Stober PK - Page 189

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
P731K (n
1N
= 3000 rpm, M
2acc,max
= 810 Nm)
150 88 98 18 5.0 P731_0050K202_0040 MB23 EZ402U 301 300 1186 20.00 20/1 16 8.0 3000 2600 4000 12 53 46
150 130 162 26 3.4 P731_0050K202_0040 MB23 EZ404U 546 550 1186 20.00 20/1 8.0 8.0 3000 2600 4000 13 53 48
150 130 162 26 3.4 P731_0050K202_0040 MB23 EZ404U 546 550 1186 20.00 20/1 12 8.0 3000 2600 4000 13 53 48
150 130 162 26 3.4 P731_0050K202_0040 MB23 EZ404U 546 550 1186 20.00 20/1 16 8.0 3000 2600 4000 13 53 48
150 139 151 28 3.2 P731_0050K202_0040 MB23 EZ502U 583 580 1186 20.00 20/1 8.0 8.0 3000 2600 4000 15 53 47
150 139 151 28 3.2 P731_0050K202_0040 MB23 EZ502U 583 580 1186 20.00 20/1 12 8.0 3000 2600 4000 15 53 47
150 139 151 28 3.2 P731_0050K202_0040 MB23 EZ502U 583 580 1186 20.00 20/1 16 8.0 3000 2600 4000 15 53 47
150 139 156 28 3.2 P731_0050K202_0040 MB33 EZ701U 376 380 1610 20.00 20/1 16 15 3000 2600 4000 40 53 57
150 139 156 28 3.2 P731_0050K202_0040 MB33 EZ701U 376 380 1610 20.00 20/1 24 15 3000 2600 4000 40 53 57
150 183 209 37 2.4 P731_0050K202_0040 MB23 EZ503U 706 710 1186 20.00 20/1 8.0 15 3000 2600 4000 19 53 49
150 183 209 37 2.4 P731_0050K202_0040 MB23 EZ503U 706 710 1186 20.00 20/1 12 15 3000 2600 4000 19 53 49
150 226 271 45 1.9 P731_0050K202_0040 MB33 EZ702U 772 770 1610 20.00 20/1 16 15 3000 2600 4000 45 53 59
150 226 271 45 1.9 P731_0050K202_0040 MB33 EZ702U 772 770 1610 20.00 20/1 24 15 3000 2600 4000 45 53 59
150 254 301 51 1.7 P731_0050K202_0040 MB23 EZ505U 706 710 1186 20.00 20/1 8.0 15 3000 2600 4000 23 53 52
150 254 301 51 1.7 P731_0050K202_0040 MB23 EZ505U 706 710 1186 20.00 20/1 12 15 3000 2600 4000 23 53 52
188 104 129 26 3.4 P731_0040K202_0040 MB23 EZ404U 437 440 948 16.00 16/1 8.0 8.0 3000 2600 4000 13 49 48
188 104 129 26 3.4 P731_0040K202_0040 MB23 EZ404U 437 440 948 16.00 16/1 12 8.0 3000 2600 4000 13 49 48
188 104 129 26 3.4 P731_0040K202_0040 MB23 EZ404U 437 440 948 16.00 16/1 16 8.0 3000 2600 4000 13 49 48
188 111 120 27 3.2 P731_0040K202_0040 MB23 EZ502U 467 470 948 16.00 16/1 8.0 8.0 3000 2600 4000 15 49 47
188 111 120 27 3.2 P731_0040K202_0040 MB23 EZ502U 467 470 948 16.00 16/1 12 8.0 3000 2600 4000 15 49 47
188 111 120 27 3.2 P731_0040K202_0040 MB23 EZ502U 467 470 948 16.00 16/1 16 8.0 3000 2600 4000 15 49 47
188 111 125 27 3.2 P731_0040K202_0040 MB33 EZ701U 301 300 1400 16.00 16/1 16 15 3000 2600 4000 40 49 57
188 111 125 27 3.2 P731_0040K202_0040 MB33 EZ701U 301 300 1400 16.00 16/1 24 15 3000 2600 4000 40 49 57
188 111 125 27 3.2 P731_0040K202_0040 MB33 EZ701U 301 300 1400 16.00 16/1 32 15 3000 2600 4000 40 49 57
188 146 167 36 2.5 P731_0040K202_0040 MB23 EZ503U 565 560 948 16.00 16/1 8.0 15 3000 2600 4000 19 49 49
188 146 167 36 2.5 P731_0040K202_0040 MB23 EZ503U 565 560 948 16.00 16/1 12 15 3000 2600 4000 19 49 49
188 181 217 45 2.0 P731_0040K202_0040 MB33 EZ702U 617 620 1400 16.00 16/1 16 15 3000 2600 4000 45 49 59
188 181 217 45 2.0 P731_0040K202_0040 MB33 EZ702U 617 620 1400 16.00 16/1 24 15 3000 2600 4000 45 49 59
188 181 217 45 2.0 P731_0040K202_0040 MB33 EZ702U 617 620 1400 16.00 16/1 32 15 3000 2600 4000 45 49 59
188 203 241 50 1.8 P731_0040K202_0040 MB23 EZ505U 565 560 948 16.00 16/1 8.0 15 3000 2600 4000 23 49 52
188 203 241 50 1.8 P731_0040K202_0040 MB23 EZ505U 565 560 948 16.00 16/1 12 15 3000 2600 4000 23 49 52
250 78 97 26 3.4 P731_0030K202_0040 MB23 EZ404U 327 330 711 12.00 12/1 8.0 8.0 3000 2600 4000 13 40 48
