Stober PK - Page 262

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ731K (n
1N
= 3000 rpm, M
2acc,max
= 1050 Nm)
77 171 190 20 2.9 PHQ731_0055K202_0071 MB23 EZ402U 583 580 2100 39.15 23177/592 12 8.0 3000 2600 4000 10 136 45
77 171 190 20 2.9 PHQ731_0055K202_0071 MB23 EZ402U 583 580 2100 39.15 23177/592 16 8.0 3000 2600 4000 10 136 45
77 252 314 29 2.0 PHQ731_0055K202_0071 MB23 EZ404U 1050 1050 2100 39.15 23177/592 8.0 8.0 3000 2600 4000 12 136 47
77 252 314 29 2.0 PHQ731_0055K202_0071 MB23 EZ404U 1050 1050 2100 39.15 23177/592 12 8.0 3000 2600 4000 12 136 47
77 252 314 29 2.0 PHQ731_0055K202_0071 MB23 EZ404U 1050 1050 2100 39.15 23177/592 16 8.0 3000 2600 4000 12 136 47
77 270 292 31 1.9 PHQ731_0055K202_0071 MB23 EZ502U 1050 1050 2100 39.15 23177/592 8.0 8.0 3000 2600 4000 14 136 46
77 270 292 31 1.9 PHQ731_0055K202_0071 MB23 EZ502U 1050 1050 2100 39.15 23177/592 12 8.0 3000 2600 4000 14 136 46
77 270 292 31 1.9 PHQ731_0055K202_0071 MB23 EZ502U 1050 1050 2100 39.15 23177/592 16 8.0 3000 2600 4000 14 136 46
77 354 405 41 1.4 PHQ731_0055K202_0071 MB23 EZ503U 1050 1050 2100 39.15 23177/592 8.0 15 3000 2600 4000 17 136 48
77 354 405 41 1.4 PHQ731_0055K202_0071 MB23 EZ503U 1050 1050 2100 39.15 23177/592 12 15 3000 2600 4000 17 136 48
77 492 583 56 1.0 PHQ731_0055K202_0071 MB23 EZ505U 1050 1050 2100 39.15 23177/592 8.0 15 3000 2600 4000 22 136 51
77 492 583 56 1.0 PHQ731_0055K202_0071 MB23 EZ505U 1050 1050 2100 39.15 23177/592 12 15 3000 2600 4000 22 136 51
82 147 161 18 3.4 PHQ731_0055K202_0067 MB23 EZ501U 548 550 2100 36.76 2279/62 8.0 8.0 3500 3100 4000 11 136 45
82 147 161 18 3.4 PHQ731_0055K202_0067 MB23 EZ501U 548 550 2100 36.76 2279/62 12 8.0 3500 3100 4000 11 136 45
82 147 161 18 3.4 PHQ731_0055K202_0067 MB23 EZ501U 548 550 2100 36.76 2279/62 16 8.0 3500 3100 4000 11 136 45
82 161 178 19 3.1 PHQ731_0055K202_0067 MB23 EZ402U 548 550 2100 36.76 2279/62 8.0 8.0 3500 3100 4000 10 136 45
82 161 178 19 3.1 PHQ731_0055K202_0067 MB23 EZ402U 548 550 2100 36.76 2279/62 12 8.0 3500 3100 4000 10 136 45
82 161 178 19 3.1 PHQ731_0055K202_0067 MB23 EZ402U 548 550 2100 36.76 2279/62 16 8.0 3500 3100 4000 10 136 45
82 236 294 28 2.1 PHQ731_0055K202_0067 MB23 EZ404U 993 990 2100 36.76 2279/62 8.0 8.0 3500 3100 4000 11 136 47
82 236 294 28 2.1 PHQ731_0055K202_0067 MB23 EZ404U 993 990 2100 36.76 2279/62 12 8.0 3500 3100 4000 11 136 47
