Stober PK - Page 316

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
EL1,2 EL3,4,5,6
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
K6 (n
1N
= 3000 rpm, M
2acc,max
= 1600 Nm)
78 271 293 7.4 4.7 K613_0380 MB23 EZ502U 1136 2308 38.32 156953/4096 16 8.0 3100 2800 4000 15 83 81
78 271 304 7.4 4.7 K613_0380 MB33 EZ701U 733 2900 38.32 156953/4096 16 15 3100 2800 4000 40 83 90
78 271 304 7.4 4.7 K613_0380 MB33 EZ701U 733 2900 38.32 156953/4096 24 15 3100 2800 4000 40 83 90
78 355 407 9.6 3.6 K613_0380 MB23 EZ503U 1374 2308 38.32 156953/4096 8.0 15 3100 2800 4000 19 83 83
78 355 407 9.6 3.6 K613_0380 MB23 EZ503U 1374 2308 38.32 156953/4096 12 15 3100 2800 4000 19 83 83
78 440 528 12 2.9 K613_0380 MB33 EZ702U 1502 2900 38.32 156953/4096 16 15 3100 2800 4000 45 83 93
78 440 528 12 2.9 K613_0380 MB33 EZ702U 1502 2900 38.32 156953/4096 24 15 3100 2800 4000 45 83 93
78 495 586 13 2.6 K613_0380 MB23 EZ505U 1374 2308 38.32 156953/4096 8.0 15 3100 2800 4000 23 83 86
78 495 586 13 2.6 K613_0380 MB23 EZ505U 1374 2308 38.32 156953/4096 12 15 3100 2800 4000 23 83 86
87 245 265 7.8 4.7 K613_0350 MB23 EZ502U 1026 2084 34.61 35441/1024 8.0 8.0 3100 2800 4000 15 83 81
87 245 265 7.8 4.7 K613_0350 MB23 EZ502U 1026 2084 34.61 35441/1024 12 8.0 3100 2800 4000 15 83 81
87 245 265 7.8 4.7 K613_0350 MB23 EZ502U 1026 2084 34.61 35441/1024 16 8.0 3100 2800 4000 15 83 81
87 245 275 7.4 5.0 K613_0350 MB33 EZ701U 662 2900 34.61 35441/1024 16 15 3100 2800 4000 40 83 90
87 245 275 7.4 5.0 K613_0350 MB33 EZ701U 662 2900 34.61 35441/1024 24 15 3100 2800 4000 40 83 90
87 245 275 7.4 5.0 K613_0350 MB33 EZ701U 662 2900 34.61 35441/1024 32 15 3100 2800 4000 40 83 90
87 321 367 10 3.6 K613_0350 MB23 EZ503U 1241 2084 34.61 35441/1024 8.0 15 3100 2800 4000 19 83 83
87 321 367 10 3.6 K613_0350 MB23 EZ503U 1241 2084 34.61 35441/1024 12 15 3100 2800 4000 19 83 83
87 397 476 12 3.1 K613_0350 MB33 EZ702U 1357 2900 34.61 35441/1024 16 15 3100 2800 4000 46 83 93
87 397 476 12 3.1 K613_0350 MB33 EZ702U 1357 2900 34.61 35441/1024 24 15 3100 2800 4000 46 83 93
87 397 476 12 3.1 K613_0350 MB33 EZ702U 1357 2900 34.61 35441/1024 32 15 3100 2800 4000 46 83 93
87 447 529 14 2.6 K613_0350 MB23 EZ505U 1241 2084 34.61 35441/1024 8.0 15 3100 2800 4000 23 83 86
87 447 529 14 2.6 K613_0350 MB23 EZ505U 1241 2084 34.61 35441/1024 12 15 3100 2800 4000 23 83 86
94 295 338 10 3.9 K613_0320 MB23 EZ503U 1142 1919 31.86 130479/4096 8.0 15 3100 2800 4000 20 83 83
94 295 338 10 3.9 K613_0320 MB23 EZ503U 1142 1919 31.86 130479/4096 12 15 3100 2800 4000 20 83 83
94 365 439 12 3.2 K613_0320 MB33 EZ702U 1249 2900 31.86 130479/4096 16 15 3100 2800 4000 46 83 93
94 365 439 12 3.2 K613_0320 MB33 EZ702U 1249 2900 31.86 130479/4096 24 15 3100 2800 4000 46 83 93
94 365 439 12 3.2 K613_0320 MB33 EZ702U 1249 2900 31.86 130479/4096 32 15 3100 2800 4000 46 83 93
94 411 487 14 2.8 K613_0320 MB23 EZ505U 1142 1919 31.86 130479/4096 8.0 15 3100 2800 4000 24 83 86
94 411 487 14 2.8 K613_0320 MB23 EZ505U 1142 1919 31.86 130479/4096 12 15 3100 2800 4000 24 83 86
104 267 305 11 3.9 K613_0290 MB23 EZ503U 1031 1733 28.77 29463/1024 8.0 15 3100 2800 4000 20 83 83
104 267 305 11 3.9 K613_0290 MB23 EZ503U 1031 1733 28.77 29463/1024 12 15 3100 2800 4000 20 83 83