250 78 97 26 3.4 P731_0030K202_0040 MB23 EZ404U 327 330 711 12.00 12/1 12 8.0 3000 2600 4000 13 40 48
250 78 97 26 3.4 P731_0030K202_0040 MB23 EZ404U 327 330 711 12.00 12/1 16 8.0 3000 2600 4000 13 40 48
250 84 90 27 3.2 P731_0030K202_0040 MB23 EZ502U 350 350 711 12.00 12/1 8.0 8.0 3000 2600 4000 16 40 47
250 84 90 27 3.2 P731_0030K202_0040 MB23 EZ502U 350 350 711 12.00 12/1 12 8.0 3000 2600 4000 16 40 47
250 84 90 27 3.2 P731_0030K202_0040 MB23 EZ502U 350 350 711 12.00 12/1 16 8.0 3000 2600 4000 16 40 47
250 84 94 27 3.2 P731_0030K202_0040 MB33 EZ701U 226 230 1000 12.00 12/1 16 15 3000 2600 4000 41 40 57
250 84 94 27 3.2 P731_0030K202_0040 MB33 EZ701U 226 230 1000 12.00 12/1 24 15 3000 2600 4000 41 40 57
250 84 94 27 3.2 P731_0030K202_0040 MB33 EZ701U 226 230 1000 12.00 12/1 32 15 3000 2600 4000 41 40 57
250 110 125 36 2.5 P731_0030K202_0040 MB23 EZ503U 423 420 711 12.00 12/1 8.0 15 3000 2600 4000 19 40 49
250 110 125 36 2.5 P731_0030K202_0040 MB23 EZ503U 423 420 711 12.00 12/1 12 15 3000 2600 4000 19 40 49
250 135 163 45 2.0 P731_0030K202_0040 MB33 EZ702U 463 460 1000 12.00 12/1 16 15 3000 2600 4000 46 40 59
250 135 163 45 2.0 P731_0030K202_0040 MB33 EZ702U 463 460 1000 12.00 12/1 24 15 3000 2600 4000 46 40 59
250 135 163 45 2.0 P731_0030K202_0040 MB33 EZ702U 463 460 1000 12.00 12/1 32 15 3000 2600 4000 46 40 59
250 152 181 50 1.8 P731_0030K202_0040 MB23 EZ505U 423 420 711 12.00 12/1 8.0 15 3000 2600 4000 24 40 52
250 152 181 50 1.8 P731_0030K202_0040 MB23 EZ505U 423 420 711 12.00 12/1 12 15 3000 2600 4000 24 40 52
P831K (n
1N
= 3000 rpm, M
2acc,max
= 1840 Nm)
31 392 429 14 2.4 P831_0070K202_0140 MB23 EZ501U 1460 1460 2887 96.96 20167/208 8.0 8.0 3900 3500 4000 11 128 61
31 429 474 16 2.2 P831_0070K202_0140 MB23 EZ402U 1460 1460 2887 96.96 20167/208 8.0 8.0 3900 3500 4000 9.5 128 61
31 629 785 23 1.5 P831_0070K202_0140 MB23 EZ404U 1494 1490 2887 96.96 20167/208 8.0 8.0 3900 3500 4000 11 128 63
31 675 730 25 1.4 P831_0070K202_0140 MB23 EZ502U 1494 1490 2887 96.96 20167/208 8.0 8.0 3900 3500 4000 13 128 63
33 372 406 21 2.3 P831_0100K202_0092 MB23 EZ501U 1380 1380 2760 91.90 11395/124 8.0 8.0 3500 3100 4000 11 132 61
33 406 450 23 2.1 P831_0100K202_0092 MB23 EZ402U 1380 1380 2760 91.90 11395/124 8.0 8.0 3500 3100 4000 9.9 132 61
33 597 744 33 1.4 P831_0100K202_0092 MB23 EZ404U 1380 1380 2760 91.90 11395/124 8.0 8.0 3500 3100 4000 11 132 63
33 640 692 36 1.3 P831_0100K202_0092 MB23 EZ502U 1380 1380 2760 91.90 11395/124 8.0 8.0 3500 3100 4000 14 132 63
34 360 393 15 2.6 P831_0070K202_0125 MB23 EZ501U 1339 1340 2887 88.94 3913/44 8.0 8.0 3900 3500 4000 11 128 61
34 393 435 16 2.3 P831_0070K202_0125 MB23 EZ402U 1339 1340 2887 88.94 3913/44 8.0 8.0 3900 3500 4000 9.4 128 61
34 577 720 23 1.6 P831_0070K202_0125 MB23 EZ404U 1494 1490 2887 88.94 3913/44 8.0 8.0 3900 3500 4000 11 128 63
34 619 669 25 1.5 P831_0070K202_0125 MB23 EZ502U 1494 1490 2887 88.94 3913/44 8.0 8.0 3900 3500 4000 13 128 63
35 350 382 10 3.1 P831_0050K302_0175 MB23 EZ501U 1302 1300 3230 86.47 7955/92 8.0 8.0 3500 3100 4000 11 128 66
35 350 382 10 3.1 P831_0050K302_0175 MB23 EZ501U 1302 1300 3230 86.47 7955/92 12 8.0 3500 3100 4000 11 128 66
35 382 423 11 2.9 P831_0050K302_0175 MB23 EZ402U 1302 1300 3230 86.47 7955/92 8.0 8.0 3500 3100 4000 9.8 128 66
35 382 423 11 2.9 P831_0050K302_0175 MB23 EZ402U 1302 1300 3230 86.47 7955/92 12 8.0 3500 3100 4000 9.8 128 66
7 PKright-angle planetary geared motors 7.2 Selection tables