82 236 294 28 2.1 PHQ731_0055K202_0067 MB23 EZ404U 993 990 2100 36.76 2279/62 16 8.0 3500 3100 4000 11 136 47
82 253 274 30 2.0 PHQ731_0055K202_0067 MB23 EZ502U 1050 1050 2100 36.76 2279/62 8.0 8.0 3500 3100 4000 14 136 46
82 253 274 30 2.0 PHQ731_0055K202_0067 MB23 EZ502U 1050 1050 2100 36.76 2279/62 12 8.0 3500 3100 4000 14 136 46
82 253 274 30 2.0 PHQ731_0055K202_0067 MB23 EZ502U 1050 1050 2100 36.76 2279/62 16 8.0 3500 3100 4000 14 136 46
82 253 284 30 2.0 PHQ731_0055K202_0067 MB33 EZ701U 685 680 2100 36.76 2279/62 16 15 3500 3100 4000 39 136 56
82 332 380 40 1.5 PHQ731_0055K202_0067 MB23 EZ503U 1050 1050 2100 36.76 2279/62 8.0 15 3500 3100 4000 17 136 48
82 332 380 40 1.5 PHQ731_0055K202_0067 MB23 EZ503U 1050 1050 2100 36.76 2279/62 12 15 3500 3100 4000 17 136 48
82 411 493 49 1.2 PHQ731_0055K202_0067 MB33 EZ702U 1050 1050 2100 36.76 2279/62 16 15 3500 3100 4000 44 136 58
82 462 548 56 1.1 PHQ731_0055K202_0067 MB23 EZ505U 1050 1050 2100 36.76 2279/62 8.0 15 3500 3100 4000 22 136 51
82 462 548 56 1.1 PHQ731_0055K202_0067 MB23 EZ505U 1050 1050 2100 36.76 2279/62 12 15 3500 3100 4000 22 136 51
91 132 144 17 3.8 PHQ731_0055K202_0060 MB23 EZ501U 492 490 1936 33.00 33/1 8.0 8.0 3000 2600 4000 12 136 45
91 132 144 17 3.8 PHQ731_0055K202_0060 MB23 EZ501U 492 490 1936 33.00 33/1 12 8.0 3000 2600 4000 12 136 45
91 132 144 17 3.8 PHQ731_0055K202_0060 MB23 EZ501U 492 490 1936 33.00 33/1 16 8.0 3000 2600 4000 12 136 45
91 144 160 19 3.5 PHQ731_0055K202_0060 MB23 EZ402U 492 490 1936 33.00 33/1 8.0 8.0 3000 2600 4000 11 136 45
91 144 160 19 3.5 PHQ731_0055K202_0060 MB23 EZ402U 492 490 1936 33.00 33/1 12 8.0 3000 2600 4000 11 136 45
91 144 160 19 3.5 PHQ731_0055K202_0060 MB23 EZ402U 492 490 1936 33.00 33/1 16 8.0 3000 2600 4000 11 136 45
91 212 264 28 2.4 PHQ731_0055K202_0060 MB23 EZ404U 891 890 1936 33.00 33/1 8.0 8.0 3000 2600 4000 12 136 47
91 212 264 28 2.4 PHQ731_0055K202_0060 MB23 EZ404U 891 890 1936 33.00 33/1 12 8.0 3000 2600 4000 12 136 47
91 212 264 28 2.4 PHQ731_0055K202_0060 MB23 EZ404U 891 890 1936 33.00 33/1 16 8.0 3000 2600 4000 12 136 47
91 227 246 30 2.2 PHQ731_0055K202_0060 MB23 EZ502U 953 950 1936 33.00 33/1 8.0 8.0 3000 2600 4000 14 136 46
91 227 246 30 2.2 PHQ731_0055K202_0060 MB23 EZ502U 953 950 1936 33.00 33/1 12 8.0 3000 2600 4000 14 136 46
91 227 246 30 2.2 PHQ731_0055K202_0060 MB23 EZ502U 953 950 1936 33.00 33/1 16 8.0 3000 2600 4000 14 136 46
91 227 255 30 2.2 PHQ731_0055K202_0060 MB33 EZ701U 615 610 2100 33.00 33/1 16 15 3000 2600 4000 39 136 56