104 330 396 12 3.5 K613_0290 MB33 EZ702U 1128 2900 28.77 29463/1024 16 15 3100 2800 4000 47 83 93
104 330 396 12 3.5 K613_0290 MB33 EZ702U 1128 2900 28.77 29463/1024 24 15 3100 2800 4000 47 83 93
104 330 396 12 3.5 K613_0290 MB33 EZ702U 1128 2900 28.77 29463/1024 32 15 3100 2800 4000 47 83 93
104 371 440 15 2.8 K613_0290 MB23 EZ505U 1031 1733 28.77 29463/1024 8.0 15 3100 2800 4000 24 83 86
104 371 440 15 2.8 K613_0290 MB23 EZ505U 1031 1733 28.77 29463/1024 12 15 3100 2800 4000 24 83 86
104 454 572 17 2.5 K613_0290 MB33 EZ703U 1600 2900 28.77 29463/1024 16 32 3100 2800 4000 58 83 96
104 586 831 21 2.0 K613_0290 MB33 EZ705U 1600 2900 28.77 29463/1024 16 32 3100 2800 4000 71 83 101
125 275 330 12 3.9 K613_0240 MB33 EZ702U 941 2900 24.01 24583/1024 16 15 2600 2300 4000 48 83 93
125 275 330 12 3.9 K613_0240 MB33 EZ702U 941 2900 24.01 24583/1024 24 15 2600 2300 4000 48 83 93
125 275 330 12 3.9 K613_0240 MB33 EZ702U 941 2900 24.01 24583/1024 32 15 2600 2300 4000 48 83 93
125 275 330 12 3.9 K613_0240 MB33 EZ702U 941 2900 24.01 24583/1024 45 15 2600 2300 4000 48 83 93
125 379 477 17 2.9 K613_0240 MB33 EZ703U 1492 2900 24.01 24583/1024 16 32 2600 2300 4000 60 83 96
125 379 477 17 2.9 K613_0240 MB33 EZ703U 1492 2900 24.01 24583/1024 24 32 2600 2300 4000 60 83 96
125 379 477 17 2.9 K613_0240 MB33 EZ703U 1492 2900 24.01 24583/1024 32 32 2600 2300 4000 60 83 96
125 489 693 22 2.2 K613_0240 MB33 EZ705U 1600 2900 24.01 24583/1024 16 32 2600 2300 4000 72 83 101
125 489 693 22 2.2 K613_0240 MB33 EZ705U 1600 2900 24.01 24583/1024 24 32 2600 2300 4000 72 83 101
125 489 693 22 2.2 K613_0240 MB33 EZ705U 1600 2900 24.01 24583/1024 32 32 2600 2300 4000 72 83 101
138 249 299 12 4.2 K613_0220 MB33 EZ702U 850 2900 21.68 5551/256 16 15 2600 2300 4000 49 83 93
138 249 299 12 4.2 K613_0220 MB33 EZ702U 850 2900 21.68 5551/256 24 15 2600 2300 4000 49 83 93
138 249 299 12 4.2 K613_0220 MB33 EZ702U 850 2900 21.68 5551/256 32 15 2600 2300 4000 49 83 93
138 249 299 12 4.2 K613_0220 MB33 EZ702U 850 2900 21.68 5551/256 45 15 2600 2300 4000 49 83 93
138 342 431 17 3.1 K613_0220 MB33 EZ703U 1347 2900 21.68 5551/256 16 32 2600 2300 4000 60 83 96
138 342 431 17 3.1 K613_0220 MB33 EZ703U 1347 2900 21.68 5551/256 24 32 2600 2300 4000 60 83 96
138 342 431 17 3.1 K613_0220 MB33 EZ703U 1347 2900 21.68 5551/256 32 32 2600 2300 4000 60 83 96
138 442 626 22 2.4 K613_0220 MB33 EZ705U 1600 2900 21.68 5551/256 16 32 2600 2300 4000 73 83 101
138 442 626 22 2.4 K613_0220 MB33 EZ705U 1600 2900 21.68 5551/256 24 32 2600 2300 4000 73 83 101
138 442 626 22 2.4 K613_0220 MB33 EZ705U 1600 2900 21.68 5551/256 32 32 2600 2300 4000 73 83 101
158 176 202 14 3.9 K613_0190 MB23 EZ503U 681 1144 18.99 17019/896 8.0 15 2600 2300 4000 24 83 83
158 176 202 14 3.9 K613_0190 MB23 EZ503U 681 1144 18.99 17019/896 12 15 2600 2300 4000 24 83 83
158 218 261 12 4.6 K613_0190 MB33 EZ702U 744 2900 18.99 17019/896 16 15 2600 2300 4000 50 83 93
158 218 261 12 4.6 K613_0190 MB33 EZ702U 744 2900 18.99 17019/896 24 15 2600 2300 4000 50 83 93
158 218 261 12 4.6 K613_0190 MB33 EZ702U 744 2900 18.99 17019/896 32 15 2600 2300 4000 50 83 93
158 218 261 12 4.6 K613_0190 MB33 EZ702U 744 2900 18.99 17019/896 45 15 2600 2300 4000 50 83 93
10.2 Selection tables 10 Khelical bevel geared motors
316
