Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
F_MB23 140 59 102.9 58 64 57.5
F_MB33 161 59 115.4 58 64 71.0
F_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
F102 ∅160 133.5 102.0 ∅160 133.5 102.0 – – – – – –
F202 ∅160 157.0 131.0 ∅160 157.0 131.0 ∅200 159.0 131.0 – – –
F302 ∅160 173.5 149.5 ∅160 173.5 149.5 ∅200 175.5 149.5 – – –
F402 ∅160 188.5 169.0 ∅160 188.5 169.0 ∅200 190.5 169.0 ∅250 193.5 169.0
F602 ∅160 219.5 196.0 ∅160 219.5 196.0 ∅200 221.5 196.0 ∅250 224.5 196.0
6 Foffset helical geared motors 6.3 Dimensional drawings