91 298 341 39 1.7 PHQ731_0055K202_0060 MB23 EZ503U 1050 1050 1936 33.00 33/1 8.0 15 3000 2600 4000 18 136 48
91 298 341 39 1.7 PHQ731_0055K202_0060 MB23 EZ503U 1050 1050 1936 33.00 33/1 12 15 3000 2600 4000 18 136 48
91 369 443 48 1.4 PHQ731_0055K202_0060 MB33 EZ702U 1050 1050 2100 33.00 33/1 16 15 3000 2600 4000 45 136 58
91 415 492 54 1.2 PHQ731_0055K202_0060 MB23 EZ505U 1050 1050 1936 33.00 33/1 8.0 15 3000 2600 4000 22 136 51
91 415 492 54 1.2 PHQ731_0055K202_0060 MB23 EZ505U 1050 1050 1936 33.00 33/1 12 15 3000 2600 4000 22 136 51
105 114 125 17 4.4 PHQ731_0055K202_0052 MB23 EZ501U 424 420 1670 28.47 2107/74 8.0 8.0 3000 2600 4000 12 136 45
105 114 125 17 4.4 PHQ731_0055K202_0052 MB23 EZ501U 424 420 1670 28.47 2107/74 12 8.0 3000 2600 4000 12 136 45
105 114 125 17 4.4 PHQ731_0055K202_0052 MB23 EZ501U 424 420 1670 28.47 2107/74 16 8.0 3000 2600 4000 12 136 45
105 125 138 18 4.0 PHQ731_0055K202_0052 MB23 EZ402U 424 420 1670 28.47 2107/74 8.0 8.0 3000 2600 4000 11 136 45
105 125 138 18 4.0 PHQ731_0055K202_0052 MB23 EZ402U 424 420 1670 28.47 2107/74 12 8.0 3000 2600 4000 11 136 45
105 125 138 18 4.0 PHQ731_0055K202_0052 MB23 EZ402U 424 420 1670 28.47 2107/74 16 8.0 3000 2600 4000 11 136 45
105 183 228 27 2.7 PHQ731_0055K202_0052 MB23 EZ404U 769 770 1670 28.47 2107/74 8.0 8.0 3000 2600 4000 12 136 47
105 183 228 27 2.7 PHQ731_0055K202_0052 MB23 EZ404U 769 770 1670 28.47 2107/74 12 8.0 3000 2600 4000 12 136 47
105 183 228 27 2.7 PHQ731_0055K202_0052 MB23 EZ404U 769 770 1670 28.47 2107/74 16 8.0 3000 2600 4000 12 136 47
105 196 212 29 2.5 PHQ731_0055K202_0052 MB23 EZ502U 822 820 1670 28.47 2107/74 8.0 8.0 3000 2600 4000 14 136 46
105 196 212 29 2.5 PHQ731_0055K202_0052 MB23 EZ502U 822 820 1670 28.47 2107/74 12 8.0 3000 2600 4000 14 136 46
105 196 212 29 2.5 PHQ731_0055K202_0052 MB23 EZ502U 822 820 1670 28.47 2107/74 16 8.0 3000 2600 4000 14 136 46
105 196 220 29 2.5 PHQ731_0055K202_0052 MB33 EZ701U 530 530 2100 28.47 2107/74 16 15 3000 2600 4000 39 136 56
105 196 220 29 2.5 PHQ731_0055K202_0052 MB33 EZ701U 530 530 2100 28.47 2107/74 24 15 3000 2600 4000 39 136 56
105 257 294 37 1.9 PHQ731_0055K202_0052 MB23 EZ503U 994 990 1670 28.47 2107/74 8.0 15 3000 2600 4000 18 136 48
105 257 294 37 1.9 PHQ731_0055K202_0052 MB23 EZ503U 994 990 1670 28.47 2107/74 12 15 3000 2600 4000 18 136 48
9.2 Selection tables 9 PHQKright-angle planetary geared motors
