∅160 119.0 131.0 ∅160 119.0 131.0 ∅200 121.0 131.0 – – –
F302 ∅160 133.5 149.5 ∅160 133.5 149.5 ∅200 135.5 149.5 – – –
F402 ∅160 148.5 169.0 ∅160 148.5 169.0 ∅200 150.5 169.0 ∅250 153.5 169.0
F602 ∅160 179.5 196.0 ∅160 179.5 196.0 ∅200 181.5 196.0 ∅250 184.5 196.0
6 Foffset helical geared motors 6.3 Dimensional drawings
